User Manual
P-663HN-51
802.11n ADSL2+ Bonded 4-port
Gateway
Version 1.01
Edition 1, 7/2009
DEFAULT LOGIN DETAILS
IP Address:
Username:
Password:
www.zyxel.com
http://192.168.1.1
admin
1234
2009 ZyXEL Communications Corporation
C
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ZyXEL Communications P-663HN-51
Summary of Contents for ZyXEL Communications P-663HN-51
- Page 1 P-663HN-51 802.11n ADSL2+ Bonded 4-port Gateway Version 1.01 Edition 1, 7/2009 DEFAULT LOGIN DETAILS IP Address: http://192.168.1.1 Username: admin Password: 1234 2009 ZyXEL Communications Corporation www.zyxel.com...
-
Page 2: Hardware Connections
ENGLISH Hardware Connections... - Page 3 1. Point the antenna up. 2. DSL: Use the included DSL Y-cable. Connect the part where the two cables come together to the P- 663HN-51’s DSL port. Connect the DSL1 end of the Y-cable to the wall jack for your first DSL line. Connect the DSL2 end of the Y-cable to the wall jack for your second DSL line.
-
Page 4: Internet Access
Internet Access 1. Enter the default IP address http://192.168.1.1 in your browser. Then type the user name (admin by default) and password (1234 by default) in the login screen. Click OK. 2. The Device Info screen displays. Click Advanced Setup to open the WAN setup screen. - Page 5 3. Click Add. Use the following screens to configure your Internet connection. 4. If you are using 2 DSL lines you are done configuring for Internet access. If you are using only 1 DSL line, go to Advanced > DSL and select Single Line Enable and click Save/Reboot.
- Page 6 Set Up a Wireless Connection 1. Place the devices close to one another. 2. Press the WPS button on the P-663HN-51 rear panel for 5 seconds and release it. The WLAN/WPS light blinks. 3. Within 2 minutes, press the WPS button on a compatible device (such as the NWD-270N).
