- Page 1 INSTEON Range Extender INSTEON Range Extender Owner’s Manual Owner’s Manual...
-
Page 2: Table Of Contents
Contents Getting Started INSTEON Range Extender Device Overview Buttons Installation Placement Extending Your Network Bridging Electrical Legs Functionality with INSTEON Access Points Appendix Specifications Troubleshooting Certifications and Warnings Product Warranty... -
Page 3: Getting Started
Getting Started Getting Started Everything you need to quickly get up and running. Everything you need to quickly get up and running. -
Page 4: Insteon Range Extender
Status LED Opposite Phase Same Phase See Bridging Electrical Legs for functionality Set Button Installation Placement Plug Range Extender into an unswitched When extending the reach of your INSTEON wall outlet. network, locate Range Extender near your INSTEON RF device. -
Page 5: Extending Your Network
Extending Your Network Extending Your Network Use Range Extender to bridge the two legs of your home’s electrical Use Range Extender to bridge the two legs of your home’s electrical supply for increased reliability. supply for increased reliability. -
Page 6: Bridging Electrical Legs
Split-Single Phase Connect your second Range Tap the set button four times. Extender to an outlet on the other Range Extender will begin to beep. side of your home. Range Extender A Range Extender B Inspect the status LED of a second... -
Page 7: Functionality With Insteon Access Points
Access Points also utilized a dual-color red and green LED. First generation Access Points only utilized a white LED that may blink or illuminate bright or dim. Use the table below to compare LED and beeper behavior for the four Range Extender and Access Point modes when deploying differing generations of devices. -
Page 8: Appendix
Appendix Appendix Everything else you might need to know about your INSTEON product. Everything else you might need to know about your INSTEON product. -
Page 9: Specifications
Beeper, can be enabled/disabled through software Setup Memory Non-volatile EEPROM Status LED Red/Green LED INSTEON Features INSTEON Messages Repeated INSTEON Minimum Receive Level 10 mV INSTEON Minimum Transmit Level 3.2 Vpp into 5 Ohms INSTEON Powerline Device INSTEON Powerline Frequency 131.65 KHz... - Page 10 Operating Environment Indoors Operating Humidity Range 0-85% relative humidity, non-condensing Operating Temperature Range 32º to 104º F 0º to 40º C Set Button Storage Temperature Range -4º to 158º F -20º to 70º C Weight 2.24 oz 63.5 g Electrical Pass-through Outlet Power Consumption <0.75 Watts...
-
Page 11: Troubleshooting
Try this: • Test Range Extender in a different power outlet. If the LED illuminates when using a different outlet, check the original outlet for power. Some outlets are controlled by a switch elsewhere in the room. Avoid switched outlets as they disable your INSTEON device when turned off. -
Page 12: Certifications And Warnings
• Each INSTEON product is assigned a unique INSTEON I.D., which is printed on the product’s label. This device complies with FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. -
Page 13: Product Warranty
You may also have other legal rights that may vary from state to state. Protected under U.S. and foreign patents (see www.insteon.com/patents) ©2014 INSTEON Rev 07.03.14...
