Page 1: Washing Machine
Washing Machine User manual WA6*M4****/WA7*M4**** WA4000MK-03843A-00_EN.indd 1 4/13/2017 11:02:04 AM... -
Page 2: Table Of Contents
Contents Safety information What you need to know about the safety instructions Important safety symbols Important safety precautions Instructions about the WEEE Installation What’s included Installation requirements Step-by-step installation Before you start The basics Laundry guidelines Operations Control panel Simple steps to start Auto cycles Manual cycles Special features... -
Page 3: Safety Information
Safety information Congratulations on your new Samsung washing machine. This manual contains important information on the installation, use and care of your appliance. Please take some time to read this manual to take full advantage of your washing machine’s many benefits and features. -
Page 4: Important Safety Precautions
Safety information These warning signs are here to prevent injury to yourself and others. Please follow them explicitly. After reading this manual, store it in a safe place for future reference. Read all instructions before using the appliance. As with any equipment that uses electricity and moving parts, potential hazards exist. To safely operate this appliance, familiarize yourself with its operation and exercise care when using it. - Page 5 5. The new hose-sets supplied with the appliance are to be used and that old hose-sets should not be reused. 6. For washing machines having ventilation openings in the base, the installation instructions shall state that the openings must not be obstructed by a carpet.
- Page 6 Safety information Remove all foreign substances such as dust or water from the power plug terminals and contact points using a dry cloth on a regular basis. • Unplug the power plug and clean it with a dry cloth. • Failure to do so may result in electric shock or fire.
- Page 7 • In this case, the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from doing it. Unplug the power plug when the appliance is not being used for long periods of time or during a thunder or lightning storm.
- Page 8 Using the product for business purposes qualifies as a product misuse. In this case, the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse.
-
Page 9: Instructions About The Weee
This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For more information on safe disposal and recycling, visit our website www.samsung.com or contact our Helpline numbers on the last page. English 9 WA4000MK-03843A-00_EN.indd 9... -
Page 10: Installation
What’s included Make sure all the parts are included in the product package. If you have missing or defective parts, contact a local Samsung customer centre or the retailer. 10 English WA4000MK-03843A-00_EN.indd 10 4/13/2017 11:02:05 AM... - Page 11 01 Door 02 Built-in sink * 03 Filter 04 Tub 05 Water Jet * 06 Adjustable legs 07 Water hose (Cold) 08 Water hose (Hot) * 09 Control panel 10 Detergent box 11 Wing distributor 12 Power cord (Optional) * 13 Handle (Set Moving) * 14 Ground lead * 15 Drain hose...
-
Page 12: Installation Requirements
Installation Installation requirements Electrical supply and grounding Drain • Make sure the drain hose is not clogged. WARNING • We recommend a standpipe in height • AC 220-240 V / 50Hz fuse or circuit of 90-100 cm. The drain hose must be breaker is required. -
Page 13: Step-By-Step Installation
Step-by-step installation STEP 1 Select a location Location requirements: Solid, level surface without carpeting or flooring that may obstruct ventilation • Away from direct sunlight • • Adequate room for ventilation and wiring • The ambient temperature is always higher than the freezing point (0 ˚C) •... - Page 14 Installation STEP 2 Adjust the levelling feet Unpack the product package. 1. Gently slide the washing machine into position. Excessive force may damage the levelling feet (A). 2. Level the washing machine by manually adjusting the levelling feet. 3. When levelling is complete, tighten the nuts (B) if provided (some models may not have the nuts).
- Page 15 2. Use a Philips screwdriver to loosen four screws on the adaptor. 3. Hold the adaptor and turn part (C) in the arrow direction to loosen it by 5 mm (*). 4. Insert the adaptor into the water tap, and tighten the screws while lifting up the adaptor.
- Page 16 WARNING Stop using the washing machine if there is a water leak, and contact a local Samsung service centre. Otherwise, this may cause electric shock. CAUTION Do not stretch the water hose by force. If the hose is too short, replace the hose with a longer, high-pressure hose.
- Page 17 NOTE • After connecting the water hose to the adaptor, check if it is connected properly by pulling the water hose downwards. • Use a standard type of water tap. If the tap is square-shaped or too big, remove the spacer ring before inserting the tap into the adaptor.
- Page 18 Installation Pump type 1. Open the hose cap (A), and insert the drain hose. Tighten the drain hose using the joint ring. NOTE • The position (side or rear) of the drain outlet depends on the model. • Availability of the hose cap depends on the model.
- Page 19 CAUTION • Do not exceed 3 m (*) for the total length of extended hoses. • Do not let the drain hose run over doorsills that protrude 5 cm (**) or more from the floor. • Do not run the drain hose under the bottom of the machine.
-
Page 20: Before You Start
Before you start The basics Prewash (Water Jet & Built-in sink) CAUTION Do not abuse Water Jet. Excessive use of Water Jet increases water consumption. • • When running water to the tub, do that gently. Otherwise, water may overflow the tub. Water Jet and Built-in sink help you hand- wash before the washing machine starts operation. - Page 21 Detergent Box To add a laundry-specific detergent, follow these steps: 1. Open the door then the Built-in sink to reveal the tub. 2. Open the detergent box by pulling in the direction of the arrow as shown in the figure and then put the detergent in the detergent box.
-
Page 22: Laundry Guidelines
Before you start Laundry guidelines Checkpoints • Check for stains or dirt. Apply a little detergent to a white towel. Rub the white towel and the dirty clothes together to transfer the dirt or colour to the white towel. Before washing, pre-treat the sleeves, collars, dress hems, and pockets by brushing with •... - Page 23 STEP 1 Sort Sort the laundry according to these criteria: • Care Label: Sort the laundry into cottons, mixed fibres, synthetics, silks, wools, and rayon. • Colour: Separate whites from colours. • Size: Mixing different-sized items together in the tub improves the washing performance. •...
- Page 24 Before you start CAUTION For inflatable items such as blankets, microfibre quilts, and waterproof materials, use the laundry net to fully soak the laundry in water. • Inflatable items may cause damage to the laundry or the machine during the wash or drying process.
- Page 25 STEP 5 Determine the load capacity Do not overload the washing machine. Overloading may cause the washing machine to not wash properly. NOTE When washing bedding or bedding covers, the wash time may be lengthened or the spin efficiency may be reduced. For bedding or bedding covers, the recommended load capacity is 3.5 kg or less.
-
Page 26: Operations
Operations Control panel Displays the remaining time of a cycle, or the information code when an issue to check occurs. Child Lock Child Lock is designed to prevent accidents by infants or children such as drowning in the tub, and remains active after the machine restarts. 01 Display To cancel the Child Lock, you must deactivate it first. - Page 27 Active Wash+ is available only in the Standby state, and offers 2 options: Water Save (default) and Drain. Water Save Select this to reduce water consumption. Drain 03 Activ Wash+ Drains the water used in the prewash. During this process, no other cycle is enabled.
-
Page 28: Simple Steps To Start
Operations Simple steps to start 1. Press Power to turn on the washing machine. 2. Select a cycle in the cycle panel. 3. Change the cycle settings (wash time, rinse count, and/or spinning time) as necessary. 4. To add an option such as Water Level, Activ Wash+, and Monsoon, press the corresponding button. -
Page 29: Auto Cycles
Auto cycles Cycle Description • Select this for most fabrics including cottons, linens, and Fuzzy normally soiled items. • Select this for less soiled clothes, such as towels, in reduced Quick time. • With this selected, the washing machine adds a soaking Soak process in advance of the main cycle. -
Page 30: Manual Cycles
Operations Manual cycles You might want to use a single cycle to wash less soiled clothes. For example, you can run the wash cycle once for nightwear. 1. Press Power to turn on the washing machine. 2. Press Wash/Rinse/Power Spin to run the individual cycle to your needs. The duration or count of each cycle can be adjusted by pressing the applicable button as many times as needed. -
Page 31: Special Features
Special features Child Lock Child Lock is designed to prevent accidents by children or infants, such as drowning in the tub. To activate the Child Lock With the Child Lock enabled Press and hold Rinse and Power Spin / • You can still manipulate on the control Spin simultaneously for 3 seconds. -
Page 32: Maintenance
Maintenance Cleaning Keep the washing machine clean to prevent deteriorated performance and to preserve its life cycle. Eco Tub Clean reminder • indicator reminds you of cleaning the tub when necessary. If you happen to see the indicator blinking after washing is complete, remove the laundry and run the Eco Tub Clean cycle. - Page 33 4. Clean the Magic filter. 5. Close the cover and insert the lower part of the filter in the basket first and then push the filter with “click” sound. English 33 WA4000MK-03843A-00_EN.indd 33 4/13/2017 11:02:11 AM...
- Page 34 Maintenance Pump filter (applicable models only) 1. Put a floor-cloth or towel under the Pump filter. Turn the filter knob anticlockwise to remove. 2. Clean the filter with running water and a soft brush. 3. Reinsert the filter, and turn clockwise until it locks into position.
- Page 35 Mesh filter 1. Use pliers to pull out the mesh filter from inside the water inlet as shown. 2. Use a soft brush to clean the filter with running water. 3. Reinsert the filter. Make sure it is tightened against water leaks. English 35 WA4000MK-03843A-00_EN.indd 35 4/13/2017 11:02:11 AM...
- Page 36 Maintenance Detergent Box 1. Open the door and then the Built-in sink to reveal the detergent box. 2. Open the detergent box by pulling in the front direction and then remove the wing distributors from the detergent box. 3. Clean the detergent box as well as the wing distributors with running water and a soft brush.
-
Page 37: Troubleshooting
Troubleshooting Checkpoints If you encounter an issue to check with the washing machine, first check the table below and try the suggestions. Symptom Action Make sure you use rated power for the product. • Does not turn on. • Make sure the power cord is completely plugged in. •... - Page 38 Troubleshooting Symptom Action • Make sure the washing machine is set on a level floor. If the floor is not level, use the levelling feet to adjust the washing machine. • Make sure the washing machine is not contacting any other object.
- Page 39 Symptom Action • Fully open both water taps. • Make sure the temperature selection is correct. • Make sure the hoses are connected to the correct water taps. Flush water lines. • Disconnect the hoses and clean the screens. The hose filter screens may be clogged.
- Page 40 Excessive suds collect in recesses and can cause foul odours. Has odours. • Run cleansing cycles to sanitize periodically. Dry the washing machine interior after a cycle has finished. • a symptom continues to happen, contact a local Samsung service centre. 40 English WA4000MK-03843A-00_EN.indd 40 4/13/2017 11:02:12 AM...
-
Page 41: Information Codes
• Check if the drain hose is clogged by any foreign substances. • If the error remains, call the customer care. If any information code keeps appearing on the screen, contact a local Samsung service centre. English 41 WA4000MK-03843A-00_EN.indd 41... -
Page 42: Specifications
Specifications Specification sheet Top loading washing machine Type WA75M4**** WA70M4**** Max load (kg) Washing Washing Power consumption (W) Spin Dimensions (mm) W540 x D568 x H1002 Net weight (kg) 31.0 Water pressure (Mpa (kg·f/cm 0.05 - 0.78 (0.5 - 8.0) Washing type Stirring type Water level (L) - Page 43 Top loading washing machine Type WA65M4**** WA62M4**** Max load (kg) Washing Washing Power consumption (W) Spin Dimensions (mm) W540 x D568 x H982 Net weight (kg) 31.0 Water pressure (Mpa (kg·f/cm 0.05 - 0.78 (0.5 - 8.0) Washing type Stirring type Water level (L) Water usage (L) Spin speed (rpm)
- Page 44 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT 1800 40 SAMSUNG INDIA www.samsung.com/in/support (1800 40 7267864) (Toll-Free) This product is RoHS compliant. DC68-03843A-00 WA4000MK-03843A-00_EN.indd 44 4/13/2017 11:02:12 AM...
