This device shall support switchable aspect ratios of 4:3 and 16:9, and shall offer a
4:3 area marker.
This device shall provide beam landing correction to compensate for changes in the
terrestrial magnetic field in different operating environments.
This device shall include digital point convergence for complete RGB convergence
accuracy within the image area. A built-in test pattern generator shall be included for
assistance in convergence and other monitor setup functions.
This device shall include a 16:9 tube with the ability to display 4:3 format video.
6.0

Dimensional Information

This device shall employ the use of a 24" diagonal (21.88" viewable) CRT.
This device shall have maximum cabinet dimensions of 17.25 inches high by 22.38
inches wide and 23.13 inches deep.
This device shall not weigh more than 113 pounds.
7.0

Connectivity Information

This device shall provide for direct connection of a single source device, and shall
be built with expansion capabilities (4 slots) for additional source devices, with a
maximum of 25 directly connected sources. This connection shall include the
following:
Component Video or RGB Video on BNC Connectors with loop-through
Optional source connections shall include the following:
Composite Video on a BNC Connector with loop-through
S-Video on two BNC Connectors with loop-through
Component Video or RGB Video on BNC Connectors with loop-through
SDI Video on a BNC Connector with loop-through
HD-SDI Video on a BNC Connector with loop-through
8.0

Power Requirements
