SyncMaster TC190, TC240

LCD MONITOR

quick start guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SyncMaster TC190 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung SyncMaster TC190

Summary of Contents for Samsung SyncMaster TC190

  • Page 1: Lcd Monitor

    SyncMaster TC190, TC240 LCD MONITOR quick start guide...

  • Page 2: Installing The Product

    Installing the Product Package Contents • Unpack the product and check if all of the following contents have been included. • Store the packaging box in case you need to move the Product at a later stage. Installation Manual Keyboard (USB) Installing the Stand Before assembling the product, place the product down on a flat and stable surface so that the screen is facing downwards.
  • Page 3 Place a soft cloth over the table to protect the product and place the product onto the cloth so that the front of the product is facing downwards. Do not remove the stopper pin before installing the base. Hold the main body of the product with your hand as shown by the figure. Insert the stand base into the stand connection part in the direction shown in the figure.

  • Page 4: Installing A Wall Mount

    Disassembly is in the reverse order of assembly. Installing a Wall Mount Before installation, disassemble the product according to the following steps. After the installation of the base, stand the monitor up as shown in the figure. Now you can remove the stopper pin to adjust the stand. - Caution Avoid lifting the product holding only the stand.
  • Page 5 This product provides a wall mount of 100 mm x 100 mm(200 mm x 100 mm) that complies with the VESA specifications. 100 mm x 100 mm 1. Turn the product off and unplug the power cord from the wall outlet. 2.

  • Page 6: Connecting To Your Network

    •Do not use screws that are incompatible with the standard VESA specifications and do not assemble them using excessive force. This may result in damage to the product or injury due to the product falling. Samsung shall not be held liable for any damage or injury.

  • Page 7: Connecting Power

    Connecting Power Connect one end of the power cord to the POWER port of the product and connect the other end of the power cord to a 220V or 110V wall outlet. (The input voltage is switched automatically.)

  • Page 8: Connecting To Another Monitor

    Connecting to another Monitor Connect between the [VIDEO OUT] port on the product and the D-Sub port on your monitor using a D-Sub cable. Connect to the [VIDEO OUT] port to display the same picture on another monitor. (For presentation purposes)

  • Page 9: Connecting A Serial Cable

    Connecting a SERIAL Cable Devices which support RS-232C connection (interface) can be connected.

  • Page 10: Connecting To Your Printer

    Connecting to your Printer Devices which support D-SUB 25-pin connection (interface) can be connected.

  • Page 11: Connecting With A Pc

    Connecting with a PC Connect the [RGB IN] port of the product to the [D-Sub] port of your PC with a D-Sub cable. Use the [RGB IN] port to directly connect the monitor to a PC.

  • Page 12: Connecting A Stereo Cable

    1-10 Connecting a Stereo Cable Connect the [AUDIO IN] port on the rear side of the monitor to the sound card of the PC.

  • Page 13: Connecting Usb

    1-11 Connecting USB USB port of the monitor supports Full-Speed Certified USB 2.0. Connect USB devices such as a mouse, keyboard and external storage devices (DSC (Digital Still Camera), MP3, external storage, etc.). You can use a USB device such as a mouse, keyboard, Memory Stick, or external hard disk drive by connecting them to the port of the monitor without connecting them to the PC.

  • Page 14: Connecting Headphones

    1-12 Connecting Headphones Connect your headphones to the Headphone connection terminal. You may connect your headphones to the monitor.

  • Page 15: Connecting Mic

    1-13 Connecting MIC Connect the microphone cable to the MIC port on the monitor. You may connect your microphone to the monitor.

  • Page 16: Kensington Lock

    1-14 Kensington Lock A Kensington Lock is an anti-theft device that enables users to lock the product so that they can safely use it in public locations. Since the shape and usage of the locking device may differ depending on the model and the manufacturer, for more information, refer to the User Manual supplied with the locking device.

  • Page 17: Troubleshooting

    Before Requesting Service Please check the following before requesting After-Sales service. If the problem continues, please contact your nearest Samsung Electronics Service Center. Is the power cord connected properly? Is the <Check Signal Cable> message displayed on the screen? Is the <Not Optimum Mode>...
  • Page 18 The display area suddenly moves to an edge or to the center. Did you change the graphics card or the driver? Did you change the resolution and frequency appropriate to the product? Is the graphics card configured correctly? Did you change the resolution and the frequency appropriate to the product? The color is displayed in 16 bit (16 colors).
  • Page 19 FAQ! How can I change the frequency of the video signal? How can I change the resolution? How can I use the power saving function? Please try the following! You have to change the frequency of the graphics card. (For more information, refer to the User Manual of the com- puter or the graphics card.) Windows XP : Change the resolution by selecting Control →...
