Lassco Wizer CR-50P User Manual

Cornerounder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CR-50P
Cornerounder
USER'S MANUAL
Before operating this equipment, please read these
instructions completely and keep these operating
instructions for future reference.
R
485 Hague Street, Rochester, NY 14606 U.S.A.
Tel: 585-436-1934
www.lasscowizer.com
Serial Number:
Date of Purchase:
Dealer:
Address:
Telephone Number:
Fax: 585-464-8665
info@lasscowizer.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CR-50P and is the answer not in the manual?

Questions and answers

Related Manuals for Lassco Wizer CR-50P

Summary of Contents for Lassco Wizer CR-50P

  • Page 1 CR-50P Cornerounder USER’S MANUAL Serial Number: Date of Purchase: Dealer: Address: Before operating this equipment, please read these instructions completely and keep these operating instructions for future reference. Telephone Number: 485 Hague Street, Rochester, NY 14606 U.S.A. Tel: 585-436-1934 Fax: 585-464-8665 www.lasscowizer.com...

  • Page 2: Table Of Contents

    1 - Introduction 1.1 - Your New CR-50P Your New CR-50P........ Page 01 Thank you for your purchase of the CR-50P Shipping Damage Inspection....Page 01 Cornerounder . We ask that you take a moment to fill in the serial...

  • Page 3: Safety

    2 - Safety 2.1 - Safety Instructions All operators must read and understand the Users CHECK DAMAGED PARTS. Before further use of the ma- Manual including all safety instructions before using this chine, a guard or other part that is damaged should be care- equipment.

  • Page 4: Warning Labels

    2 - Safety 2.2 - Warning Labels English French WARNING: DO NOT EXPOSE TO RAIN AVERTISSEMENT: NE PAS EXPOSER OR USE IN DAMP LOCATIONS. À LA PLUIE ET NE PAS UTILISER DANS LES EMPLACEMENTS HUMIDES Page 03...

  • Page 5: Grounding Instructions

    2 - Safety 2.3 - Grounding Instructions Diagram 2-10 METAL SCREW COVER OF GROUNDED OUTLET BOX GROUNDING In the event of a malfunction or breakdown, grounding provides a path of least resistance for electric current to re- duce the risk of electric shock. This tool is equipped with an electric cord having an equipment-grounding conduc- tor and a grounding plug.

  • Page 6: Setting Up Your Machine

    Base of the Machine 3.2 - Electrical Start Up 3.2.1 Your CR-50P comes with an electrical cord containing the plug to fit into a standard grounded 115V outlet. 3.2.2 Your CR-50P also has a power switch with keyed lock-out. Make Power Cord sure that the key is removed before continuing on to step 3.2.3.

  • Page 7: Cutting Unit Installation (Standard & Special Sizes)

    3 - Setting Up Your Machine 3.3 - Cutting Unit Installation (Standard & Special Sizes) 3.3.1 Loosen the Top Yoke Wing Nut (50-34) on the right hand side of the Top Yoke (50-15) and swing the Top Yoke toward you to obtain access to the Cutting Unit Cavity in the Table Ring Casting (50-14). 3.3.2 Making sure the Adapter Hold Down Tab (50-11) is not in the way, insert the Adapter Plate (50-26) into the Table Ring Casting.

  • Page 8: Cutting Unit Installation (Large Sizes)

    3 - Setting Up Your Machine 3.4 - Cutting Unit Installation (Large Sizes) 3.4.1 Loosen the Top Yoke Wing Nut (50-34) on the right hand side of the Top Yoke (50-15) and swing the Top Yoke as shown to obtain access to the Cutting Unit Cavity in the Table Ring Casting (50-14). 3.4.2 Make sure the Adapter Plate has been removed.

  • Page 9: Adjusting The Pressure Foot

    3 - Setting Up Your Machine 3.6 - Adjusting the Pressure Foot PRESSURE FOOT ASSEMBLY IS NOT REMOVEABLE Wing Nut Hex Nut 3.6.1 To adjust horizontally (depending on the size of the Cutting Unit) Thumb Screw loosen the center Thumb Screw on the Top Yoke, adjust in or out until the Pressure Foot clears the black guard on the Cutting Unit.

  • Page 10: Maintenance

    5 - Maintenance 5.1 - Safety ALWAYS DISCONNECT THE POWER BEFORE PERFORMING MAINTENANCE ON THIS MACHINE. MAINTENANCE SHOULD ONLY BE PERFORMED BY A QUALIFIED TECHNICIAN. KEEP HANDS CLEAR WHILE PERFORMING MAINTENANCE ON THIS MACHINE. MOVING PARTS CAN CRUSH AND CUT. 5.2 - Annual Lubrication 5.2.1 Lightly oil the two Yoke Slide Rods where they enter the adapter ring approximately every two weeks or as needed...
  • Page 11 6 - Troubleshooting 6.1 - Determining the Cause and Correction to Certain Problems Problem Cause Correction Machine cycles continuously Foot Pedal stuck in depressed Replace foot pedal mode Micro-Switch is faulty or out of See Micro-Switch adjustment adjustment below To properly adjust the Micro-Switch: 6.1.1 Rotate the motor until the Cam Block is at the top dead center as shown in the diagram below.

  • Page 12: Parts Diagram

    6 - Parts Diagram 6.1 - Parts Diagram Page 11...

  • Page 13: Parts List

    6 - Parts Diagram 6.2 - Parts List 50-26: Adapter Plate 50-12: Adapter Plate Rotation Tab 50-15: Top Yoke 50-201A: Pressure Foot Assembly 50-03L: Left Paper Guide (50-03R: Right Paper Guide Not Shown) 50P-80: Wood Table 50-04: Yoke Slide Rods 50P-41: Bottom Yoke 50P-22: Microswitch Actuator 50P-2000A: Microswitch Assembly...
