Starboard Side Control
Module Cable Installation
(Outboard Models 250 HP
3.4 Litre and Above)
Before tightening cable fastener locknut, be sure that
pin (on end of cable fastener) is completely thru cable
end and shift/throttle lever. A pin, that is partially thru
cable and lever, may cause fastener to bend when
locknut is tightened.

Shift Cable

a -
Cable Fastener Locknut
b - Cable Fastener
c - Shift Cable
d - Cable Anchor Barrel
IMPORTANT: Cable fastener (b) must be relocated to
position as shown.
Torque shift cable fastener locknut to
2.8
to N.m.)

Throttle Cable

20-25 (2.3
Ibs. in.
-6-
a - Cable Fastener Locknut
-
b Cable Fastener
-
c Throttle Lever
d Spacer (From Parts Bay)
-
e Throttle Cable
f - Cable Anchor Barrel
Torque throttle cable fastener locknut to 20 to 25 Ibs
)
in. (2.3 to 2.8 N m
a
Screws
b Cable Retainer
C Access Cover
Position access cover and cable retainer onto back
side of control and secure both to control with 2
Torque access cover and cable retainer screws
screws.
to 60 Ibs. in. (7 N.m.)
