SCREEN

In each of the four modes, the following data is displayed:
Pyramid mode: LIVE STEP TRACK SEQ
Track name: name of the current track.
Track zoom: zoom of the current track (/4, /2, x1, x2, x4,
x8, x16).
Track time signature: time signature of the current track
(from 1/1 to 24/16).
MIDI in flashes if a MIDI message is received;
A, MIDI out B and USB out
is sent.
Current track: track number and bank (A, B, C, D) in Live
and Step Modes.
Track out sequence number and the tracks you are editing
in TRACK mode. Can also display the next sequence to
be played in the chain.
Current sequence: shows the playing sequence (and so
the group of tracks you are editing in TRACK mode).
Can also display the next sequence to be played in the
chain.
Mode zone: highlights the main parameters of each
mode, which generally can be edited via the clickable
data encoder .
MIDI out
flash when a MIDI message
Player zone: track player (a representation of the current
track, the level of zoom, the track length), the player posi-
tion, and the page you are viewing in Live, Step and Track
modes:
The example above shows a 12 and 1/4 measure long track
(12 measures + 1 beat). The four outlined squares represent
the first page of the track. The arrow icon indicates the player
is currently at the twelfth measure.
In SEQ mode the
Player zone
In the example above, 6 sequences are chained and SE06
(highlighted) will play 2 measures.
the set sequence chain:
