FLIR DNR100 Series Quick Networking Manual

This guide will show you how to set up your system for connection over the Internet using a PC,
Smartphone, or Tablet.
Before You Start:
Make sure you have:
• A router and high-speed Internet access (not included).
• Connected the NVR to a router or switch on your network using an Ethernet cable. See the Quick
Connection Guide for details.
• A PC connected to the same network as your NVR.
• Mac users, please visit
Find Your IP and MAC Address
1
Left-click and login if prompted (Default User Name:
admin; Default Password: 000000). Click
the navigation bar.
Record your information below:
: . .
IP ADDRESS
: - - - -
MAC ADDRESS
Port Forwarding
3
Manually forward ports 80 and 35000 to the NVR's IP address.
All routers are different. To port forward your router, please refer to your router's user
manual.
An example of a port forwarding screen is shown for illustration purposes:
EXAMPLE
HTTP 80 80
Client 35000 35000
NOTE: An automatic port forwarding wizard is available from www.flirsecurity.com/pro.
Quick Networking Guide
www.flirsecurity.com/pro for instructions.
on
.
-
12
12
DNR100 Series
Network Video Surveillance Recorder
Local Connection (for PC)
2
a
Install CMS software for PC from the CD
www.flirsecurity.com/pro
or from on a
computer in the same LAN as the NVR.
b
Click Config Manager>Device Manage.
c
Click Search Device. If a Windows Firewall
alert appears, click Allow.
d Check the NVR and click Add Management.
Click Search
Device
Check the NVR
Click Add
Management
4 Register for FLIR DDNS
a
Open your web browser and go to:
http://ddns.myddns-flir.com
b Click Create Account.
c
Complete the Account Information fields
with your personal information. Complete
the Warranty Information with your purchase
details (optional).
f
DDNS User Name:
Record your
DDNS Domain Name:
information here:
DDNS Password:
e
Enter the User Name (default: admin) and
Password (default: 000000) for the NVR and
click OK.
f Click OK.
g
Click Device List. Click + next to No Group.
Double-click the NVR. Click-and-drag the NVR
h
to the display area to view.
Click Device
List
Click-and-drag the
Click + next
NVR to the display
to No Group
area to view
Double-click
the NVR
d
Complete the System Information fields:
DNR100
Product License: URL Request: <Product Code>-
Select your product Choose a URL for your <MAC Address>:
model from the DDNS connection Locate the MAC address
Product License (i.e. your name, your of your NVR.
drop down menu company or business
(i.e. DNR100). name, or anything of
your choice).
e
Once the information has been entered,
click Create New Account. Your Account
information will be sent to you at the email
Address you used in Step c.
