Raxiom Smoked Mustang Tail Lights (99-04) - Installation Instructions

The below installation instructions work for the following products:



Raxiom Smoked Mustang Tail Lights (99-04)



Mustang Stock Replacement Taillights - Pair (99-04)



Mustang Stock Replacement Taillight - LH (99-04)



Mustang Stock Replacement Taillight - RH (99-04)

Please read through the instructions carefully before starting this project. Take the time to get all the materials together as

well as all the safety equipment.

Tools needed:



1/4 inch or 3/8 inch Drive Socket Wrench



7/16in Deep Socket (1/4 inch or 3/8 inch Drive)



Plastic Body Panel Fastener removal tool



(Two) Flat Head Screw Drivers

First thing you need to do is open the trunk and locate the plastic trunk hinge surround covering the trunk latch.

Next remove the four plastic body panel fasteners with the body panel tool. (if you have one) If not you can use two flat

head screw drivers together to pry the fasteners out.

Now remove the plastic panel from the trunk.

Here you can see the surround panel and the four fasteners, and also the center trim panel beneath it.

Table of Contents

Do you have a question about the 99-04 and is the answer not in the manual?

Page 1 Raxiom Smoked Mustang Tail Lights (99-04) - Installation Instructions The below installation instructions work for the following products:  Raxiom Smoked Mustang Tail Lights (99-04)  Mustang Stock Replacement Taillights - Pair (99-04)  Mustang Stock Replacement Taillight - LH (99-04) ...
Page 2 Next locate the push on plastic fasteners on the trunk panel behind the taillight and pull them right off of the stud. You should now be able to take out the center trunk panel. Remove it and then take the side inner trunk panels out of the car.
Page 3 Now reinstall the center plastic surround piece around the trunk latch. It’s easier to install if you put the bottom push fasteners in first to locate it, and then the top ones should go right in. Close the trunk and your done, and enjoy your new Raxiom Smoked Mustang Tail Lights (99-04)
Page 4 Here is a comparison of the new smoked light (Driver Side) to the factory light. (Passenger Side) And finally here is a comparison of the factory lights (Top) to the new Smoked lights. (Bottom)
Page 5 Installation instructions provided by AmericanMuscle customer Andrew Tamlyn 10.14.10 Find more how-tos, instructions and videos at www.americanmuscle.com!
