PBI DXP-5410EM-C User Manual

4-channel integrated h.264 hd encoder-modulator. dxp-5410 series; dxp-5411em series
Hide thumbs
Table of Contents

Advertisement

Quick Links

DXP- - - - 5410/5411
DXP
DXP
DXP
ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001
р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704
ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru
User Manual
5410/5411EM
EM
5410/5411
5410/5411
EM
ООО «ТЛК Трейд», Санкт-Петербург
Brighten Your Digital View!
EM
4-Channel Integrated H.264
HD Encoder-Modulator
+7 812 64 99 888
mail@tlct.ru

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DXP-5410EM-C and is the answer not in the manual?

Questions and answers

Related Manuals for PBI DXP-5410EM-C

Summary of Contents for PBI DXP-5410EM-C

  • Page 1 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru User Manual Brighten Your Digital View! DXP- - - - 5410/5411 5410/5411EM 5410/5411 5410/5411 4-Channel Integrated H.264 HD Encoder-Modulator ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001 р/с...

  • Page 2: Table Of Contents

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Contents Notice Before Using the Device 1 Overview 2 Features 3 Technical Specifications 4 Block Diagram 5 Front panel and rear panel instructions 5.1 Front panel 5.2 Rear panel 6 Control with Front Panel 6.1 Overview of the Menu 6.2 Description of menu 6.2.1 Status...
  • Page 3 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Notices COPYRIGHT (Copyright © 2013 Beijing Jaeger Communication Electronic Technology Co., Ltd.) Not to be copied, used or translated in part or whole without Beijing Jaeger prior consent in writing except approval of ownership of copyright and copyright law.
  • Page 4 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru For more detailed information about recycling of this product, please contact your local Civic Office, your household waste disposal service, or the shop where you purchased the product. COPYRIGHTS Television programs, movies, video tapes, discs, and other materials may be copyrighted. Unauthorized recording of copyrighted material may be against the copyright laws in your region.
  • Page 5 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Before Using the Device Thank you for purchasing the DXP-5410/5411EM 4-Channel Integrated Encoder-Modulator. This User Manual is written for operators/users of the DXP-5410/5411EM to assist in installation and operation. Please read this user manual carefully before installation and use of the device. FOR YOUR SAFETY This equipment is provided with a protective earthing ground incorporated in the power cord.

  • Page 6: Overview

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru • The mounting environment should be relatively dust free, free of excessive vibration and the ambient temperature between 0C° to 40C°. Relative humidity of 20% to 80% (non-condensed) is recommended. •...

  • Page 7: Technical Specifications

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru ASI & TS/IP outputs Up to 5 TS/IP output streams (200Mb/s Max.)( 4 for encoders, 1 for ASI mirrored or reMUX) 480i/NTSC, 576i/PAL, 720p,1080i & 1080p Constant Bit Rate (CBR) & Variable Bit Rate (VBR) DVB-C/QAM (ITU J.83 Annex A/C) or DVB-T/COFDM RF out, selectable 50MHz ~ 996MHz RF carrier output frequency adjustable 120dBµV Total Output Level...
  • Page 8 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Maximum Effective Bit Rate 200 Mb/s Data type Byte Packet Length 188/204 Bytes Valid Receiving Amplitude 200 ~ 880mVp-p DVB-ASI Output Interface Type BNC Female, 75Ω Maximum Effective Bit Rate 200Mb/s Data type Byte...
  • Page 9 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Guard Interval 1/4，1/8，1/16，1/32 1/2，2/3，3/4，5/6，7/8 FEC rate 36dB min., 40dB typ. RF Output F-type Female，75Ω Interface Carrier Central Frequency 50~996MHz adjustable，step by 10 KHz Output Level 90~120dBµV, step by 1dB Spurious ≥60dBc @ 120dBuV ≥12dB（typ.）...

  • Page 10: Block Diagram

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru 4 Block Diagram 5 Front panel and rear panel instructions 5.1 Front panel ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001 р/с...

  • Page 11: Rear Panel

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru A1 Status LEDs Power: green when power is on, red when one of the power supply unit malfunction Warning: red when function faulty Alarm: red when function critical A2 Encoder Status Encoder 1~4 working status, green light indicates the corresponding encoder module is under working, red when the corresponding encoder module malfunction or stop or input is invalid (the other 4 LEDs are not used)

  • Page 12: Front Panel

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru DXP-5410EM/5411EM-S B1 ASI IN ASI input interface B2 ASI OUT 2 ASI output interface (output in mirror) B3 Audio Video Input CVBS and Audio input interface B4 RS232 Reserved for factory use B5 Alarm Alarm relay interface B6 RF Out...

  • Page 13: Description Of Menu

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Status Configuration System Encoder Remux TS/IP TS/IP COFDM Status (Mode: /QAM Setting Output (Full Multiple Duplex/ Output/ Multiple Full Output) Duplex) 6.2 Description of menu The main menu items can be selected with the keypad. By pressing the [Enter], the user navigates to the submenus, which are selected in the same manner.
  • Page 14 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru FEC Counter Reset Reset the FEC packets counter TS/IP Status Display IP link Status: Link Status (Multiple Output) 10M/100M/1000M/Disconnect 6.2.2 Config – Encoder Submenu & Description Default Value Parameters Encoder Select: Encoder 1: the encoder 1 is active for configuration Encoder 2: the encoder 2 is active for configuration Encoder Select...
  • Page 15 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Audio Format: Audio Format: MPEG1 Layer2 MPEG1 Layer2: set the audio compression format MPEG-1 Layer II MPEG2 AAC-LC, MPEG4 AAC-LC can be selected on DXP- 5410EC series only Audio Bit Rate: 32k bps /48k bps /56k bps /64k bps /80k bps Audio Bit Rate: 128 Kbps /96k bps /112k bps128k bps /160k bps /192k bps /224k bps /256k bps /320k bps /384k bps...

  • Page 16: Ts/Ip (Multiple Output Mode

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru 6.2.3 Config – Remux Submenu & Description Default Value Parameters Program List: select the programs to remux. Click on Enter to select, double click to cancel. (The program(s) will be marked with an asterisk (*) once be selected) Encoder 1: select the program from encoder 1 Encoder 2: select the program from encoder 2...

  • Page 17: Ts/Ip (Full Duplex Mode

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Gigabit Out Switch: Gigabit Out Switch: ON ON/OFF: to switch on/off the current channel IP Board IP Gigabit Address: set the IP address of the IP port Address:10.10.10.10 IP Board Net Gigabit Subnet Mask: set the net mask of the IP port Mask:255.255.255.0 IP Board...

  • Page 18: Modulation (Qam

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Uni/Multi Address: Uni/Multi IP Address: set the destination IP address 238.069.070.001 Uni/Multi UDP Port: set the destination port number, valid Uni/Multi UDP Port: 01234 range from 1~65535 ProMPEG FEC Switch: ProMPEG FEC Switch: Enable/Disable Disable ProMPEG FEC Mode:...

  • Page 19: Modulation (Cofdm

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru modulator IP In: the stream from IP input will be delivered to modulator ASI Input: the stream from ASI input will be delivered to modulator 16QAM/32QAM/64QAM/128QAM/256QAM Constellation 64QAM valid range from 782~12500 Symbol Rate 6875 Yes: the spectrum is inverted...

  • Page 20: Asi Output

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Spare: always output from the backup RF input RF Out Restore Spare to Main: switch to Main source (the built-in modulator) (the submenu displays Main to Spare: switch to Backup RF source only when Auto mode is selected.) 6.2.9 Configuration –...

  • Page 21: Control With Web Server

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Edit Login Password: press Enter and key in the password Default Login Password: WEB Login Password for WEB management 12345 Gigabit Mode: Multiple Output: the IP I/O is configured as multiple uni/multicast output mode, which delivers up to 5 streams over IP.
  • Page 22 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Status of Encoders and ASI input Status of Output Status of TS/IP Linkage 7.2 Configuration All parameters for encoding, TS/IP I/O, built-in Remux, modulation and RF output can be found under the page “Configuration”.
  • Page 23 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Encoder-1~4 There are four encoders, each encoder works independently. Click on the to configure the Encoder 1, and the same for the rest. Video Settings Video Rate Ctl: set constant bit rate mode or variable bit rate mode for the selected encoder Input Video Format: select the resolution for the encoded video in the dropdown list.
  • Page 24 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Audio Settings Audio Format: set the audio compression format MPEG-1 Layer II or MPEG2 AAC-LC. (MPEG4 AAC-LC can be selected on DXP-5410EC series only) Audio Bit Rate: set the audio bitrate. Audio Channel Mode: set the audio in stereo or mono.
  • Page 25 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Scale Horizontal: set the resolution in horizon Modulation In the page user can set up the parameters for the built-in modulator. DXP-5410/5411EM support QAM and COFDM modulation upon user’s configuration. The tag name will change following the change of the modulation mode.
  • Page 26 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Encoder1 / Encoder2 / Encoder3 / Encoder4 / Remux / IP In / ASI Input 7.3 MUX In the “MUX” page, select the program(s) that to be remultiplexed and configure the necessary parameters for the new generated transport stream.
  • Page 27 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru 7.4 TS/IP DXP-5410/5411EM support two TS/IP operation mode, which are respectively Multiple Output Mode and Full Duplex Mode. To switch between the two mode please refer to chapter 7.6. 7.4.1 Multiple Output Mode Gigabit Out There are up to 5 streams encapsulated onto TS/IP output when TS/IP is configured as multiple output mode.
  • Page 28 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Gigabit In IP in is not supported under multiple output mode Gigabit Local Gigabit Address: set the IP address of the IP port Gigabit Subnet Mask: set the net mask of the IP port ООО...
  • Page 29 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Gigabit MAC Address: display the MAC address of the IP port, cannot be modified by user Gigabit Gateway: set the gateway address under which the IP port is connected Gateway MAC Address: set the MAC address of the gateway under which the device is connected, this is necessary when the IP streaming is needed to pass through the gateways Protocol: select UDP or RTP protocol for the IP output TS Pkts Per UDP: set the number of TS packets that can be carried by each UDP packet...
  • Page 30 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Time To Live: set TTL to the output IP packets Type of Service: select the service type for the outputted IP streaming Uni/Multi IP Address: set the unicast or multicast address for the output IP streaming Uni/Multi UDP Port: set the destination port number, valid range from 1~65535 ProMPEG FEC Switch: Enable or Disable the ProMPEG FEC (Note: the two submenus below are available only when the ProMPEG FEC is switched on and has be...
  • Page 31 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Gigabit Input Note the Column and Row FEC UDP ports have to be configured if Pro-MPEG protocol is used in the IP signal inputted. Uni/Multicast IP Address: set the multicast address for the incoming IP streaming. To receive a unicast streaming, the submenu can be ignored.
  • Page 32 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Gigabit Local Gigabit Address: set the IP address of the IP port Gigabit Subnet Mask: set the net mask of the IP port Gigabit MAC Address: display the MAC address of the IP port, cannot be modified by user Gigabit Gateway: set the gateway address under which the IP port is connected Gateway MAC Address: set the MAC address of the gateway under which the device is connected, this is necessary when the IP streaming is needed to pass through the gateways...
  • Page 33 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Device Device name: Check the name and the serial number of this device. User can resign this product name at will, the device name should be less than 24 characters. The serial number is read-only. Serial Number: show the serial number for the device, cannot be modified by user.
  • Page 34 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Version User can check versions of the device, as shown in the picture below. Web Login Username: set the username for webpage login ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001 р/с...
  • Page 35 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Password: set the password for webpage login Factory Default Click the button “Default” to restore the factory default settings to the device. Note: the IP address of the device and the operation mode of the Gigabit board will not be restored. System Reboot User can reboot this device by clicking the button “Reboot”.
  • Page 36 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Upgrade DXP-5410/5411EM support online firmware upgrade. To upgrade the device, load the upgrade file first by clicking on “Browse…”, in the opened window select the correct upgrade file, then click on “Upgrade”, wait the device complete the upgrade procedure.
  • Page 37 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Open the box and take out the device with care. Inspect if there is any damage to the appearance of the device. Fix the device into the standard EIA 19” rack. Connect the input and output cables.
  • Page 38 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Video Compression H.264 / AVC H.264 / AVC H.264 / AVC H.264 / AVC H.264 / AVC H.264 / AVC Audio Compression MPEG + AAC MPEG + AAC MPEG + AAC MPEG MPEG MPEG...
  • Page 39 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru No.3 Feng Zhi East Road, Xi Bei Wang Town, Hai Dian District, Beijing, 100094, China Tel：＋86 10-82617178 Fax：＋86 10-82610263 ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001 р/с...
