Garmin GPSMAP 702 Series Installation Instructions Manual

GPSMAP 702/902 SERIES
®
INSTALLATION
INSTRUCTIONS

Important Safety Information

See the Important Safety and Product Information guide in the
product box for product warnings and other important
information.
When connecting the power cable, do not remove the in-line
fuse holder. To prevent the possibility of injury or product
damage caused by fire or overheating, the appropriate fuse
must be in place as indicated in the product specifications. In
addition, connecting the power cable without the appropriate
fuse in place voids the product warranty.
Always wear safety goggles, ear protection, and a dust mask
when drilling, cutting, or sanding.
When drilling or cutting, always check what is on the opposite
side of the surface.
To obtain the best performance and to avoid damage to your
boat, install the device according to these instructions.
Read all installation instructions before proceeding with the
installation. If you experience difficulty during the installation,
contact Garmin Product Support.
®
Contacting Garmin Support
• Go to support.garmin.com
product manuals, frequently asked questions, videos, and
customer support.
• In the USA, call 913-397-8200 or 1-800-800-1020.
• In the UK, call 0808 238 0000.
• In Europe, call +44 (0) 870 850 1241.
Updating the Device Software
You may need to update the device software when you install
this device or add an accessory to the network. You can use
one of two methods to update the software.
• Use the ActiveCaptain
™
• Download the update from
/software/marine.html using a 32 GB card and a computer
running Windows operating system.
®
For more information, see the owner's manual at
www.garmin.com/manuals/GPSMAP702-902.
Registering Your Device
Help us better support you by completing our online registration
today. You can register your device using one of two methods.
• Use the ActiveCaptain app.
WARNING
CAUTION
NOTICE
for help and information, such as
app.
www.garmin.com/support
• Go to my.garmin.com/registration
account to register the device.
Keep the original sales receipt, or a photocopy, in a safe place.
After you add devices to the chartplotter network, register the
new devices.
Tools Needed
• Drill
• Drill bits appropriate for the device and mounting style
Mounting Style
Bail with included M4 wood screws
Flush
Flush with included M3.5 wood screws (702 series) 2 mm (
Flush with included M4 wood screws (902 series)
Flush with included machine screws and nut plates 6 mm (
Flush with included M3.5 machine screws and
tapped holes (702 series)
Flush with included M4 machine screws and tapped
holes (902 series)
• #2 Phillips screwdriver
• Jigsaw or rotary tool
• File and sandpaper
• Marine sealant (recommended)

Mounting Considerations

This device should be mounted in a location that is not exposed
to extreme temperatures or conditions. The temperature range
for this device is listed in the product specifications. Extended
exposure to temperatures exceeding the specified temperature
range, in storage or operating conditions, may cause device
failure. Extreme-temperature-induced damage and related
consequences are not covered by the warranty.
When selecting a mounting location, you should observe these
considerations.
• The location should provide optimal viewing as you operate
your boat.
• The location should allow for easy access to all device
interfaces, such as the keypad, touchscreen, and card
reader, if applicable.
• The location must be strong enough to support the weight of
the device and protect it from excessive vibration or shock.
• To avoid interference with a magnetic compass, the device
should not be installed closer to a compass than the
compass-safe distance value listed in the product
specifications.
• The location must allow room for the routing and connection
of all cables.
• The location must not be a flat, horizontal surface. The
location should be in a vertical angle.
The location and viewing angle should be tested before you
install the device. High viewing angles from above and below
the display may result in a poor image.
Bail Mounting the Device
If you are mounting the bracket on fiberglass with screws, it is
recommended to use a countersink bit to drill a clearance
counterbore through only the top gel-coat layer. This will help to
avoid cracking in the gel-coat layer when the screws are
tightened.
and sign into your Garmin
Drill Bit Sizes
3.2 mm (
13 mm (
3.2 mm (
4 mm (
M3.5 tap
M4 tap
NOTICE
NOTICE
October 2018
190-02141-02_0D
1
/ in.)
8
1
/ in.)
2
5
/ in.)
64
1
/ in.)
8
1
/ in.)
4
3
/ in.)
16
