Installation and operation manual 3001391_US_Grease_Fan_GSV200-450_171114 GSV 200-450 grease fan READ AND SAVE THESE INSTRUCTIONS! Product information Chapters 1 + 2 Mechanical installation Chapter 3 Electrical installation Chapter 4 Start up and configuration Chapter 5 Maintenance and troubleshooting Chapter 6 Job name: _________________________________...
1. Product information 1.1 Function exodraft Model GSV Grease Fan is designed to provide a large exhaust volume at a high discharge velocity. It is intended for use as a part of a restaurant kitchen exhaust system and grease applications according to NFPA 96.
• US 3001391_US_Grease_Fan_GSV200-450_171114 1.3 Shipping Protection The fan is shipped in a corrugated cardboard box. If a transport securing device is attached (GSV 400 and GSV 450 only) to the bottom of the fan to hold the motor and impeller in place, do not remove the transport securing device before the fan is ready for immediate installation.
Remove the transport securing device (if present) holding the motor shaft and impeller in place. Place the exodraft fan on the neoprene gasket centered over the cutout. Fig. 2 Open the fan and secure the fan onto the adapter, through the pre-drilled holes in the bottom, with lag bolts or self-tapping sheet metal screws, one at each corner.
If any of the original wire supplied with the system must be replaced, use similar wire of the same tem- perature rating. Otherwise, insulation may melt or degrade, exposing bare wire. 4.2 Wiring diagram for GSV 200-315 The connection diagram below shows how the fan is connected to the fan speed control and the power source (see fig. 6).
• US 3001391_US_Grease_Fan_GSV200-450_171114 4.3 Wiring diagram for GSV 400-450 The connection diagram below shows how the fan is connected to the power source (see fig. 7). Use a 3-conductor wire of min. 14 AWG with ground. Wiring must be run outside the duct, but can run between the duct and the roof curb.
Apply power and check that the impeller is rotating in the direction of the arrow on the side of the top motor cover. All exodraft fans run in a clockwise direction when viewed from the top. Double check if three phase motor is tested on temporary wiring.
6. Maintenance and troubleshooting 6.1 Maintenance intervals The exodraft Grease Fan is designed for prolonged use. For dirty or grease-laden exhaust, inspect the impeller after (3) months and set up a periodic inspection based on these findings. Clean as required.
• US 3001391_US_Grease_Fan_GSV200-450_171114 6.3 Spare parts ordering When ordering spare parts, please have the model number and part position number available White 01 Motor 21 Motor housing insulation 02 Motor mounting plate 22 Screw - SS (2) 03 Screw - SS (2) 23 Washer - SS (2) 04 Washer - SS (2) 24 Screw - SS...
Page 12
Distributor in USA & Canada P: 770.587.3238 ENERVEX Inc. F: 770.587.4731 1200 Northmeadow Pkwy. T: 800.255.2923 Suite 180 info@enervex.com Roswell, GA 30076 www.enervex.com www.exodraft.com...
