Genasun GV-10 Manual

Solar charge controllers with maximum power point tracking, 10.5a/140w
Hide thumbs Also See for GV-10:

Advertisement

Quick Links

www.genasun.com
GENASUN
c/o BLUE SKY ENERGY
2598 FORTUNE WAY • SUITE K
VISTA, CA 92081 • USA
IMPORTANT SAFETY INSTRUCTIONS | SAVE THESE INSTRUCTIONS
GV-10 Manual
Solar Charge Controllers with Maximum Power Point Tracking
For models:
GV-10-Pb-12V:
GV-10-Pb-CV:
GV-10-Li-12.5V:
GV-10-Li-14.2V:
GV-10-Li-16.7V:
GV-10-Li-CV(**.*V):
10.5A / 140W
(see specs p.7 for the max. power of Li-ion versions.)
GENASUN GV-10 (ALL MODELS) MANUAL, REVISION 2.0 | 01.2018
12V Lead-Acid/AGM/Gel/Sealed/Flooded
12V Custom Multi-Stage Lead-Acid/AGM/Gel/
Sealed/Flooded
11.1V (3s) Lithium Cobalt/Polymer
12V (4s) Lithium Iron Phosphate
14.8V (4s) Lithium Cobalt/Polymer
Custom CC/CV or Multi-Stage Lithium Variation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-10 and is the answer not in the manual?

Questions and answers

Summary of Contents for Genasun GV-10

  • Page 1 (see specs p.7 for the max. power of Li-ion versions.) GENASUN c/o BLUE SKY ENERGY 2598 FORTUNE WAY • SUITE K VISTA, CA 92081 • USA GENASUN GV-10 (ALL MODELS) MANUAL, REVISION 2.0 | 01.2018 IMPORTANT SAFETY INSTRUCTIONS | SAVE THESE INSTRUCTIONS...
  • Page 2: Safety Instructions

    ÉCLAIRÉES. CAUTION for the GV-10-Pb (Lead Acid Versions Only): INTERNAL TEMPERATURE COMPENSATION. RISK OF FIRE, USE WITHIN 0.3 m (1 ft) of BATTERIES. Lead-acid batteries can create explosive gases. Short circuits can draw thousands of amps from a battery. Carefully read and follow all instructions supplied with the battery.
  • Page 3: Inspection And Maintenance

    Grounding is not necessary for operation and is at the user's discretion. If the GV-10 is to be used with a solar array electrically connected to earth ground, please note the following: WARNING: THIS UNIT IS NOT PROVIDED WITH A GFDI DEVICE. Consult Article 690 of the National Electrical Code (or the standards in force at the installation location) to determine whether a GFDI is necessary for your installation.
  • Page 4: Selecting The Battery Type

    Please consult the specification table at the end of this manual to BATTERIES: determine the best setting for your battery type. To change your GV-10 controller to the “FLOODED” setting, unscrew the four screws on the bottom of the controller, remove the top, and install the supplied jumper on the 6-pin connector as shown in diagram 1.
  • Page 5: Connecting The Battery

    PANEL first will not damage the GV-10, we recommend connecting the panel first. This eliminates the risk of short-circuiting the panel while the GV-10 is operating, which can cause damage. • In most applications, the panel should be connected only to the GV-10.
  • Page 6: Status Indication

    Status Indication: ERROR INDICATION Overheat: The controller’s internal temperature is too high. SETS OF 2 RED BLINKS. The GV-10 has a MULTICOLOR Overload: This could be caused by changing the solar RUN/CHARGE INDICATION panel connections while the controller is operating.
  • Page 7: Specifications

    The GV-10 will not operate without a battery. If the system appears to be overcharging or the GV-10 will not begin charging, ensure that the solar panel is wired only to the GV-10. If the GV-10 does not appear to be charging, note that the GV-10 waits up to one minute before trying to restart if is has shut down due to lack of power from the solar panel.
  • Page 8 Certifications: Copyright © 2018 Genasun. All rights reserved. Changes are periodically made to the information herein which will be incorporated in revised editions of this publication. Genasun may make changes or improvements to the product(s) described in this publication at any time and without notice.
