Pulsar dBi 3 Ex ia Installation Manual

EC DECLARATION OF CONFORMITY
Declaration No. 001001
We, the undersigned:
Name of Pulsar Process Measurement Ltd.
Manufacturer /
Authorised
representative
Address: Pulsar Process Measurement Ltd
Cardinal Building
Enigma Commercial Centre
Sandy's Road
Malvern
Worcestershire
WR14 1JJ
Country: England
Declare under our sole responsibility that the
following apparatus:
Product Ultrasonic Transducers, HART dBi
description: range
Model or Type dBi 3, dBi 6, dBi 10 & dBi 15 Ex ia
No.: & Ex mb versions
Brand name: HART dBi range
Are in conformity with the following relevant EC
legislation:
ATEX directive 94/9/EC
EMC directive 2004/108/EC
Based on the following harmonised standards:
EN60079-0:2009 EN60079-11:2012 (Ex ia)
EN60079-18:2009 (Exmb) EN60079-26:2007 (Ex ia)
EN61326-1:2006 EN55011 Class B radiated emissions
EN61000-4-2 Level 4 Immunity to static discharge
EN61000-4-3 Immunity to radiated fields
EN61000-4-5 Level 4 immunity to surges
EN61000-4-6 Level 4 immunity to conducted interference
And therefore complies with all of the relevant
essential requirements of those other directives.
The following Notified Body has been involved in the
conformity assessment process:
Notified Body TRaC Global Ltd
Notified Body 0891
No.
Role: Issue of ATEX EC Type Examination
certificate
Certificate No. TRaC12ATEX0022X (Ex ia) &
TRaC12ATEX0023X (Ex mb)
Additional information:
ATEX coding II 1 G Ex ia IIC T4 Ga & II 1 D Ex ia IIIC
T130°C Da Tamb -40°C to +80°C
II 2 G Ex mb IIC T4 Gb & II 2 D Ex mb
IIIC T130°C Db Tamb -40°C to +80°C
Limitations on 1. The dBi transducers must be routinely
use inspected to avoid the build up of dust
layers when installed in a Zone 21 & 22.
Electrostatic hazard – The dBi
2.
transducers must only be wiped with a
damp or antistatic cloth
3. Only the fuses listed on drawing D-0804-
0978-A are permitted to be used with the
Ex mb approved dBi transducers.
Name and position of person binding the manufacturer
or authorised representative:
Signature
Name Steve Lycett
Function
Authorised Person
Location
Pulsar Process Measurement Ltd, WR14
1JJ
Date of issue 2012-11-09
P U L S A R Process Measurement Limited
Cardinal Building
Enigma Commercial Centre
Sandy's Road
Tel: +44 (0)1684 891371
Malvern Fax: +44 (0)1684 575985
WR14 1JJ email: info@pulsar-pm.com
United Kingdom http://www.pulsar-pm.com
©Pulsar Process Measurement Ltd 2012
dBi series
Intelligent Transducer
INSTALLATION MANUAL
Full manual available @ www.pulsar-pm.com
M-DBi—000-001-1P
