Quick Start Guide

ENGLISH
1
EN Connect the fiber optic cable from your service
provider's network to the PON port.
Warning! To avoid possible eye injury, do NOT
look into an operating fiber-optic module's
connector.
2 Connect a phone to the phone port using the phone cable.
3 Connect a computer to the LAN port using the yellow
Ethernet cable.
Connect the power cable to the modem and press the
4
power button.
Note: Only use the USB port for file sharing.
EN
5 Make sure the LEDs are on and check the status.
Configuring your PMG5317-T20B
Open a web brower and go to http://192.168.1.1
Enter the default User Name (admin) and Password (1234), then
click Login.
1/2
Wireless N GPON HGU with 4-port

Hardware Connections

1
PON
1
5
2
WLAN/
USB PHONE
WPS
On: Linked successfully.
Blinking: Trying to link up.
PON
Off: Link off.
On : Linked successfully. (Any LAN port)
1
Blinking: Data transmitting.
LAN
Off : Link off.

Internet Setup

http://192.168.1.1
User Name : admin
Password : 1234
(default)
PMG5317-T20B
GbE Switch and USB
PHONE LAN
2 3
1
4 3 2 1
LAN INTERNET
On : Registered to IMS but no voice
1 communication.
Blinking: Voice on communication.
PHONE
Off: No registered SIP accounts to this line,
or device power off.
On: Power on and system ready.
Off: Power off.
POWER
PMG5317-T20B
User Name
Password
POWER ON
POWER
4
PON ALM BATT POWER
admin
1234
Login
