- Page 1 ASSEMBLY INSTRUCTIONS Description : TRANSITIONAL PED FOR BUTTERFLY TOP Item No. : T-7XB BEFORE ASSEMBLY ITEM : T-7XB Printed in Vietnam - 1 -...
- Page 2 (M7.8x13mm) (M13mm) Allen key Height adjustable leveler (4mm) (6mm) STEP 1 Attach legs (B) to column (A) with nuts (3), washers (2) and (1). Tighten with wrench (4) as shown below. ITEM : T-7XB Printed in Vietnam - 2 -...
- Page 3 Use the Allen key (5) to loosen the bolts, and take off the mounting plate underneath of the table top. STEP 3 Attach the mounting plate to top of the column (A) with washers (1), (2) and nuts (3). Tighten with the wrench (4) as shown below. ITEM : T-7XB Printed in Vietnam - 3 -...
- Page 4 Assemble the height adjustable levelers (6) at bottom of legs (B). STEP 5 Stand the table upright. Unlock the table top from both sides underneath of the top as shown below. Pull the 2 parts of the table top apart. ITEM : T-7XB Printed in Vietnam - 4 -...
- Page 5 STEP 6 Lift the butterfly leaf on, and spread it at center of open table top. Lock the table top parts at underneath as shown below. ITEM : T-7XB Printed in Vietnam - 5 -...
