- Page 1 Original Operating Instructions MAB 465 WWW.CSUNITEC.COM...
- Page 2 Fig. 1 Fig. 2 WWW.CSUNITEC.COM...
-
Page 3: Table Of Contents
Dispose of the device via communal collection points. The lubricant used can contain substances dangerous to the environment. Dispose of the lubricant according to local regulations. Observe the disposal instructions from the lubricant manufacturer. MAB 465 WWW.CSUNITEC.COM... -
Page 4: General Instructions
If the situation is not avoided, it may lead to material damage. ► Follow the instructions in this warning to avoid material damage. NOTE ► A note indicates additional information that simplifies the use of the machine. MAB 465 WWW.CSUNITEC.COM... -
Page 5: Safety
■ Pay attention to cleanliness at the workplace. ■ Keep the machine clean, dry and free of oil and grease. ■ Follow the instructions on lubricating and cooling the tool. MAB 465 WWW.CSUNITEC.COM... - Page 6 Risk of losing one or more fingers. ► Remove loose jewellery before begin- ning work. ► Wear a hair net if you have long hair. MAB 465 WWW.CSUNITEC.COM...
- Page 7 ► Check that the tool is tightened securely before using (see section “Inserting the tool”). ► Do not allow the connecting cable to hang over edges (trip effect). MAB 465 WWW.CSUNITEC.COM...
- Page 8 ■ Allow the machine to run at idle for ("restart protection"), the machine must be approx. 2 minutes. switched on using the ON/OFF switch. The machine is then ready for operation again. MAB 465 WWW.CSUNITEC.COM...
-
Page 9: Components / Delivery
Direction of rotation switch Also wear the following protective equip- ment during special work: Scope of supply Symbol Meaning Machine MAB 465 Helmet for protecting your head Hexagonal offset screwdriver, size against falling objects SW 4 ZAK 075 ejector pin... -
Page 10: Before Using For The First Time
(D) supplied. ► Check the safety chain for proper function before every use. A dam- aged safety chain must not be used. Replace a damaged safety chain immediately. MAB 465 WWW.CSUNITEC.COM... - Page 11 Steel with low thickness When drilling into low thickness steel, an additional steel plate (minimum dimensions 100 x 200 x 20 mm) must be placed under the workpiece. Secure the steel plate to prevent it from falling. MAB 465 WWW.CSUNITEC.COM...
- Page 12 Tighten both hexagonal socket screws ‹ in the tool mount with the Allen wrench (A) supplied. Removing the tool Untighten both hexagonal socket ‹ screws in the tool mount with the Allen wrench (A) supplied and remove the tool from below. MAB 465 WWW.CSUNITEC.COM...
-
Page 13: Using
Deactivating the magnetic clamp Hold the handle tightly (10) to stop the ‹ machine from slipping. Switch the magnet (23) ON/OFF ‹ switch off. The indicator lamp in the magnet (23) ON/OFF switch extin- guishes. MAB 465 WWW.CSUNITEC.COM... - Page 14 Spray the drill on the inside load. and outside before drilling. In the case of larger drill depths, repeat this procedure. ► Make sure that swarf is removed regularly. With larger drilling depths, break up the swarf. MAB 465 WWW.CSUNITEC.COM...
- Page 15 ► When reaming and counter-sinking, observe the limits stated in the techni- ► Make sure that swarf is removed regu- cal data for the tools to be used. larly. With larger drilling depths, break up the swarf. MAB 465 WWW.CSUNITEC.COM...
-
Page 16: Eliminating Blockages
‹ NOTE Clean the guide of the machine slide. ‹ ► The BDS range of accessories Put the machine and accessories into ‹ includes special devices (e.g., the transport case. POW 200) for removing swarf. MAB 465 WWW.CSUNITEC.COM... -
Page 17: Storage
BDS or by an au- thorised specialist workshop. Unauthorised repairs will invalidate the guarantee. Customer service/service Should you have any questions on custom- er service/service, please contact BDS.We will be happy to give you the address of your nearest service partner. MAB 465 WWW.CSUNITEC.COM... -
Page 18: Troubleshooting
The lubrication system does Lubricant tap closed. Open the lubricant tap. not function. Connecting nipple clogged. Clean the tank and nipple. NOTE ► If you cannot resolve the problem with the steps described above, please contact customer service. MAB 465 WWW.CSUNITEC.COM... -
Page 19: Technical Data
Technical data Technical data Model MAB 465 Dimensions (L x W x H) 295 x 178 x 598 Magnetic foot (L x W x H) 168 x 84 x 41,5 Approx. net weight. 230 V / 50-60 Hz Operating voltage (see type plate) -
Page 20: Ec Declaration Of Conformity
D-41063 Mönchengladbach We hereby declare that the product: Magnetic core drilling machine Model: Model MAB 465 conforms to the following relevant regulations: EC Directive 2006/42/EC on machinery ■ The following harmonised standards were applied in whole or in part: ●... - Page 21 Fig. 3 B, C WWW.CSUNITEC.COM...
- Page 22 CS Unitec 22 Harbor Ave, Norwalk, CT 06850 4330 Center St., Deer Park, TX 77536 Tel: 1-800-700-5919 (US/CA) +1-203-853-9522 (Intl.) Internet: www.csunitec.com E-mail: info@csunitec.com WWW.CSUNITEC.COM...
