- Page 1 TECHNICAL MANUAL Line amplifier module Art. 4833C Passion.Technology. Design.
- Page 2 Warning Intended use This Comelit product was designed for use in the creation of audio and video communication systems in residential, commercial or industrial settings and in public buildings or buildings used by the public. Installation All activities connected to the installation of Comelit products must be carried out by qualified technical personnel, with careful observation of the indications provided in the Manuals / Instruction sheets supplied with those products.
-
Page 3: Technical Features
Description Amplifier for Simplebus TOP systems, to increase the distance between the external unit and mixer 4888C. Regenerates the video component of the riser signal. Equipped with microcontroller for optimal operation management. Follow the operating instructions in the technical documentation. Power supply: 12V AC or 20V DC. Only to be mounted on the system section feeding into the mixers art. - Page 4 12V~ VIDEO ENTRY SYSTEM RISER ⁓ ⁓ OUT OUT 4833C EXTERNAL UNIT System performance and layouts For further information of system performance and to view installation layouts, click on the system type that best meets your requirements: • SBTOP audio/video system...
- Page 5 C E R T I F I E D M A N A G E M E N T S Y S T E M S w w w . c o m e l i t g r o u p . c o m Via Don Arrigoni, 5 - 24020 Rovetta (BG) - Italy...
