DT301/ DT311 Battery Charger Kit
BASIC OPERATION GUIDE
Thank you for purchasing the DT301/ DT311 Battery Charger Kit by DT Research.
This device enables charging of one DT Mobile Tablet (DT301/ DT311) battery pack.
Please follow this guide for operational instructions.

Instructions:

The charger is designed to charge one DT301/ DT311 battery pack. To connect the
battery pack to the charger:
• Place the charger pack with LED-light facing up.
• Place the battery with top facing up (top is the side that is viewable when on
the DT301/ DT311 tablet).
• Align the battery pin connector facing the charger opening. Please see images.
ACC-001-311 for charging the 45W battery pack
ACC-001-34 for charging the 60W or 90W battery pack
Slowly insert the battery pack into the charger,
making sure the battery pin connector lines
up with the charger pins. Push the battery
pack all the way into the charger, the LED light
on the charger should come on.
CAUTION: This charger must only be used with the specific battery models for which it is
designed. Failure to do so may result in battery or charger damage, or personal injury.
