Overview

Launch the Mondopad software

1) Turn on the Mondopad device.
2) Your Mondopad device has been pre-installed with Mondopad software. Once the Mondopad device is turned on,
the behavior of the Mondopad software varies depending on how the Mondopad device was configured within your
organization and whether local administration rights have been defined.
If the Mondopad home page displays:
Begin using the software.
•
If the Windows logon screen displays:
a. Log on using a valid user account name and password. The Mondopad logon screen appears.
b. Type the same user account name and password into the Mondopad logon screen. The Mondopad home page
appears.
If the Windows desktop displays:
Tap the Mondopad icon
•
The Mondopad home page appears.
If a Windows or Mondopad registration page displays: Contact your administrator. Your Mondopad device has
not been configured.

Touch screen techniques

Tap: Quickly touch the screen once with your finger or stylus. This action is the same as single-clicking the left button of a
mouse.
Double-tap: Quickly touch the screen twice with your finger or stylus. This action is the same as double-clicking the left
button on a mouse.
Pan: Touch the screen and move your finger in the direction you want to scroll through the image, document, or page.
Swipe: Touch the screen and swipe your finger in the direction you want to move through the document or through the
folder images.
Two-Fingered Swipe: Using two fingers, touch the screen and swipe your fingers left to add a page to your Whiteboard,
right to go to the previous Whiteboard page, up to increase the Whiteboard page size, or down to scroll up the Whiteboard
page.
Drag and Drop: Touch the screen with your finger and hold it until a copy of the file or folder is visible. Without lifting your
finger, move your finger across the screen to the location you want to drop your file or folder. Lift your finger.
Zoom In: Using two fingertips, touch the screen and move your fingertips closer together to decrease the image or docu-
ment size.
Zoom Out: Using two fingertips, touch the screen and move your fingertips away from each other to increase the image
or document size.
NOTES:
• Avoid placing objects within 1/4" (6mm) of the touch screen, such as shirt sleeves, the palm of your hand, pens, and
non-pointing fingers. These objects interfere with touch screen commands.
• When using a pointing device, make certain that it does not scratch or damage the touch screen surface.
Mondopad v2.0 Software Guide
or launch the software through Start > All Programs > InFocus > Mondopad.
Page 5
