Eaton TRL04 Technical Data

TRL04, TRL07
Timers
Timers multifunctional
Up to 7 functions
7 time ranges
Wide input voltage range
1 change over contact
Width 17.5 mm
Installation design
Technical data
1. Functions 6. Output circuit
The function has to be set before connecting the relay to the supply 1 potential free change over contact
voltage. Rated voltage:
Switching capacity:
E ON delay Fusing:
R OFF delay Mechanical life:
Ws* Single shot leading edge with control input (only TRL07) Electrical life:
Wa* ingle shot trailing edge with control input (only TRL07)
Es* ON delay with control input (only TRL07) Switching frequency:
Wu Single shot leading edge voltage controlled
Bp Flasher pause first Overvoltage category:
Rated surge voltage:
* Only available on TRL07
7. Control input
2. Time ranges
Input not potential free:
Time range Adjustment range Loadable:
1s 50ms 1s Max. line length:
10s 500ms 10s Trigger level (sensitivity):
1min 3s 1min Min. control pulse length:
10min 30s 10min
1h 3min 1h 8. Accuracy
10h 30min 10h
Base accuracy:
100h 5h 100h
Adjustment accuracy:
Repetition accuracy:
3. Indicators
Voltage influence:
Green LED U/t ON: indication of supply voltage Temperature influence:
Green LED U/t flashes: indication of time period
Yellow LED R ON/OFF: indication of relay output 9. Ambient conditions
Ambient temperature:
4. Mechanical design
Storage temperature:
Self-extinguishing plastic housing, IP rating IP40 Transport temperature:
Mounted on DIN-rail TS 35 according to EN 60715 Relative humidity:
Mounting position: any
Shockproof terminal connection according to VBG 4 (PZ1 required), Pollution degree:
IP rating IP20
Tightening torque: max. 1Nm
Terminal capacity: 10. Dimensions
1 x 0.5 to 2.5mm² with/without multicore cable end
1 x 4mm² without multicore cable end
2 x 0.5 to 1.5mm² with/without multicore cable end
2 x 2.5mm² flexible without multicore cable end
5. Input circuit
Supply voltage: 24V to 240V AC/DC
Terminals: A1(+)-A2
Tolerance: -15% to +10%
Rated consumption: 4VA (1.5W)
Rated frequency: AC 48 to 63Hz
Duty cycle: 100%
Reset time: 100ms
5mm 44mm
Residual ripple for DC: 10%
60mm
Drop-out voltage: >30% of minimum rated supply voltage
Overvoltage category: III (in accordance with IEC 60664-1)
Rated surge voltage: 4kV 11. Weight
Single packing:
Release 07/09
090564 / IL04910002E
TRL04, TRL07
Functions
ON delay (E)
When the supply voltage U is applied, the set interval t begins (green
LED U/t flashes). After the interval t has expired (green LED U/t
illuminated) the output relay R switches into on-position (yellow LED
illuminated). This status remains until the supply voltage is interrupted.
If the supply voltage is interrupted before the expiry of the interval t,
the interval already expired is erased and is restarted when the supply
voltage is next applied.
U
E
LED U/t
R t <t
OFF delay (R)
The supply voltage U must be constantly applied to the device (green
LED U/t illuminated). When the control contact S is closed, the output
relay R switches into on-position (yellow LED illuminated). If the control
contact is opened, the set interval t begins (green LED flashes). After
the interval t has expired (green LED U/t illuminated) the output relay
switches into off-position (yellow LED not illuminated). If the control
contact is closed again before the interval t has expired, the interval
already expired is erased and is restarted.
250V AC
U
2000VA (8A / 250V)
8A fast acting LED U/t
R
20 x 10 6 operations S
t <t
2 x 10 operations
5 R
t <t
at 1000VA resistive load
max. 6/min at 1000VA resistive load
(in accordance with IEC 60947-5-1)
Single shot leading edge with control input (Ws)
III (in accordance with IEC 60664-1)
The supply voltage U must be constantly applied to the device (green
4kV
LED U/t illuminated). When the control contact S is closed, the output
relay R switches into on-position (green LED U/t illuminated) and the
set interval t begins (green LED U/t flashes). After the interval t has
Terminals A1-B1 expired (green LED U/t illuminated) the output relay switches into
yes off-position (yellow LED not illuminated). During the interval, the control
10m
contact can be operated any number of times. A further cycle can only
automatic adaption to supply voltage be started when the cycle run has been completed.
DC 50 ms / AC 100 ms
U
LED U/t
Ws
±1% of maximum scale value
S
<5% of maximum scale value
R
t t
<0.5% or ±5ms
-
≤0.01% / °C
Connections
-25 to +55°C
with control contact without control contact
-25 to +70°C
-25 to +70°C
15% to 85% (+) (+)
U ~ U ~
(in accordance with IEC 60721-3-3 class 3K3)
(-) ( -)
2, if built in 3
15 S
(in accordance with IEC 60664-1)
A1 B1
A1 15
R
A2 16 18
A2
16 18
17,5mm
Danger!
72g
Never carry out work on live parts! Danger of fatal injury! The product must not be
used in case of an obvious damage. To be installed by an authorized person.
Single shot trailling edge with control input (Wa)
The supply voltage U must be constantly applied to the device (green
LED U/t illuminated).
Closing the control contact S has no influence on the condition of the
output R. When the control contact is opened, the output relay switches
into on-position (yellow LED illuminated) and the set interval t begins
(green LED U/t flashes). After the interval t has expired (green LED U/t
illuminated), the ouput relay switches into off-position (yellow LED not
illuminated). During the interval, the control contact can be operated
any number of times. A further cycle can only be started when the cycle
run has been completed.
U
LED U/t
Wa
S
R t t
ON delay with control input (Es)
The supply voltage U must be constantly applied to the device (green
LED U/t illuminated).
When the control contact S is closed, the set interval t begins (green
LED U/t flashes). After the interval t has expired (green LED U/t illumi-
nated) the output relay R switches into on-position (yellow LED illumi-
nated). This status remains until the control contact is opened again.
If the control contact is opened before the interval t has expired , the
interval already expired is erased and is restarted with the next cycle.
U
LED U/t
Es
S
R t <t
Single shot leading edge voltage controlled (Wu)
When the supply voltage U is applied, the output relay R switches
into on-position (yellow LED illuminated) and the set interval t begins
(green LED U/t flashes). After the interval t has expired (green LED U/t
illuminated) the output relay switches into off-position (yellow LED not
illuminated). This status remains until the supply voltage is interrupted.
If the supply voltage is interrupted before the interval t has expired, the
output relay switches into off-position. The interval already is erased
and is restarted when the supply voltage is next applied.
U
Wu
LED U/t
R t <t
Flasher pause first (Bp)
When the supply voltage U is applied, the set interval t begins (green
LED U/t flashes). After the interval t has expired, the output relay R
switches into on-position (yellow LED illuminated) and the set interval t
begins again. After the interval t has expired, the output relay switches
into off-position (yellow LED not illuminated).
15
The output relay is triggered at a ratio of 1:1 until the supply voltage is
A1 B1
interrupted.
A1 15
U
R
Bp
LED U/t
A2 16 18
R
u t t t t
A2
16 18
TRL04, TRL07
Zeitrelais
Zeitrelais multifunktional
Bis zu 7 Funktionen
7 Zeitbereiche
Weitbereichseingang
1 Wechsler
Baubreite 17.5 mm
Installationsbauform
Technische Daten
1. Funktionen 6. Ausgangskreis
Die Auswahl der Zeitfunktion muss im spannungslosen Zustand erfolgen. 1 potentialfreier Wechsler
Bemessungsspannung:
E Einschaltverzögert Schaltleistung:
R Rückfallverzögert mit Steuereingang Absicherung:
Ws* Einschaltwischend mit Steuereingang (allein TRL07) Mechanische Lebensdauer:
Wa* Ausschaltwischend mit Steuereingang (allein TRL07) Elektrische Lebensdauer:
Es* Einschaltverzögert mit Steuereingang (allein TRL07)
Wu Einschaltwischend Spannungsgesteuert Schalthäufigkeit:
Bp Blinker pausebeginnend
Überspannungskategorie:
* Diese Funktionen sind allein verfügbar bei Type TRL07 Bemessungsstoßspannung:
2. Zeitbereiche 7. Steuereingang
Zeitendbereich Einstellbereich Eingang potentialbehaftet:
1s 50ms 1s Belastbar:
10s 500ms 10s Max. Leitungslänge:
1min 3s 1min Ansprechschwelle:
10min 30s 10min Min. Steuerimpulslänge:
1h 3min 1h
10h 30min 10h 8. Genauigkeit
100h 5h 100h
Grundgenauigkeit:
Einstellgenauigkeit:
3. Anzeigen
Wiederholgenauigkeit:
Grüne LED U/t ON: Versorgungsspannung liegt an Spannungseinfluss:
Grüne LED U/t blinkt: Anzeige des Zeitablaufs Temperatureinfluss:
Gelbe LED R ON/OFF: Stellung des Ausgangsrelais
9. Umgebungsbedingungen
4. Mechanische Ausführung
Umgebungstemperatur:
Gehäuse aus selbstverlöschendem Kunststoff, Schutzart IP40 Lagertemperatur:
Befestigung auf Profilschiene TS 35 gemäß EN 60715 Transporttemperatur:
Einbaulage: beliebig Relative Luftfeuchtigkeit:
Berührungssichere Zugbügelklemmen nach VBG 4 (PZ1 erforderlich),
Schutzart IP20 Verschmutzungsgrad:
Anzugsdrehmoment: max. 1Nm
Klemmanschluss:
1 x 0.5 bis 2.5mm² mit/ohne Aderendhülse 10. Abmessungen
1 x 4mm² ohne Aderendhülse
2 x 0.5 bis 1.5mm² mit/ohne Aderendhülsen
2 x 2.5mm² flexibel ohne Aderendhülsen
5. Versorgungskreis
Versorgungsspannung: 24V bis 240V AC/DC
Klemmen: A1(+)-A2
Toleranz: -15% bis +10%
Nennverbrauch: 4VA (1.5W)
Nennfrequenz: AC 48 bis 63Hz
Einschaltdauer: 100%
Wiederbereitschaftzeit: 100ms
Restwelligkeit bei DC: 10%
5mm 44mm
Abfallspannung: >30% der min. Versorgungsspannung
60mm
Überspannungskategorie: III (nach IEC 60664-1)
Bemessungsstoßspannung: 4kV
11. Gewicht
Einzelverpackung:
Ausgabe 07/09
250V AC
2000VA (8A / 250V)
8A flink
20 x 10 6 Schaltspiele
2 x 10 Schaltspiele
5
bei 1000VA ohmscher Last
max. 6/min bei 1000VA ohmscher Last
(nach IEC 60947-5-1)
III (nach IEC 60664-1)
4kV
Klemmen A1-B1
ja
10m
automatisch an Versorgung angepasst
DC 50 ms / AC 100 ms
±1% vom Skalenendwert
<5% vom Skalenendwert
<0.5% oder ±5ms
-
≤0.01% / °C
-25 bis +55°C
-25 bis +70°C
-25 bis +70°C
15% bis 85%
(nach IEC 60721-3-3 Klasse 3K3)
2, im eingebauten Zustand 3
(nach IEC 60664-1)
17,5mm
72g
