WebDT 390 Basic Operation Manual page 2

THE WebDT 390
The WebDT 390
(with Windows XP Operating System)
Microphone Wireless LED
Battery/Power LED
1 2
Calibration
Wireless Network Settings
Input/ Output Ports
Headphone Jack
A
B USB Ports
C DC Power Input
Button Functions
(with Windows XP Operating System)
BUTTON ACTION
Programmable
1 2 3
Programmable, launch soft (on-screen) keyboard (default)
4
Launch SAS (Secure Attention Sequence)
5 Generate Ctrl+Alt+Del keys to invoke the security windows defined under
Windows XP
Programmable,
6
Change display orientation (portrait/ landscape) (default)
Programmable, system utility menu (default)
7
2
ENGLISH
3 4 5 6 7
Battery and Power Meter
Button Management
Programmable,
8
As scanner trigger when equipped with the scanner module
Power on,
Push/release typically enters Standby mode, or Push/release exits Standby
9
mode or restarts device (software dependent)
Push and hold (over 4 seconds) invokes hardware shutdown
Stylus
8
9 Power/Battery LED Status:
A
• Blue indicates the battery is 25% to 100% charged
B
C
• Blinking blue indicates the battery is charging
• Orange indicates that the battery is between 11% to 25%
• Blinking Orange indicates that the battery is below 10%
Precautions
•
Always exercise care when operating and handling the WebDT 390.
• Do NOT apply excessive pressure to the display screen.
• We recommend using the Stylus provided to keep the screen clean.
• Avoid prolonged exposure of the display panel to any strong heat source. Wherever
possible, the WebDT 390 should face away from direct light to reduce glare.
•
If the AC-DC power adapter is used to recharge or power the device, do NOT use
any AC-DC adapter other than the one provided with the device or acquired from
the manufacturer or its partners.
•
In the unlikely event that smoke, abnormal noise, or strange odor is present,
immediately power off the WebDT 390 and disconnect all power sources. Report
the problem to your device provider immediately.
•
Never attempt to disassemble the WebDT 390, as this will void the warranty.
THE WebDT 390
Basic Features
The WebDT 390 wireless tablet integrates a bright and responsive touch display, 1 mini-
USB port, and embedded networking elements such as Bluetooth. The primary device is
complemented by a suite of accessories, including battery expansion, docking cradles,
and carrying cases, for a comprehensive user experience.
3
ENGLISH
