Samsung SyncMaster 204B User Manual page 68

If the signal transferred from the computer is the same as the following Preset Timing Modes, the
screen will be adjusted automatically. However, if the signal differs, the screen may go blank while
the power LED is on. Refer to the video card manual and adjust the screen as follows.
Table 1. Preset Timing Modes
Display Mode
VESA,1600X1200
IBM,640X350
IBM,720X400
IBM,720X400
VESA,640X480
VESA,640X480
MAC,640X480
MAC,832X624
VESA,800X600
VESA,800X600
VESA, 800X600
VESA,800X600
VESA,1024X768
VESA,1024X768
VESA,1024X768
VESA,1152X864
MAC,1152X870
VESA.1280X960
VESA,1280X1024
Horizontal Vertical
Frequency Frequency
(kHz)
75.000 60.000
31.469 70.086
31.469 70.087
31.469 59.940
37.861 72.809
37.500 75.000
35.000 66.667
49.726 74.551
35.156 56.250
37.879 60.317
48.077 72.188
46.875 75.000
48.363 60.004
56.476 70.069
60.023 75.029
67.500 75.000
68.681 75.062
60.000 60.000
79.976 75.025
Horizontal Frequency
The time to scan one line connecting the right edge to the left edge of
the screen horizontally is called Horizontal Cycle and the inverse
number of the Horizontal Cycle is called Horizontal Frequency. Unit:
kHz
Vertical Frequency
Like a fluorescent lamp, the screen has to repeat the same image
many times per second to display an image to the user. The
frequency of this repetition is called Vertical Frequency or Refresh
Rate. Unit: Hz
Pixel Clock
(MHz)
(Hz)
162.000
25.175
28.322
25.175
31.500
31.500
30.240
57.284
36.000
40.000
50.000
49.500
65.000
75.000
78.250
108.00
100.00
108.00
135.00
Sync Polarity
(H/V)
+/+
+/-
-/+
-/-
-/-
-/-
-/-
-/-
+/-,+/-
+/+
+/+
+/+
-/-
-/-
+/+
+/+
-/-
+/+
+/+
