- Page 1 FULL HD VIDEO SECURITY SYSTEM Quick Start Guide...
-
Page 2: Troubleshooting
Troubleshooting If you are experiencing video loss, verify that all cables are properly and securely connected to the DVR. • Check your Network Connection • Check your Username and Password • Restart the DVR if you have trouble connecting. Main Menu > Shutdown > Enter Username & Password > Click “Reboot” To reset your DVR to factory settings, refer to the User manual. -
Page 3: Dvr Setup
DVR Setup KIT Model SDH-B73023BF/SDH-B73043BF/SDH-B74043BV/SDH-B74043DF/SDH-C74083HF/SDH-C75083BF/ SDH-C75123BF/SDH-ST341/SDH-ST581 DVR Model SDR-B73303/SDR-B74303/SDR-B75303 • 4CH DVR CAUTION RISK OF ELECTRI SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK DO NOT OPEN COVERS. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. - Page 4 DVR Setup CAUTION RISK OF ELECTRI SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK DO NOT OPEN COVERS. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING : TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE UNITS NOT SPECIFICALLY DESIGNED FOR OUTDOOR USE TO RAIN OR MOISTURE.
- Page 5 Connect one end of the Ethernet cable into your router’s LAN port, and the other end of the cable to the Ethernet port on the rear panel. CAUTION RISK OF ELECTRI SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK DO NOT OPEN COVERS.
- Page 6 Startup Wizard Guide Once the setup is complete, the DVR will power on and display the Startup Wizard. Click “Next”. Right-click on the mouse within the text box for the digital keyboard to create a Username and Password for your DVR. Retype password. Click “Next”. Password MUST be 8-13 characters long. • If the password is 8~9 characters long, it should contain a combination of letters, digits and special symbols.
- Page 7 New Hard Disk Drive(s) (HDD) must be formatted before use. Click “Select” to choose the unformatted HDD listed under HDD Management. Select Off/Auto to Overwrite HDD. Click “Format HDD”. When done format- ting HDD, Click “Next”. For more information, refer to the User Manual. Video Recording Schedule Select the channel and type of scheduled recording mode, Normal or Motion.
- Page 8 Startup Wizard Guide General System Configuration. Set the date, time, date format, time format, language, video format, and menu timeouts for the DVR. Click “Next”. To remotely access recordings via the Wiseview app or port forwarding, you must connect the DVR to the router using an Ethernet cable.
- Page 9 Optional Steps Enable/Disable Email Setting to send or receive email alerts from your DVR. DDNS : To use the web viewer to access your DVR, refer to the User Manual for further instructions. Setting this up will enable you to do port forwarding, where you can access your videos and camera recordings from any computer, anywhere.
-
Page 10: Main Interface
Main Interface 5 6 7 8 9 10 10_ English... - Page 11 Camera Type "A" means "AHD camera". Absence of it means 960H camera. Date & Time Displays current date and time. Channel Name Displays channel name. SAMSUNG Logo Samsung logo is displayed only when there is video loss. Image Capture Capture snapshots of current live feed. Manual Recording Enable/Disable Manual Recording.
- Page 12 Remote Viewing App Once you’ve set up your system, you can install the WiseView app for remote viewing and access to your cameras from anywhere, anytime. Open Google Play or the App Store and download the free Wiseview app. Once installed, open the WiseView app. Tap the dropdown menu and select Device Tap [+] to add a new device.
-
Page 13: App Interface
App Interface Live view of Playback recordings View recorded video connected cameras footage View captured View the device(s) For more information images connected to the app about the app and add new device(s) English _... - Page 14 App Interface Main Menu Device List 4/6/8/9/16 Split Screen Capture Record Video Stream Mode Start/Stop Live Stream Mute On/OFF Screen Size Format: Stretching, Original, 4:3, and 16:9 14_ English...
- Page 15 Camera Installation Template To make camera installation easier, you can tear off this page and adhere it to the place you would like to install your cameras. TEMPLATE This template is used to install the camera on the wall Screw holes for the Camera installation CAMERA FRONT...
