Portable Air Conditioner

Operation

Timer Setting

Setting the Auto-Off Timer
When the air-conditioner is running, press the TIMER button - the timer LED will illuminate. The
display will flash "--" 5 times. While it is flashing, press UP and DOWN to adjust the time - range is
0.5 hours (30 minutes) to 24 hours. For timer settings under 3 hours, the increments are in 30
minute blocks. For timer settings over 3 hours, increments are in 1 hour blocks. When the timer
expires, the air-conditioner will turn off automatically.
Setting the Auto-On Timer
When the air-conditioner is in standby, press the TIMER button - the timer LED will illuminate. The
display will flash "--" S times. While it is flashing, press UP and DOWN to adjust the time and set
the method of operation required. If you set the mode to COOL or HEAT, then you can also select
the desired temperature. For timer settings under 3 hours, the increments are in 30 minute blocks.
For timer settings over 3 hours, increments are in 1 hour blocks. When the timer expires, the air-
conditioner will turn on automatically and run in the selected operating mode.
Changing a Previously Set Timer
If you need to change an existing timer setting, press the TIMER button. The display will flash,
showing the time remaining. While it is flashing, press UP or DOWN to increase or decrease the
time. If you press the TIMER a second time while the numbers are flashing, the timer will be
cancelled.

Operating Modes

HEAT and COOL
• While the air-conditioner is running or is in TIMER ON mode, press MODE to select HE AT
or COOL mode. The LEDs on the control panel will light up.
• Press UP/DOWN to set the appropriate temperature (range = 18 to 30
each press of the UP or DOWN button, the temperature will change by 1
Press SPEED to select the most appropriate fan speed, between LOW and HIGH speeds.
After selecting COOL or HEAT mode, press SLEEP on your remote control (or press UP and T IMER
on the control panel simultaneously) to enter SLEEP mode. Both the upper and lower fans will be
set and locked to LOW speed. Set the timer from 0.5 to 12 hours, based on your requirements, after
which the air-conditioner will automatically be turned off. If you wish to cancel the SLEEP mode,
press the SLEEP button again.
DEHUMIDIFY
• While the air-conditioner is running or is in TIMER ON mode, press MODE to select
DEHUMIDIFY mode. The LEDs on the control panel will light up.
• Temperature and speed are not adjustable in dehumidify mode.
FAN
• While the air-conditioner is running or is in TIMER ON mode, press MODE to select FAN
mode. The LEDs on the control panel will light up.
• Press SPEED to select the appropriate fan speed, between LOW and HIGH speeds.
Temperature is not adjustable.
When the full water indicator is displayed, the air-conditioner will stop working and you
should drain the water.
In DEHUMIDIFY and FAN modes, you do not need to use the exhaust pipe.
E&OE E&OE ©2017 Bio Design ©2017 Bio Design
Bio Design
° C (64 to 86 ° F)). For
° .
