INSTEON SignaLinc RF Quick Start Manual

Quick-Start Guide
SIGNAL ENHANCERS
SignaLinc RF (#2442P)
TM
Two Signal Enhancers are required in each home with INSTEON
enabled products.
Signal Enhancers repeat all INSTEON messages, thereby ensuring
a highly reliable INSTEON Network.
N N e e e e d d H H e e l l p p ? ? F F o o r r a a s s s s i i s s t t a a n n c c e e c c a a l l l l y y o o u u r r f f r r i i e e n n d d l l y y
s s u u p p p p o o r r t t p p e e r r s s o o n n @ @ 8 8 6 6 6 6 - - 2 2 4 4 3 3 - - 8 8 0 0 1 1 8 8

PART ONE: Installing Two Signal Enhancer Interfaces

S S t t e e p p 1 1 . .
Plug the f f i i r r s s t t Signal Enhancer into a convenient wall outlet.
S S t t e e p p 2 2 . .
Point your Signal Enhancer's antenna towards the floor or ceiling.
S S t t e e p p 3 3 . .
On the f f i i r r s s t t Signal Enhancer press and hold the SET button for 10 seconds and release.
The Signal Enhancer's LED will b b l l i i n n k k f f a a s s t t ( ( 4 4 t t i i m m e e s s p p e e r r s s e e c c o o n n d d ) ) and will continue to blink until you complete step 7. If it
does not blink, try again and don't let up too soon — 10 seconds is a pretty long time!
S S t t e e p p 4 4 . .
Plug the s s e e c c o o n n d d Signal Enhancer into another outlet.
S S t t e e p p 5 5 . .
Point your Signal Enhancer's antenna towards floor or ceiling.
S S t t e e p p 6 6 . .
Look at the s s e e c c o o n n d d Signal Enhancer's Status LED:
• If it is b b l l i i n n k k i i n n g g f f a a s s t t , go to step 7.
• If it is b b l l i i n n k k i i n n g g s s l l o o w w l l y y ( ( o o n n c c e e e e v v e e r r y y 2 2 s s e e c c o o n n d d s s ) ) o o r r n n o o t t b b l l i i n n k k i i n n g g a a t t a a l l l l , repeat step 4 trying another outlet.
N N o o t t e e : : Y Y o o u u m m a a y y n n e e e e d d t t o o t t r r y y s s e e v v e e r r a a l l o o u u t t l l e e t t s s . . If you are unable to locate a "fast blinking" outlet please call 866-243-8018
for assistance. If you have tried 5 outlets go back and move the first SignaLinc to another outlet.
S S t t e e p p 7 7 . .
Press and release the SET button on the f f i i r r s s t t Signal Enhancer.
The Status LED on both Signal Enhancers will stop blinking and remain steadily on.
Congratulations! You have made your home INSTEON ready.
Pass-through
Outlet
TM
Antenna
• Do not use an outlet controlled by
• Don't place near large metal
• Point the antennas on both
Set Button
Status LED
HINTS
a switch.
objects.
Signal Enhancers in the same
direction.
