Tools; Parts; Orientate The Power Cable Like This; Fit The Cable Guide Part - Hypercom T4220 PEDPack Quick Installation Manual
Hide thumbs
Also See for T4220 PEDPack:
- Quick reference manual (10 pages) ,
- Quick manual (4 pages) ,
- Quick reference manual (2 pages)
Table of Contents
Advertisement
TOOLS
TOOLS
RECOMMENDED
Torque setting 40CNm
for all screw fixings
5 min
PZ
2
4
OPTIONAL
If locking device, turn key
then remove to secure.
To unlock, first ensure
key fitted.
PARTS
x2
x1
Fit the cable guide
part
x2
Torque setting 40CNm
1
Hook cables
through gap without
unplugging
3
To remove device...
Hypercom T4220- PEDPack
Quick Installation Guide
Cable Guide part
Orientate the power
cable like this
