WebDT 312 Operation Manual

WebDT 312

SPECIFICATIONS

Display
Display Resolution
Processor
Memory (RAM)
Storage
System
Operating Systems
Network Interface
Input and Control
Buttons
Indicator
Input/Output Ports
Audio
Security
Enclosure
Protective Grips
Dimensions (H x W x D)
Weight
Battery Pack
Mechanical
AC/DC Adapter
Power Cords
Stylus
Regulatory
Operating Temperature
Humidity
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131
Copyright © 2010, DT Research, Inc. All Rights Reserved.
DT Research and WebDT are registered trademarks of DT Research, Inc.
8
ENGLISH
10.4" (diag.) TFT LCD with Resistive Touch;
outdoor-viewable option
1024 x 768 (XGA)
®
Intel Atom™ processor Z530 1.6GHz
1GB to 2GB
2GB to 16GB Internal Flash Module, 32GB to 64GB
SSD
® ®
Microsoft Windows Embedded Standard 7, Windows
®
7 Professional, Windows XP Embedded, Windows
Pro for Embedded Systems or Linux
Bluetooth 2.0
1 Power button, 7 Front buttons and
1 Trigger button
1 Power/ Battery status LED and 1 WLAN active LED
1 DC-in Jack; 1 Microphone-in and
1 Headphone-out Jacks; 2 USB 2.0 port
Built-in speakers
WPA-Personal, WPA2-Personal, WPA-Enterprise,
WPA2-Enterprise, AES-CCMP 128-bit, WEP 128-bit and
64-bit; 802.1X: EAP-SIM, LEAP, PEAP, TKIP,
EAP-FAST, EAPTLS, EAP-TTLS
ABS + PC Plastic and Magnesium-aluminum alloy
Rubber with handstrap, added drop protection
8.3 x 10.3 x 0.8 (in); 210 x 261 x 18 (mm)
2.05 lbs (0.93 kg)
Internal (2S2P; 7.4V, 2200mAh) or (2S2P; 7.4V,
3760mAh) Optional: External (2S2P; 7.2V, 3900mAh)
Input: 100 – 240VAC / Output: 19V DC@2.36A
North America, EU, UK, China and Japan
Non-electronic tip
FCC Class B, CE, C-Tick, RoHS compliant
Operation: 0°C - 40°C / Storage: 0°C - 60°C
0% - 90% non-condensing
http://www.dtresearch.com
WebDT 312
®
®
XP
BASIC OPERATION GUIDE
INTRODUCTION
Thank you for acquiring the latest addition to
DT Research's line of tablet devices— the WebDT 312.
Featuring a slim yet robust enclosure, the two-pound
WebDT 312 with 10.4" TFT display is powered by the
Intel® Atom™ processor, offering optimal combinations of
performance and power savings. An external
battery expansion option provides approximately 3-4 hours of additional battery
operation for up to six hours of mobile usage.
The WebDT 312 is available in Microsoft® Windows® Embedded Standard
7, Windows® 7 Professional, Windows® XP Embedded, Windows® XP Pro for
Embedded Systems or Linux operating systems. Each software operating
system features web browser, client/ server computing software, media player,
accessories, and applications support.

PACKAGE CONTENTS

• One WebDT 312 with Internal Battery Pack (2200mAh), Stylus, Grips and Screen Cover
• AC-DC Power Adapter with Power Cord
• Basic Operation Guide
Major options, depending on configuration:
• Desktop Charging Cradle with DC-inPower Jack and Ethernet, USB and optional VGA Ports
• External Battery Pack
• Internal High Capacity Battery (3760mAh)
• External Battery Charger Kit
* If your WebDT 312 contains MSR, camera or scanner module, please refer to the POS
module operation guide for detailed operation.
