OWNERS MANUAL

Two Stroke Dirt Bike

Distributed by SSR Motorsports

Address: 12825 Alondra Blvd, Norwalk CA 90650

www.ssrmotorsports.com

Please note that this is a general manual. The model of the vehicle

you have may differ from the picture shown in this manual.

Need help?

Do you have a question about the SX50 and is the answer not in the manual?

Questions and answers

Summary of Contents for SSR Motorsports SX50

Page 1: Owners Manual
OWNERS MANUAL Two Stroke Dirt Bike Distributed by SSR Motorsports Address: 12825 Alondra Blvd, Norwalk CA 90650 www.ssrmotorsports.com Please note that this is a general manual. The model of the vehicle you have may differ from the picture shown in this manual.
Page 2 Instructions Please read this owner’s manual carefully before using this product! This is very important! It’s required for driver’s safety and vehicle’s maintenance! If the rider is without safety awareness or driving experiences, please drive under the adult’s supervision! This is most important! It’s very important for your safety. This product is recommended for riders of 12 years old or over.
Page 3 Safety warning 1. This vehicle is not a toy. 2. Children must be trained before operating this vehicle. 3. Be sure of children's ability to avoid injury. This is very important. 4. Children must understand the manual and the importance of warnings in the manual. 5.
Page 4 step: Please install the rear shock absorber, and tighten nuts on both sides with 25N.m force. step: Please install the front tire (make sure the tread pattern and cycle valve outside), and tighten the nuts with force between 35N.m ~ 45N.m. step: Please install the handlebar (adjust to proper angles), and tighten the nuts with force between 15N.m ~ 25N.m.
Page 5 Tire gauge The proper tire pressure can provide the maximum stability and performance. Check and adjust the tire pressure regularly, to make sure the pressure is correct. To find the tire size and standard pressure, please check parameter list and warning label on the vehicle.
Page 6 Tool bag inspection Check whether tool bag is taken every time before riding. The tool bag is equipped with some professional tools. You can use them when needed. Self-protection inspection Self-protection inspection is to help ensure a safe and fun riding experience. Please wear the proper protective clothing to ensure your safety.
Page 7 6. Do not make dangerous movements while riding to ensure safety. Parking 1. Turn back the throttle and brake at the same time. 2. Parking function is recommended to avoid sliding. Cleaning After every ride, the rider should clean the vehicle. Always place the vehicle on flat surface to clean, and then check.
Page 8 Engine maintenance: After every riding, please close the switch of carburetor and fuel. Release the fuel. This is very important. If you don’t do it accordingly, the vehicle will not be easy to start after it has been placed for a long time, or carburetor will leak. Maintenance list (Please operate according to maintenance list) I: Inspection, Maintenance or lubricant replacement C: Cleaning L: Add lubricant...
Page 9 Warning labels plate Key switch Rear Brake Fuel shut off valve Pull Starter Carburetor choke PRODUCT NAME DIRT BIKE PRODUCT MODEL SX50 LENGTH X WIDTH X HEIGHT 1200×600×810 ENGINE MODEL 1E44F-6 (mm) AXLE BASE (mm) BORE×STROKES 44.015×33±0.06 WHEEL BASE (mm) DISPLACEMENT (ml) 50.53...
Page 10 FRONT/REAR TIRE 2.50—10 DRIVE MODE CHAIN DRIVE SPECIFICATION RONT/REAR TIRE PETROL MIXED LUBRICATION MODE PRESSURE LUBRICATE FRONT/REAR RIM TYPE ALLOY RIM COOLING MODE AIR-COOLED HEADLIGHT SPECIFICATION FUEL GRADE MIXTURE RATIO PRIMARY REDUCTION RATIO 3.20 1:25 FUEL &LUBRICANT OIL FINAL REDUCTION RATIO 4.91 LWA dB(A) DRIVE RATIO...
