Numatics G2-2 series Quick Start Manual

Getting Started

This is a brief document designed to quickly get you started setting up your valve manifold with an integrated
Numatics' G2-2 Series Modbus/TCP communication node.
1) Initial Unpacking and Inspection
1) Examine exterior of package for signs of damage. Report any damage to shipping carrier.
2) Remove wrapped manifold assembly from box.
a) Remove manifold assembly from anti-static packaging
b) Retain documentation for installation and configuration
3) Examine manifold assembly for any shipping damage such as:
a) Bent pins or connectors
b) Report any damage to shipping carrier immediately
4) Examine manifold assembly for proper ordered configuration. (Valves, I/O, Protocol, etc.)
2) G2-2 Introduction
Below is an example of a 2012 series valve manifold. This fieldbus manifold series is capable of addressing a
total of 224 I/O. The manifold can be viewed as having two sections to it, the
Side Valve Side
. The
maximum of 6 modules totaling 192 Outputs, 96 Inputs, or various combinations. The communication
module has two connectors: a communication connector and a 4-pin power connector. Pin-outs for these,
along with I/O connectors, are labeled on the side of the respective modules.
Discrete I/O
LED Status
Indicator(s)
Dual 25 Pin Sub-D
w/Aux Power
Output Module
Analog Module
Connector Module
G2-2 Series Modbus/TCP Quick Start Manual
supports a maximum of 32 solenoid coils and the
Connectors
I/O Point
19 Pin Round
8 Connector I/O Module
TDG22EMQS1-0EN
Subject to change without notice
www.numatics.com/fieldbus
Discrete I/O Side
(Maximum of 6 Modules)
Module/
Network
Status LED's
EtherNet
IP
MAC ADDRESS
Manual Configuration
Terminal Strip Module
Module (MCM)
9/07
Valve Side
and the
Discrete I/O Side
supports a
Valve Side
(Maximum of 32 Solenoids)
Chassis Ground
Connection
Valve
End Plates
Valve
Valve Side
Sub-D Output
Module
Communications
Module (Node)
Solenoid LED
Status Indicator
Discrete I/O
Manual
Override
Page 1
