Marshall Amplification CODE Quick Start page 2

WELCOME TO CODE
CODE is a new generation of Marshall amplifier featuring Marshall Softube
Technology (MST). Fully programmable, CODE combines authentic modelling
of classic and contemporary Marshall tones with studio quality FX. CODE in-
corporates full Bluetooth ® control and audio streaming using the Marshall
Gateway™ App. Thank you for choosing Marshall.
GETTING STARTED
Ensure that the ON/OFF switch is set to the OFF position.
If using the CODE100H head, connect your speaker cable to the SPEAKER
output on the rear panel of the amplifier and to your speaker cabinet.
WARNING! Always ensure that mains power is switched OFF before unplugging
the speaker cabinet. NEVER use CODE100H without a speaker cabinet
connected.
Connect the supplied power cord to the rear of the amplifier before
plugging into the mains electricity supply.
Plug your guitar cable into to your guitar and into the amplifier INPUT
jack socket.
Always use a good quality screened/shielded ¼" jack to jack guitar
!
cable.
Set the MASTER volume control to zero.
Turn the amplifier ON using the ON/OFF switch.
Gradually turn the MASTER up to your desired volume level.
PRESETS
What is a Preset?
A Preset is a group of amplifier & speaker models, with tonal settings and FX:
Chorus, Delay, Reverb etc, stored to a single location within your CODE
amplifier's memory. This is like a 'snapshot' of the whole amplifier's settings
(excluding MASTER volume), which can be recalled using the PRESET
selector, the Marshall Gateway™ App, the 2-way footswitch (supplied) or with
the CODE footcontroller (PEDL-91009, sold separately).
!
CODE has 100 editable Presets.
Exploring Presets
Turn the PRESET selector to explore CODE's factory Presets.
The Preset name, number and active Sections will show on the display
screen. Take some time to listen to the factory Presets before creating your
own unique sound.
Discover how to create your own Presets in the full CODE Owner's
!
Manual at marshallamps.com
Whilst the information contained herein is correct at the time of publication, due to its policy of constant improvement and development, Marshall Amplification Plc reserves the right to alter specifications without prior notice.
CATS-00225
CODE100_OneSheet_EN V4 28_02_17.indd 2
CONTROLS
CODE's control knobs adjust GAIN, BASS, MIDDLE, TREBLE and VOLUME.
Because these settings are stored as part of a Preset, the control knobs are
inactive until used. This means that until they are turned their position is not
related to their setting within a Preset.
When you turn a control knob it becomes active. The display screen will
!
- The Marshall Team.
show the name and edited setting of whichever control you are using -
this value will change up and down as you turn the control knob.
The value shown above the edited setting is the stored setting.
Your adjusted settings will remain active until you move off the
!
current Preset. When you return to that Preset its settings will have
reverted back to what is stored.
You can QUICK STORE your setting changes at any point by pressing and
holding down the EXIT/STORE switch.
CAUTION: When you use QUICK STORE, the existing Preset will be overwritten
with your setting changes.
GET CONNECTED
Connect your iOS or Android device via Bluetooth, your MP3 player via the
dedicated MP3 mini jack socket, or your computer via USB, to stream tracks
from your music library through CODE.
Connect to your preferred audio software via USB to use CODE as a digital
recording interface.
The Bluetooth ® word mark and logos are registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Marshall Amplification Plc is under license. Other
trademarks and trade names are those of their respective owners.
Marshall Amplification Plc, Denbigh Road, Bletchley, Milton Keynes, MK1 1DQ, England.
Download the Marshall Gateway™ App, which is
available now from the App Store and Google Play,
to control CODE with your iOS or Android
device via Bluetooth.
