American Pinball Houdini Master of Mystery Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Houdini Master of Mystery and is the answer not in the manual?

Questions and answers

Related Manuals for American Pinball Houdini Master of Mystery

Summary of Contents for American Pinball Houdini Master of Mystery

  • Page 3 STOP AND READ - UNPLUGING BOARD CONNECTORS WARNING! WHILE THE MACHINE IS POWERED ON CAN, AND MOST LIKELY WILL, DESTROY THE BOARD!!! THIS IS NOT COVERED UNDER AMERICAN PINBALL’S WARRANTY AND YOU ARE RESPONSIBLE FOR A REPLACEMENT BOARD, WITH NO EXCEPTIONS. Houdini Service Manual W W W .

  • Page 4: Coverage

    Service related questions can also be sent via e-mail to service@american-pinball.com. Defective parts need to be sent to American Pinball at the purchaser’s expense, if the defective parts cannot be removed, the entire Pinball Machine will need to be returned to the Distributor for repair or replacement. All parts returned must be properly packaged with an RMA tag/Trouble ticket then returned freight prepaid to the Sellers facility.

  • Page 5: Disclaimer Of Damage

    STOP AND READ - UNPLUGING BOARD CONNECTORS WARNING! WHILE THE MACHINE IS POWERED ON CAN, AND MOST LIKELY, WILL DESTROY THE BOARD!!! THIS IS NOT COVERED UNDER AMERICAN PINBALL’S WARRANTY AND YOU WILL ARE RESPONSIBLE FOR A REPLACEMENT BOARD, WITH NO EXCEPTIONS. Houdini Service Manual...

  • Page 6: Notices

    OPENING THE COIN DOOR EXPOSES HIGH VOLTAGE WARNING! PARTS IN THE GAME, AND DIRECT CONTACT TO THESE HIGH VOLTAGE PARTS CAN LEAD TO SERIOUS OR FATAL INJURIES. THIS EQUIPMENT IS ONLY TO BE SERVICED BY TRAINED PROFESSIONALS ONLY. N O T I C E S Cable harness placements and ground strap routing in the game have been designed to keep RF radiation and conduction within levels accepted by the FCC rules.
  • Page 7 Pinball. Any reproductions or modifications are illegal. W A R N I N G S American Pinball authorized parts are to be used only. Using ANY unauthorized parts will void all warranties and may cause injury to persons or property.
  • Page 8 viii Houdini Service Manual...

  • Page 9: Table Of Contents

    ONTENTS ........Contents Coverage ......................-iv Conditions.......................
  • Page 10 C O N T E N T S To access Houdini’s Sound settings ............3-29 Standard Adjustment Settings ..............3-31 To access Houdini’s Standard Adjustments settings .......3-31 Presets ......................3-32 To access Houdini’s Presets..............3-32 Statistics......................3-34 To access Houdini’s Statistics menu ............3-34 Utilities......................3-36 To access Houdini’s Utilities menu ............3-36 Switch Locations ..............4-39 Dedicated Switch Locations ................4-39 Playfield Switch Map ...................4-41...
  • Page 11 C O N T E N T S To configure the Serial Chain Manager ...........6-80 Configuring the Serial Chain Controllers .............6-80 To configure a Serial Chain Controller:............6-80 PDB Protocol ....................6-87 To install the P-ROC LED Board hardware ..........6-88 Section 5: Board Drawings and Parts .............6-89 Assemblies, Posts &...
  • Page 12 C O N T E N T S Seance Multiball ..................8-171 Outlane Drain Modes.................8-171 Milkcan Multipliers ..................8-172 Master Magician (Wizard) Mode..............8-173 Stacking.....................8-173 Houdini Code Update ............9-175 Code Update Procedure ................9-175 To download Houdini Code to a Microsoft Windows PC .......9-176 To download Houdini Code to a MAC............9-176 To update Houdini code.................9-176 Houdini Log Copy ..................9-179...
  • Page 13 IST OF IGURES ........Contents Open Carton ...........2-3 Carton View After Laying On Side .
  • Page 14 L I S T O F F I G U R E S PCB0013 All Layers ..........6-99 PCB0013 Bottom View .
  • Page 15 L I S T O F F I G U R E S Right Flipper Assembly .........7-142 Right Flipper Assembly Detailed .
  • Page 16 L I S T O F F I G U R E S Houdini Service Manual...
  • Page 17 IST OF ABLES ........Contents Service Menu Icons..........3-14 Tests Menu Icons .
  • Page 18 L I S T O F TA B L E S P3-ROC J13 USB table ..........6-59 P3-ROC J14 Serial Switches table .
  • Page 19 L I S T O F TA B L E S Driver Board table ..........6-73 Power Driver 16 PDB Protocol table .
  • Page 20 L I S T O F TA B L E S Parts for Stage Mech Breakdown Assembly......7-149 Parts for Stage Monitor Assembly.

  • Page 21: Overview

    Ch 1 - Overview VERVIEW ........
  • Page 22 O V E R V I E W About This Manual Houdini Service Manual...

  • Page 23: Unpacking Instructions

    Ch Unpacking Instructions - Unpacking Instructions NPACKING NSTRUCTIONS ........

  • Page 24: Carton View After Laying On Side

    U N PA C K I N G I N S T R U C T I O N S Unpacking Houdini Figure 2.2 Carton View After Laying On Side Remove the 2 top corner protectors (highlighted in the following picture). Figure 2.3 Remove Corner Protectors Pull the game out by the center strap.

  • Page 25: Pull Game Out By Center Strap

    U N PA C K I N G I N S T R U C T I O N S Unpacking Houdini Figure 2.4 Pull Game Out By Center Strap Remove the four legs from the bottom corner protectors. Figure 2.5 Remove Bottom Corner Protectors Slide the game completely out of the box.

  • Page 26: Game Out Of Box

    U N PA C K I N G I N S T R U C T I O N S Unpacking Houdini Figure 2.6 Game Out of Box With assistance, stand the game upright. Figure 2.7 Game Upright Cut the shrink wrap by the front legs. Figure 2.8 Cut Shrink Wrap Houdini Service Manual...

  • Page 27: Install Leg Mounting Hardware

    U N PA C K I N G I N S T R U C T I O N S Unpacking Houdini Install the legs with the supplied hardware. Figure 2.9 Install Leg Mounting Hardware Lay the game down and cut away the shrink wrap covering the rear leg mounting area. Figure 2.10 Remove Shrink Wrap From Rear Legs Carefully lift the game and rest it either on your knee or on a stool.

  • Page 28: Houdini Lifted On Back Legs

    U N PA C K I N G I N S T R U C T I O N S Unpacking Houdini Figure 2.11 Houdini Lifted on Back Legs Now install the two front legs with the included hardware. Once legs are installed, return the game to normal resting position. Figure 2.12 Houdini Raised on Back Legs Cut and remove the center band, remove the remaining shrink wrap, and the two cardboard protectors from the machine.

  • Page 29: Securing Head In Place

    U N PA C K I N G I N S T R U C T I O N S Unpacking Houdini Figure 2.14 Houdini Head Raised Turn the Allen wrench clockwise to secure the head in place. Figure 2.15 Securing Head in Place BE CAREFUL TO NOT PINCH THE WIRES WHEN LIFTING THE HEAD CAUTION! INTO UPRIGHT POSITION.
  • Page 30 Pull the glass off and follow the supplied instructions that are attached to playfield. ENJOY YOUR GAME! Go to American Pinball’s website www.american-pinball.com/support/register/ to register your pinball machine. Product registration only takes a few minutes to complete and provides the following benefits: •...

  • Page 31: Leveling Houdini

    U N PA C K I N G I N S T R U C T I O N S Unpacking Houdini If necessary, perform coil adjustments. For more information on coil adjustments, refer to the Service Menu chapter in this manual.
  • Page 32 U N PA C K I N G I N S T R U C T I O N S Unpacking Houdini 2-12 Houdini Service Manual...

  • Page 33: Service Menu

    • Have you unpacked your Houdini machine and set it up according to the instructions in this manual? • Have you downloaded the most current supported code from American Pinball’s Support site? Settings are occasionally updated. Please refer to American Pinball’s Support Note: site for the most current documentation.

  • Page 34: Api Cockpit

    S E R V I C E M E N U Houdini Service Menu A P I C O C K P I T Houdini’s service menu contains tests for all the electrical and mechanical functions within the game. Figure 3.1 Service Menu Navigation Buttons Table 3.1 Service Menu Icons...

  • Page 35: Tests

    Health Houdini is in an unhealthy state. Refer to the Houdini Meter - Service Manual or contact your American Pinball distributor. T E S T S The Tests menu includes a number of diagnostic tests for assuring that your machine is performing at its optimal health.

  • Page 36: Tests Menu

    S E R V I C E M E N U Houdini Service Menu Table 3.2 Tests Menu Icons Switches Coils Display Cabinet Stage Mechanical 3-16 Houdini Service Manual...

  • Page 37: To Access Houdini's Tests Menu

    S E R V I C E M E N U Houdini Service Menu To access Houdini’s Tests menu Power on the machine. Open the coin door. Press the MENU SELECT button to access the service mode. Figure 3.2 Service Menu Navigation Buttons Press the red +/- button to select the Tests icon.

  • Page 38: Switch Testing

    S E R V I C E M E N U Houdini Service Menu Table 3.3 API Cockpit Navigation API Cockpit Button Flipper Button Equivalent Functionality Green Press left and right flipper • Back one level buttons simultaneously • Exit Red (+) Right flipper •...

  • Page 39: Coil Testing

    S E R V I C E M E N U Houdini Service Menu For a more extensive description of each switch within Houdini, refer to the Note: Switch Locations chapter. C O I L T E S T I N G To test coils, you must close the coin door in order to provide power.

  • Page 40: Coil Adjustment Settings

    S E R V I C E M E N U Houdini Service Menu C O I L A D J U S T M E N T S E T T I N G S Coil settings allow you to control the “strength” of the various mechanisms on the playfield.

  • Page 41: Coil Adjustment Settings

    S E R V I C E M E N U Houdini Service Menu Decrease the number of the LOWER CATAPULT by one and repeat the process. U P P E R C A T A P U L T Place a ball in the upper catapult located right below the trunk.

  • Page 42: Features Adjustment Settings

    S E R V I C E M E N U Houdini Service Menu Name Description Value (Range) Left Pop Specifies the strength of the left pop • Options: 5 to 20 bumper. • Increments: 1 • Default: 12 Left Sling Specifies the strength of the left sling.

  • Page 43: Features Adjustment Settings

    S E R V I C E M E N U Houdini Service Menu Press the MENU SELECT button to enter the Settings section. Use the flipper buttons to page through the different settings to the Features setting. Press the green BACK EXIT button to return to the previous menu. Table 3.5 Features Adjustment Settings Name...
  • Page 44 S E R V I C E M E N U Houdini Service Menu Name Description Value (Range) Jail Escapes Difficulty Specifies the level of difficulty required for Jail Escape Hurry • Options: Easy, Hard Ups. • Default: Easy For example: When set to easy, a ramp shot only needs to enter ramp and not hit the target to complete Jail Escape Hurry King of Cards Throws Per Specifies the number of cards that the player can throw from...
  • Page 45 S E R V I C E M E N U Houdini Service Menu Name Description Value (Range) Missions Completed For Specifies the number of completed missions required to earn a • Options: Off, 2, 3, 4, 5 Houdini Letter Houdini letter.

  • Page 46: Pricing Adjustment Settings

    S E R V I C E M E N U Houdini Service Menu Name Description Value (Range) Tournament Mode Specifies the conditions to prepare a game for tournament • Options: On, Off play. Disable all extra balls, removes randomness of Magic •...

  • Page 47: Price Table

    S E R V I C E M E N U Houdini Service Menu Table 3.6 Price Table Desired Coinage Set “Pricing Plan’ 25 cents per game 1 unit = 1 credit 25 cents per game 1 unit for 1 credit, 2 for 3 50 cents per game 2 units for 1 credit 50 cents per game or 3 games per dollar...

  • Page 48: Replay Adjustment Settings

    S E R V I C E M E N U Houdini Service Menu Name Description Value (Range) Max Service Credits The highest number of credits that can be added to the • Options: 0 to 98 machine. • Increments: 1 •...

  • Page 49: Sound Adjustment Settings

    S E R V I C E M E N U Houdini Service Menu Name Description Value (Range) Replay Award Level 2 Specifies the point total required to receive an award that is • Options:50000,5000000 defined in Replay Award Type. •...

  • Page 50: Sound Adjustment Settings

    S E R V I C E M E N U Houdini Service Menu Press the green BACK EXIT button to return to the previous menu. Table 3.9 Sound Adjustment Settings Name Description Value (Range) Announce Next Shot Specifies whether the narrator describes the next shot, after •...

  • Page 51: Standard Adjustment Settings

    S E R V I C E M E N U Houdini Service Menu S T A N D A R D A D J U S T M E N T S E T T I N G S Standard adjustments address global options, such as the number of balls per game, tilt settings, and replay award settings.

  • Page 52: Presets

    The Presets feature allows you load a profile of settings. There are seven presets available. In addition, from the Preset menu, you can save your current settings and re-load them. Presets are subject to change. Refer to American Pinball’s Support page for Note: the most current listing of Presets.

  • Page 53: Preset Settings Table

    S E R V I C E M E N U Presets Press the green BACK EXIT button to return to the previous menu. Table 3.11 Preset Settings table Default Extra Name Extra Easy Easy Medium Hard Setting Hard Bonus Multiplier Extra Ball Level Escapes for Escape Death FILM Lit at Start of Game Handcuff Escape Pops per Handcuff...

  • Page 54: Statistics

    S E R V I C E M E N U Statistics Default Extra Name Extra Easy Easy Medium Hard Setting Hard Timer for Stage Modes (in seconds) Trunk MB Lock starts Lit Trunk Multiball Ball Save Trunk Multiball Jackpots for Houdini Super Letter .

  • Page 55: Seance Multiball

    S E R V I C E M E N U Statistics Screen Audit Name Description Total Extra Balls The total number of earned extra balls. Total Games Played The total number of games played. 1 Player Games The total number of 1 player games. Basic 2 Player Games The total number of 2 player games.

  • Page 56: Utilities

    S E R V I C E M E N U Utilities Screen Audit Name Description Score 0 to 10K Total number of games with scores between 0 and 10k. Score 10K to 25K Total number of games with scores between 10k and 25k. Score 25K to 50K Total number of games with scores between 25k and 50k.
  • Page 57 S E R V I C E M E N U Utilities Table 3.13 Utilities Utility Name Description Clear Houdini’s Ejects the ball from subway and trough. Balls Clear Statistics The current statistics will be moved to ‘previous period’ and all values will be set back to 0. Note: This does not impact all time statistics.
  • Page 58 S E R V I C E M E N U Utilities 3-38 Houdini Service Manual...

  • Page 59: Switch Locations

    Ch 4 - Switch Locations WITCH OCATIONS ........
  • Page 60 S W I T C H L O C AT I O N S Dedicated Switch Locations DEDICATED SWITCH LOCATIONS Return 1 Return 2 Return 3 Return 4 Return 5 Return 6 Return 7 Return 8 Board 2 Bank A Opto Opto Opto...

  • Page 61: Playfield Switch Map

    S W I T C H L O C AT I O N S Dedicated Switch Locations P L A Y F I E L D S W I T C H M A P Figure 4.1 Playfield Switch Map   3/$<),(/' 6:,7&+ 0$3   ( VFDSH...
  • Page 62 S W I T C H L O C AT I O N S Dedicated Switch Locations 4-42 Houdini Service Manual...

  • Page 63: Coil Locations

    Coil LocationsCh 5 - Coil Locations OCATIONS ........

  • Page 64: Playfield Coil Map

    C O I L L O C AT I O N S Coil Locations P L A Y F I E L D C O I L M A P Figure 5.1 Playfield Coil Map 5-44 Houdini Service Manual...

  • Page 65: Fuses

    C O I L L O C AT I O N S Fuses ............F U S E S Table 5.2 Fuse Table...
  • Page 66 C O I L L O C AT I O N S Fuses 5-46 Houdini Service Manual...

  • Page 67: P-Roc Boards

    Ch 6 - P-ROC Boards P-ROC B OARDS ........Table 6.1 Houdini Board Parts Number table Board...

  • Page 68: Theory Of Operation

    P - R O C B O A R D S Theory of Operation ............T H E O R Y O F O P E R A T I O N The P -ROC consists primarily of an FPGA, supporting logic, and a bunch of...

  • Page 69: P3-Roc Functional Descriptions

    P - R O C B O A R D S Theory of Operation P 3 - R O C F U N C T I O N A L D E S C R I P T I O N S U S B A USB interface is used to connect the P to a host computer.
  • Page 70 P - R O C B O A R D S Theory of Operation • Schedule – Drivers can be configured to turn on at scheduled times and stay on for a specific number of milliseconds before the schedule is disabled. The scheduled times can be one or more points in time spaced approximately 1/32 of a second apart.
  • Page 71 P - R O C B O A R D S Theory of Operation Switch Function Serial Switch Chain 1 Termination S T A T U S There are 2 power LEDs. When behaving normally, they should all illuminate when the board has power.

  • Page 72: J1 Power Connector Table

    P - R O C B O A R D S Theory of Operation C O N N E C T O R S Table 6.5 -ROC J1 Power Connector table Power 4-pin Molex: 0.200” Spacing Ground Ground VCC (5V) Table 6.6 -ROC J2 Power Connector table...

  • Page 73: J4 Burst Switch Table

    P - R O C B O A R D S Theory of Operation Burst Switches 26-pin Header: 0.100” Spacing Ground Burst Switch Input 1 Ground Burst Switch Input 2 Ground Burst Switch Input 3 Burst Switch Burst Switch Input 7 Input 4 3.3V Burst Switch...

  • Page 74: J5 Burst Switch Table

    P - R O C B O A R D S Theory of Operation Burst Switches 26-pin Header: 0.100” Spacing 3.3V Burst Switch Input 37 3.3V Burst Switch Input 38 Table 6.9 -ROC J5 Burst Switch table Burst Switches 26-pin Header: 0.100” Spacing 3.3V Burst Switch Driver 8...

  • Page 75: J6 Burst Switch Table

    P - R O C B O A R D S Theory of Operation Table 6.10 -ROC J6 Burst Switch table Burst Switches 26-pin Header: 0.100” Spacing 3.3V Burst Switch Driver 40 3.3V Burst Switch Driver 41 Burst Switch Burst Switch Driver 46 Driver 42 Ground...

  • Page 76: J8 Burst Switch Table

    P - R O C B O A R D S Theory of Operation Burst Switches 26-pin Header: 0.100” Spacing Ground Burst Switch Driver 19 Ground Burst Switch Driver 20 Ground Burst Switch Driver 21 Burst Switch Burst Switch Driver 23 Input 16 Ground Burst Switch...

  • Page 77: J9 Burst Switch Table

    P - R O C B O A R D S Theory of Operation Burst Switches 26-pin Header: 0.100” Spacing Ground Burst Switch Input 49 Ground Burst Switch Input 50 Ground Burst Switch Input 51 Burst Switch Burst Switch Input 55 Input 52 3.3V Burst Switch...

  • Page 78: J10 Burst Switch Table

    P - R O C B O A R D S Theory of Operation Burst Switches 26-pin Header: 0.100” Spacing 3.3V Burst Switch Input 29 3.3V Burst Switch Input 30 Table 6.14 -ROC J10 Burst Switch table Burst Switches 26-pin Header: 0.100” Spacing 3.3V Burst Switch Driver 56...

  • Page 79: J11 Serial Switches Table

    P - R O C B O A R D S Theory of Operation Table 6.15 -ROC J11 Serial Switches table Serial Switches 0 3-pin Molex: 0.100” Spacing Ground Serial Switch Data + Serial Switch Data - Table 6.16 -ROC J12 Serial Drivers table Serial Drivers 0 3-pin Molex: 0.100”...

  • Page 80: J15 Serial Drivers Table

    P - R O C B O A R D S Theory of Operation Table 6.19 -ROC J15 Serial Drivers table Serial Drivers 1 3-pin Molex: 0.100” Spacing Serial Switch Data + Serial Switch Data - Table 6.20 -ROC J16 JTAG Port table JTAG Port 14-pin Header: 2mm spacing Ground...

  • Page 81: J18 Auxiliary Port Table

    P - R O C B O A R D S Theory of Operation 5-pin Molex: 0.100” Spacing Ground Table 6.22 -ROC J18 Auxiliary Port table Auxiliary Port 20-pin Header: 0.100” Spacing Ground Ground Aux Data 0 Aux Control 0 Aux Data 1 Aux Control 1 Aux Data 2...

  • Page 82: Section 2: Sw-16 Boards

    P - R O C B O A R D S Section 2: SW-16 Boards GPIO 10-pin Molex: 0.100” Spacing GPIO 7 Ground P O W E R There are 2 power connectors for 5V input. Only one should be used at any one time. J1 is pin compatible with a standard personal computer 4-pin power supply cable commonly used to power disk drives.

  • Page 83: Sw-16: J1 Power Connector Table

    P - R O C B O A R D S Section 2: SW-16 Boards Table 6.24 SW-16: J1 Power Connector table Power Required 3-pin Molex: 0.156” Spacing Ground Table 6.25 SW-16: J2 Bank A Switch Inputs table Required Bank A Switch Inputs if using Bank A 10-pin Molex: 0.100”...

  • Page 84: Inputs Table

    P - R O C B O A R D S Section 2: SW-16 Boards Table 6.27 SW-16: J4 Serial Data Out table Serial Data Out Required 3-pin Molex: 0.100” Spacing Ground Serial Data + Serial Data - Table 6.28 SW-16: J6 Bank B Switch Inputs table Required...

  • Page 85: Sw-16 Board Id Table

    P - R O C B O A R D S Section 2: SW-16 Boards Dipswitch Description Address bit 3* Address bit 4* Address bit 5* ID bit 5 *On = 1, Off = 0 B O A R D I D The board ID is a value that can be read by software, and it is configurable via the following dipswitch and resistor placement options.

  • Page 86: Sw-16 Register Device Type Table

    P - R O C B O A R D S Section 2: SW-16 Boards Dipswitch Description Address bit 3* Address bit 4* Address bit 5* ID bit 5 Terminate serial bus *On = 1, Off = 0 R E G I S T E R S Table 6.33 SW-16 Register Device Type table Device Type...

  • Page 87: To Install The Sw-16 Board Hardware

    Using a 2-wire cable, connect J3 to the previous board in the chain. If the boards are separated by more than a few feet, American Pinball recommends a shielded and twisted pair. For short runs, any 2-wire cable should suffice.

  • Page 88: Section 3: P-Roc Pd-16 Driver Boards

    P - R O C B O A R D S Section 3: P-ROC PD-16 Driver Boards • Bank A switch: P -ROC switch # = SW-16 address * 16 + Bank A switch input • Bank B switch: P -ROC switch # = SW-16 address * 16 + 8 + Bank B switch input # •...

  • Page 89: P-Roc Power Driver Connectors

    P - R O C B O A R D S Section 3: P-ROC PD-16 Driver Boards P - R O C P O W E R D R I V E R C O N N E C T O R S Table 6.37 Power Driver 16 J1 Logic Power table...

  • Page 90: Power Driver 16 J3

    P - R O C B O A R D S Section 3: P-ROC PD-16 Driver Boards Table 6.41 Power Driver 16 J3 Bank A High Power Out table Recommended if Bank A High Power Out using Bank A 3-pin Molex: 0.156” Spacing Fused High Power Out Fused High Power Out Table 6.42...

  • Page 91: P-Roc Board Address Configuration

    P - R O C B O A R D S Section 3: P-ROC PD-16 Driver Boards Table 6.44 Power Driver 16 J4 Bank B High Power Out table Bank B High Recommended if Power Out using Bank B 3-pin Molex: 0.156” Spacing Fused High Power Output Fused High Power Output Table 6.45...

  • Page 92: Address Table

    P - R O C B O A R D S Section 3: P-ROC PD-16 Driver Boards Dipswitch Description *On = 1, Off = 0 When the P-ROC board is configured, groups of 8 data bits are assigned to indexes. Bits 3:1 of those indexes should correspond to the desired driver board's address, and bit 0 corresponds to the desired bank (0=Bank A, 1=Bank B).

  • Page 93: Power Driver 16 Leds For Driver Board Table

    P - R O C B O A R D S Section 3: P-ROC PD-16 Driver Boards Table 6.48 Power Driver 16 LEDs for Driver Board table Description 3.3V Fused Bank A power Fused Bank B power Watchdog expired Table 6.49 Power Driver 16 Switches for Driver Board table Switch...

  • Page 94: Watchdog

    P - R O C B O A R D S Section 3: P-ROC PD-16 Driver Boards W A T C H D O G Each board has a watchdog circuit that keeps the FETs deactivated when the board is not receiving commands from the Master. This may happen due to a failure in the P-ROC or in the Master, or it could be due to a wiring issue in the serial chain.
  • Page 95 P - R O C B O A R D S Section 3: P-ROC PD-16 Driver Boards Serial Bus Protocol (PDB Protocol) Field <between bytes> 1-5 IDLE clock cycles Byte 4 {0,0,0,0,Bank data bits[3:0]} PDB Protocol Requirements • Each byte is sent MSB first. •...

  • Page 96: To Install The P-Roc Driver Board Hardware

    Using a 2-wire cable, connect J9 to the previous board in the chain. If the boards are separated by more than a few feet, American Pinball recommends a shielded and twisted pair. For short runs, any 2-wire cable should suffice.

  • Page 97: I Using Bank B To Install The P-Roc Driver Board

    P - R O C B O A R D S Section 4: PD LED-2 Boards I using Bank B to install the P-ROC Driver Board Connect the power source (5V-80V DC) to J6. Use J4 to supply power to the Bank B devices. Connect Bank B devices to J11 so the driver board can complete the path to ground to activate the devices when commanded.

  • Page 98: Pd-Led-2 Programming

    P - R O C B O A R D S Section 4: PD LED-2 Boards the PD-LED-2 to drive LED serial chains, the serial chains must be powered externally. The PD-LED-2 should not be used to supply power to the chain(s). The PD-LED-2 can be programmed to set the intensity level of an LED to one of 256 levels.

  • Page 99: To Fade An Led's Color

    P - R O C B O A R D S Section 4: PD LED-2 Boards Write the upper 8 bits of the LED's index number to the Address direct register [15:8]. Write the desired intensity level to the Color direct register. To fade an LED’s color Write the lower 8 bits of the fade rate to the Fade Rate [7:0] direct register.

  • Page 100: To Configure The Serial Chain Manager

    P - R O C B O A R D S Section 4: PD LED-2 Boards Indirect registers used to configure the Serial Chain Manager include: Serial String A Start Sub-Manager A’s first LED Serial String A End Sub-Manager A’s last LED Serial String B Start Sub-Manager B’s first LED WS281X Low Bit Time...

  • Page 101: Pd-Led-2 J2 Serial Data In Table

    P - R O C B O A R D S Section 4: PD LED-2 Boards Logic Power Required 2-pin Molex: 0.156” Spacing Ground Table 6.52 PD-LED-2 J2 Serial Data In table Serial Data In Required 3-pin Molex: 0.100” Spacing Serial+ Serial- Ground...

  • Page 102: Pd-Led-2 J9 Led Drivers Table

    P - R O C B O A R D S Section 4: PD LED-2 Boards LED Drivers 20-pin Header: 0.100” Spacing LED 11 Ground Table 6.55 PD-LED-2 J9 LED Drivers table LED Drivers 20-pin Header: 0.100” Spacing 3.3V LED 12 LED 13 LED 14 Ground...

  • Page 103: Pd-Led-2 J10 Led Drivers Table

    P - R O C B O A R D S Section 4: PD LED-2 Boards Table 6.57 PD-LED-2 J10 LED Drivers table LED Drivers 20-pin Header: 0.100” Spacing 3.3V LED 36 LED 37 LED 38 Ground 3.3V LED 39 LED 40 LED 41 Ground...

  • Page 104: Pd-Led-2 J8 Led Drivers Table

    P - R O C B O A R D S Section 4: PD LED-2 Boards LED Drivers 20-pin Header: 0.100” Spacing LED 63 LED 62 Ground 3.3V LED 63 LED 64 LED 65 Ground 3.3V LED 66 LED 67 LED 68 Ground 3.3V...

  • Page 105: Pd-Led-2 Status Leds Table

    P - R O C B O A R D S Section 4: PD LED-2 Boards S T A T U S L E D S Table 6.61 PD-LED-2 Status LEDs table Description 3.3V 5.0V Watchdog expired Ready D I P S W I T C H E S Table 6.62 PD-LED-2 Dipswitches table Dipswitch...

  • Page 106: Pd-Led-2 Serial Bus Direct Registers Table

    P - R O C B O A R D S Section 4: PD LED-2 Boards Dipswitch Description Address bit 3* Address bit 4* *On = 1, Off = 0 D I R E C T R E G I S T E R S Table 6.64 PD-LED-2 Serial Bus Direct Registers table Serial Bus Register Address...

  • Page 107: Pdb Protocol

    P - R O C B O A R D S Section 4: PD LED-2 Boards Direct Data Register Direct Address Register WS281x Reset Bit Time WS281x[0] First Address WS281x[0] Last Address WS281x[1] First Address WS281x[1] Last Address WS281x[2] First Address WS281x[2] Last Address 15:14 RESERVED...

  • Page 108: To Install The P-Roc Led Board Hardware

    Using a 2-wire cable, connect J2 to the previous board in the chain. If the boards are separated by more than a few feet, American Pinball recommends a shielded and twisted pair. For short runs, any 2-wire cable should suffice.

  • Page 109: Section 5: Board Drawings And Parts

    P - R O C B O A R D S Section 5: Board Drawings and Parts ............S E C T I O N 5 : B O A R D D R A W I N G S A N D P A R T S Figure 6.4 PCB005 Servo Board Drawing...

  • Page 110: Pcb005 Schematic

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.5 PCB005 Schematic Table 6.68 Board Parts for PCB005 Additional Quantity Part Description Part Number Info Solder Jumper Solder Reflow No Paste Capacitor MLCC - 0805 16volts 10 µF Header, 2-Pin, Dual row...

  • Page 111: Pcb009 All Layers

    P - R O C B O A R D S Section 5: Board Drawings and Parts Additional Quantity Part Description Part Number Info 3x4 Conn Pins .100, 12 Pin 103817-2 3x4 Connector Header 4 pin, Dual Row 39299042 Header 4X2 Red Colored Figure 6.6 PCB009 All Layers...

  • Page 112: Pcb009 Top View

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.8 PCB009 Top View Figure 6.9 PCB009 Schematic Table 6.69 Board Parts for PCB009 Additional Quantity Part Description Part Number Info IN-T3A8FCH RGB LED IN-T3A8FCH Header, 5-Pin 22232051...

  • Page 113: Pcb0010 All Layers

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.10 PCB0010 All Layers Figure 6.11 PCB0010 Bottom View Figure 6.12 PCB0010 Top View 6-93 Houdini Service Manual...

  • Page 114: Board Parts For Pcb010

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.13 PCB010 Schematic Table 6.70 Board Parts for PCB010 Additional Quantity Part Description Part Number Info IN-T3A8FCH RGB LED IN-T3A8FCH Header, 5-Pin 22232051 Header 5 Resistor...

  • Page 115: Pcb0011 Bottom View

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.15 PCB0011 Bottom View Figure 6.16 PCB0011 Top View Figure 6.17 PCB011 Schematic 6-95 Houdini Service Manual...

  • Page 116: Board Parts For Pcb011

    P - R O C B O A R D S Section 5: Board Drawings and Parts Table 6.71 Board Parts for PCB011 Additional Quantity Part Description Part Number Info IN-T3A8FCH RGB LED IN-T3A8FCH Header, 10-Pin, Dual Row 67997-410HLF Header 10X2 Header, 5-Pin 22232051 Header 5...

  • Page 117: Pcb012 Bottom View

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.19 PCB012 Bottom View 6-97 Houdini Service Manual...

  • Page 118: Pcb012 Top View

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.20 PCB012 Top View 6-98 Houdini Service Manual...

  • Page 119: Board Parts For Pcb012

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.21 PCB012 Schematic Table 6.72 Board Parts for PCB012 Additional Quantity Part Description Part Number Info IN-T3A8FCH RGB LED IN-T3A8FCH Header, 10-Pin, Dual Row 67997-410HLF Header 10X2 Header, 5-Pin...

  • Page 120: Board Parts For Pcb013

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.23 PCB0013 Bottom View Figure 6.24 PCB0013 Top View Figure 6.25 PCB013 Schematic Table 6.73 Board Parts for PCB013 Additional Quantity Part Description Part Number Info IN-T3A8FCH RGB LED...

  • Page 121: Pcb014 Top View

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.26 PCB014 All Layers Figure 6.27 PCB014 Bottom View Figure 6.28 PCB014 Top View 6-101 Houdini Service Manual...

  • Page 122: Board Parts For Pcb014

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.29 PCB014 Schematic Table 6.74 Board Parts for PCB014 Additional Quantity Part Description Part Number Info IN-T3A8FCH RGB LED IN-T3A8FCH Header, 10-Pin, Dual Row 67997-410HLF Header 10X2 Header, 5-Pin...

  • Page 123: Pcb015 All Layers

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.30 PCB015 All Layers 6-103 Houdini Service Manual...

  • Page 124: Pcb015 Bottom View

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.31 PCB015 Bottom View 6-104 Houdini Service Manual...

  • Page 125: Pcb015 Top View

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.32 PCB015 Top View 6-105 Houdini Service Manual...

  • Page 126: Pcb015 Schematic

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.33 PCB015 Schematic Figure 6.34 PCB016 All Layers 6-106 Houdini Service Manual...

  • Page 127: Pcb016 Top View

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.35 PCB016 Bottom View Figure 6.36 PCB016 Top View 6-107 Houdini Service Manual...

  • Page 128: Board Parts For Pcb016

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.37 PCB016 Schematic Table 6.75 Board Parts for PCB016 Additional Quantity Part Description Part Number Info IN-T3A8FCH RGB LED IN-T3A8FCH Header, 10-Pin, Dual Row 67997-410HLF Header 10X2 Header, 5-Pin...

  • Page 129: Pcb0019 Rev 00 Ball Trough Receiver Drawing

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.38 PCB0019 Rev 00 Ball Trough Receiver Drawing Figure 6.39 PCB0019 Rev 00 Ball Trough Receiver Drawing v2 6-109 Houdini Service Manual...

  • Page 130: Pcb0019 Rev 00 Schematic

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.40 PCB0019 Rev 00 Schematic Table 6.76 Board Parts for PCB0019 Rev 00 Additional Quantity Part Description Part Number Info Header, 12-Pin, 2.54mm 22057128 Header 1X2 Resistor 0.5 W 22KOhm...

  • Page 131: Pcb019-01 Rev 00 Ball Trough Transmitter Drawing

    P - R O C B O A R D S Section 5: Board Drawings and Parts Additional Quantity Part Description Part Number Info Diff Comparator IC LM339N IC, axial 14 DIP Phototransistor IR 880NM 5MM QSD124A4R0 Infrared sensor Red LED 5V SSL-LX3044ID-5V Standard LEDs - Resistor - Do not connect...

  • Page 132: Pcb019-01 Rev 00 Schematic

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.43 PCB019-01 Rev 00 Schematic Table 6.77 Board Parts for PCB019-01 Rev 00 Additional Quantity Part Description Part Number Info Header, 5-Pin, Right Angle Tin 22057058 Header 5 pos 2.54mm...

  • Page 133: Pcb0020 Rev 01 Opto Interface Board V1

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.44 PCB0020 Rev 01 Opto Interface Board v1 Figure 6.45 PCB0020 Rev 01 Opto Interface Board v2 6-113 Houdini Service Manual...

  • Page 134: Pcb0020 Rev 01 Schematic

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.46 PCB0020 Rev 01 Schematic Table 6.78 Board Parts for PCB0020 Rev 01 Additional Quantity Part Description Part Number Info Header, 2-Pin, Dual row 39281023 Header 1X2 Header 4 pin, Dual row...

  • Page 135: Pcb0021 Add On Driver Board V1

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.47 PCB0021 Add On Driver Board v1 Figure 6.48 PCB0021 Add On Driver Board v2 6-115 Houdini Service Manual...

  • Page 136: Board Parts Number For Pcb0021

    P - R O C B O A R D S Section 5: Board Drawings and Parts Figure 6.49 PCB0021 Schematic Table 6.79 Board Parts Number for PCB0021 Additional Quantity Part Description Part Number Info Diode DO-214AA/SMB S1GB-13 Standard Diode Vr=400V Connector 4 Pos 0.100 vert 22232041...

  • Page 137: Pcb0022 Layout

    P - R O C B O A R D S Section 5: Board Drawings and Parts Additional Quantity Part Description Part Number Info Blue LED 0805 LTST-C170TBKT Blue 470nm LED Indication FUSE HLDR CARTRIDGE 5*20 4628 Fuse Bracket Header Cuttalbe 0.100 (2.54) M20-9990345 .100 Male Pins 26 POS...

  • Page 138: Board Parts Number For Pcb0022

    P - R O C B O A R D S Section 5: Board Drawings and Parts Table 6.80 Board Parts Number for PCB0022 Additional Quantity Part Description Part Number Info KK .156 Header 3 Pos 0009652038 Connector KK series Cap Alum 33000UF 20% 25V LLS1E333MELC Capacitor 25V...

  • Page 139: Assemblies, Posts & Ring Locations

    Assemblies, Posts & Ring LocationsCh 7 - Assemblies, Posts & Ring Locations & R SSEMBLIES OSTS OCATIONS ........

  • Page 140: Ball Lock Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies 3 B A L L L O C K A S S E M B L Y Figure 7.1 3 Ball Lock Assembly Drawing Figure 7.2...

  • Page 141: Ball Under Trough Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Item No. Quantity Part Description Part Number 2-56 Nut Plate MTL0068-00 3-Ball Switch Spacer PLS0001-31...

  • Page 142: Parts For 3 Ball Under Trough Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Table 7.2 Parts for 3 Ball Under Trough Assembly Item No. Quantity Part Description Part Number...

  • Page 143: Ball Under Trough Assembly Drawing

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies 6 B A L L U N D E R T R O U G H A S S E M B L Y Figure 7.5 6 Ball Under Trough Assembly Drawing Table 7.3...
  • Page 144 A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Item No. Quantity Part Description Part Number Trough Bumper Plug RBR0014-00 Ball Trough Receiver Board PCB-0019-00...

  • Page 145: Adj Down Post

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies A D J D O W N P O S T Figure 7.6 Adj Down Post Assembly Figure 7.7...

  • Page 146: Parts For Adj Down Post Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Table 7.4 Parts for Adj Down Post Assembly Item No. Quantity Part Description Part Number...

  • Page 147: Adj Down Post 2

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies A D J D O W N P O S T 2 Figure 7.8 Adj Down Post 2 Assembly Figure 7.9...

  • Page 148: Parts For Adj Down Post 2 Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Table 7.5 Parts for Adj Down Post 2 Assembly Item No. Quantity Part Description Part Number...

  • Page 149: Adj Up Post

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies A D J U P P O S T Figure 7.10 Adj Up Post Assembly Figure 7.11 Adj Up Post Assembly Drawing Table 7.6 Parts for Adj Up Post Assembly...

  • Page 150: Back Box Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies B A C K B O X A S S E M B L Y Figure 7.12 Back Box Assembly - Detailed 7-130 Houdini Service Manual...

  • Page 151: Back Box Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Figure 7.13 Back Box Assembly Table 7.7 Parts for Back Box Assembly Item No.
  • Page 152 A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Item No. Quantity Part Description Part Number Speaker - 2” Tweeter ELE0003-00 Vent Grill Universal MTL0094-00...

  • Page 153: Back Panel Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Item No. Quantity Part Description Part Number Ground Braid WIR0005-00 #6 x 1/2"...

  • Page 154: Catapult Assembly - Detailed

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Item No. Quantity Part Description Part Number LED Strip Bracket MTL0036-00 #8 1/2”...

  • Page 155: Catapult Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Figure 7.16 Catapult Assembly Table 7.9 Parts for Catapult Assembly Item No.

  • Page 156: Left Flipper Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Item No. Quantity Part Description Part Number 8-32 X 1/4" SEMS MS Zinc MAS1008-04 5/16 E Ring SPC0003-10...

  • Page 157: Parts For Left Flipper Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Figure 7.18 Left Flipper Assembly - Detailed Table 7.10 Parts for Left Flipper Assembly Item No.

  • Page 158: Left Flipper Crank Link Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Item No. Quantity Part Description Part Number Coil Tubing PLS0047-00 #10 Split Lock Washer 91102A740 10/32 X 3/8 SH CS...

  • Page 159: Line Filter Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Table 7.11 Parts for Left Flipper Crank Link Assembly Item No. Quantity Part Description Part Number...

  • Page 160: Ramp Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Table 7.12 Parts for Line Filter Assembly Item No. Quantity Part Description Part Number Line Filter MTG Plate...

  • Page 161: Ramp Sign Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies R A M P S I G N A S S E M B L Y Figure 7.22 Ramp Sign Assembly Table 7.14 Parts for Ramp Sign Assembly...

  • Page 162: Right Flipper Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Item No. Quantity Part Description Part Number Spotlight Flasher LED Bulb LIT0004-00 Plastic Spacer PLS0001-30...

  • Page 163: Parts For Right Flipper Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Table 7.15 Parts for Right Flipper Assembly Item No. Quantity Part Description Part Number Right Flipper Bracket...

  • Page 164: Right Flipper Assembly Detailed

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Figure 7.24 Right Flipper Assembly Detailed Table 7.16 Parts for Right Flipper Assembly Detailed Item No.

  • Page 165: Spotlight (Left Flipper) Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Item No. Quantity Part Description Part Number #10 Flat Washer 91251A346 5/32 X 7/16"...

  • Page 166: Spotlight (Right Flipper) Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Item No. Quantity Part Description Part Number 6-32 X 3/16 PPH MS Zinc MAS0006-03 2 PIN Molex Mini Fit JR Connector - Plug WIR0006-02P...

  • Page 167: Stage Mech Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Item No. Quantity Part Description Part Number 6-32 X 3/16 PPH MS Zinc MAS0006-03 2 PIN Molex Mini Fit JR Connector - Plug WIR0006-02P...
  • Page 168 A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Item No. Quantity Part Description Part Number Houdini Stage Monitor Assy ASM0025-00 8-32 x 3/8"...

  • Page 169: Stage Mech Breakdown Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies S T A G E M E C H B R E A K D O W N A S S E M B L Y Figure 7.27 Stage Mech Assembly Table 7.20 Parts for Stage Mech Breakdown Assembly...
  • Page 170 A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Item No. Quantity Part Description Part Number Stage Backdrop MTL0055-00B Optek Phototransistor SWI0007-01 Stage Opto Hold Down...

  • Page 171: Stage Monitor Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies S T A G E M O N I T O R A S S E M B L Y Figure 7.28 Stage Monitor Assembly Table 7.21 Parts for Stage Monitor Assembly...

  • Page 172: Steamer Trunk Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Item No. Quantity Part Description Part Number 4-40 x 3/16 PPH MS Zinc MAS0004-03 HH Marquee Front PLS0040-00...

  • Page 173: Parts For Steamer Trunk Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Table 7.22 Parts for Steamer Trunk Assembly Item No. Quantity Part Description Part Number Steamer Trunk Bottom...

  • Page 174: Steamer Trunk Diverter Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies S T E A M E R T R U N K D I V E R T E R A S S E M B L Y Figure 7.30 Steamer Trunk Diverter Assembly Table 7.23 Parts for Steamer Trunk Diverter Assembly...

  • Page 175: Subway Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Item No. Quantity Part Description Part Number 10/32 X 3/8" PPH MS MAS0010-06 #8 X 1/2"...

  • Page 176: Super Vuk Scoop Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Table 7.24 Parts for Subway Assembly Item No. Quantity Part Description Part Number HH Under Trough PLS0003-00E...

  • Page 177: Parts For Super Vuk Scoop Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Table 7.25 Parts for Super VUK Scoop Assembly Item No. Quantity Part Description Part Number...

  • Page 178: Trunk Switch Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies T R U N K S W I T C H A S S E M B L Y Figure 7.33 Trunk Switch Assembly Table 7.26 Parts for Trunk Switch Assembly...

  • Page 179: Trunk Up Post Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies T R U N K U P P O S T A S S E M B L Y Figure 7.34 Trunk Up Post Assembly Table 7.27 Parts for Trunk Up Post Assembly...

  • Page 180: Vuk Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Item No. Quantity Part Description Part Number 8-32 X 1/4” SEMS MS Zinc MAS1008-04 23-800 Lugless Coil C0I0001-01...

  • Page 181: Parts For Vuk Assembly

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Assemblies Table 7.28 Parts for VUK Assembly Item No. Quantity Part Description Part Number VUK Assembly- Left Side Mount MTL0088-00...

  • Page 182: Post And Ring Locations

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Post and Ring Locations ............P O S T A N D R I N G L O C A T I O N S 7-162 Houdini Service Manual...

  • Page 183: Post Locations

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Post and Ring Locations Figure 7.36 Post Locations 7-163 Houdini Service Manual...

  • Page 184: Rubber Ring Locations

    A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Post and Ring Locations Figure 7.37 Rubber Ring Locations 7-164 Houdini Service Manual...
  • Page 185 A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Post and Ring Locations 7-165 Houdini Service Manual...
  • Page 186 A S S E M B L I E S , P O S T S & R I N G L O C AT I O N S Post and Ring Locations 7-166 Houdini Service Manual...

  • Page 187: Houdini Game Rules

    Ch Houdini Game Rules - Houdini Game Rules OUDINI ULES ........

  • Page 188: Basic Stage Modes

    H O U D I N I G A M E R U L E S Houdini Game Rules Overview B A S I C S T A G E M O D E S Table 8.1 Basic Stage Modes Chinese Water Torture Hit the key lane to lower Houdini into the tank.

  • Page 189: Movie Modes

    H O U D I N I G A M E R U L E S Houdini Game Rules Overview Table 8.2 Special Stage Modes Bullet Catch Shoot the trunk to lock a ball in the upper catapult, then shoot moving the target to lock in the site (and jackpot value, which is decreasing while trying to hit the moving shot).

  • Page 190: Jail Escape Hurry-Ups

    H O U D I N I G A M E R U L E S Houdini Game Rules Overview J A I L E S C A P E H U R R Y - U P S Spell E-S-C-A-P-E from stand-up target hits. Complete all five Jail Escape Hurry-Ups to earn a Houdini letter, complete X to earn Return From Beyond.

  • Page 191: Seance Multiball

    H O U D I N I G A M E R U L E S Houdini Game Rules Overview S E A N C E M U L T I B A L L Spell S-E-A-N-C-E to light at the scoop and score jackpots. Spell in order to earn Super Jackpot.

  • Page 192: Milkcan Multipliers

    H O U D I N I G A M E R U L E S Houdini Game Rules Overview Figure 8.4 Outlane Drain Modes The player can also earn/light the Outlane Drain Modes at Magic Shop. If earned there, the ability to select the mode moves from side-to-side with the flippers. If earned via SEANCE or ESCAPE, the option is static.

  • Page 193: Master Magician (Wizard) Mode

    H O U D I N I G A M E R U L E S Houdini Game Rules Overview M A S T E R M A G I C I A N ( W I Z A R D ) M O D E You must collect all HOUDINI letters •...
  • Page 194 H O U D I N I G A M E R U L E S Houdini Game Rules Overview 8-174 Houdini Service Manual...

  • Page 195: Houdini Code Update

    There are two types of updates: code updates and full system updates. Full system updates are not currently necessary. If in the future a full system Note: update is required, an American Pinball support member will provide detailed instructions. Please have the following items available before performing a code update: •...

  • Page 196: To Download Houdini Code To A Microsoft Windows Pc

    H O U D I N I C O D E U P D AT E Code Update Procedure To download Houdini Code to a Microsoft Windows PC Go to www.american-pinball.com/support/updates/. Compare the game version on your machine to the most current version available on the site.

  • Page 197: Houdini Code Update Message

    H O U D I N I C O D E U P D AT E Code Update Procedure Figure 9.1 Houdini Code Update Message Times may vary, but expect the code update to take approximately 5 minutes. Figure 9.2 Houdini Code Update Complete When the code update process completes an “Update Complete!”...
  • Page 198 H O U D I N I C O D E U P D AT E Code Update Procedure After upgrading Houdini code, the USB device will contain audits and settings Note: information. In the case of a full system update, these files are used to restore settings and audit history.

  • Page 199: Houdini Log Copy

    H O U D I N I C O D E U P D AT E Code Update Procedure H O U D I N I L O G C O P Y To assist in game development and troubleshooting, American Pinball may ask for a copy of the game logs. To copy game logs Open the coin door and locate the provided USB extension cable.
  • Page 200 H O U D I N I C O D E U P D AT E Code Update Procedure 9-180 Houdini Service Manual...

  • Page 201: Miscellaneous Diagrams

    Ch Miscellaneous Diagrams - Miscellaneous Diagrams ISCELLANEOUS IAGRAMS ........
  • Page 202 M I S C E L L A N E O U S D I A G R A M S About This Chapter Figure 10.1 Cabinet Diagram 10-2 Houdini Service Manual...
  • Page 203 M I S C E L L A N E O U S D I A G R A M S About This Chapter Figure 10.2 Power Block Diagram Figure 10.3 Transformer Diagram 10-3 Houdini Service Manual...
  • Page 204 M I S C E L L A N E O U S D I A G R A M S About This Chapter Figure 10.4 Transformer Wiring Diagram 10-4 Houdini Service Manual...
  • Page 205 M I S C E L L A N E O U S D I A G R A M S About This Chapter Figure 10.5 Dipswitch Settings Diagram Please refer to the Fuse table in the Coil Locations chapter for a list of fuses Note: used in Houdini.
  • Page 206 M I S C E L L A N E O U S D I A G R A M S About This Chapter 10-6 Houdini Service Manual...
  • Page 207 ............D O C U M E N T F E E D B A C K To submit feedback, comments, changes, or additional information related to this document, please contact your American Pinball distributor.
  • Page 208 Part Number DOC0001-00 TFYWF7G For Support Call: 833-API-HELP...

Table of Contents
