Argos3D - P100
Quick Start Guide
Version 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Argos3D - P100 and is the answer not in the manual?

Questions and answers

Related Manuals for Bluetechnix Argos3D - P100

Summary of Contents for Bluetechnix Argos3D - P100

  • Page 1 Argos3D - P100 Quick Start Guide Version 2...
  • Page 2 This document is protected by copyright. All rights reserved. No part of this document may be reproduced or transmitted for any purpose in any form or by any means, electronically or mechanically, without expressly written permission by Bluetechnix GmbH. Windows is a registered trademark of Microsoft.

  • Page 3: Table Of Contents

    Start-up screen ......................... 8 Install Argos - P100 Drivers ......................10 Start using your Argos - P100 with “BltTofSuite” ................ 17 System Requirements & Support ....................18 Support ........................... 18 Product History ..........................19 Document Revision History ....................19 ©Bluetechnix 2016...
  • Page 4 Bluetechnix takes no liability for any damages and errors causing of the usage of this board. The user of this board is responsible by himself for the functionality of his application. He is allowed to use the board only if he has the qualification.

  • Page 5: Unboxing

    Quick Start Guide - Argos3D - P100 Unboxing In the box  Argos - P100  Micro USB Cable  /3A Power Supply  Tripod  Quick Start Guide Connecting your Argos -P100 1.2.1 Connector Overview The Argos - P100 features three connectors. A 5V @2.5A connection, Micro USB2.0 and an external sync...

  • Page 6: Connecting The Power Supply

    Quick Start Guide - Argos3D - P100 1.2.2 Connecting the power supply To ensure, that your Argos - P100 works correctly, plug in the power supply and wait for approximately 10 seconds until the camera boots up. Figure 1-2: Connecting Power Supply 1.2.3...

  • Page 7: Downloading The Support Package

    Quick Start Guide - Argos3D - P100 Downloading the support package Please point your browser to our support site https://support.bluetechnix.com/ and select the ‘Free Access’ area. Support website Figure 2-1: Bluetechnix support site © Bluetechnix 2016 Page 7 | 19...

  • Page 8: Start-Up Screen

    Quick Start Guide - Argos3D - P100 Start-up screen Figure 2-2: Start-up screen Please select your product: Argos3D – P100 On the product support page please download the latest support package from the download section. © Bluetechnix 2016 Page 8 | 19...
  • Page 9 Quick Start Guide - Argos3D - P100 Once you downloaded the support package extract the .zip file on your hard drive to e.g. C:\Argos3D-P100\ and read the Readme.txt first. Figure 2-3: Unzipped support package © Bluetechnix 2016 Page 9 | 19...

  • Page 10: Install Argos - P100 Drivers

    Quick Start Guide - Argos3D - P100 Install Argos - P100 Drivers At the first time you have plugged in your Argos - P100, you have to install the driver which can be found in the support package. Open the Windows “Device Manager” in the “Control Panel”...
  • Page 11 Quick Start Guide - Argos3D - P100 Once Device Manager is opened, right click “Bluetechnix – Argos3D – P100” in “Other Devices” and click “Update Driver Software”. Figure 3-2: Device Manager – Update Driver Software © Bluetechnix 2016 Page 11 | 19...
  • Page 12 Quick Start Guide - Argos3D - P100 Then choose “Browse my computer for driver software”. Figure 3-3: Locate and install driver software manually © Bluetechnix 2016 Page 12 | 19...
  • Page 13 Quick Start Guide - Argos3D - P100 Point the driver install utility to “C:\Argos3D-P100\windows\driver” on your local hard drive. Check “Include subfolders” and click “Next”. Figure 3-4: Browse for driver software on your computer © Bluetechnix 2016 Page 13 | 19...
  • Page 14 Quick Start Guide - Argos3D - P100 If the following question arises, choose to lay your trust upon Bluetechnix GmbH. Figure 5: Always trust software from “Bluetechnix GmbH” © Bluetechnix 2016 Page 14 | 19...
  • Page 15 Quick Start Guide - Argos3D - P100 The Update Driver Software Utility finishes the driver installation showing following Window. Figure 3-6: Driver Software successfully installed © Bluetechnix 2016 Page 15 | 19...
  • Page 16 Quick Start Guide - Argos3D - P100 After successful driver installation there should be a new device in the device manager named “Bluetechnix - Argos 3D - P100”. Figure 3-7: Bluetechnix PMD Devices in Device Manager Congratulations You now have successfully installed your Argos - P100 on your PC.

  • Page 17: Start Using Your Argos - P100 With "Blttofsuite

    - P100 with “BltTofSuite” Browse to the directory where you previously saved the BltTofSuite software zip file. Unzip the software. On how to use this software, please refer to the Bluetechnix ToF Suite user manual included in the support package.

  • Page 18: System Requirements & Support

    Dedicated USB 2.0 port or USB 3.0 port  2 GByte RAM Support For answers to common questions, troubleshooting steps and further documentation visit our Bluetechnix support website or using the direct link: https://support.bluetechnix.com/wiki/Argos © Bluetechnix 2016 Page 18 | 19...

  • Page 19: Product History

    Quick Start Guide - Argos3D - P100 Product History Document Revision History Version Date Document Revision First draft 20160210 Removed BltTofSuite section Updated driver installation Updated Downloading support package Table 6.1: Revision history © Bluetechnix 2016 Page 19 | 19...
