Important! Please Read Carefully And Save This Document.
contains important information about your combination smoke and CO alarm's operation. If you are
installing this alarm for use by others, you must leave this manual (or a copy of it) with the end user.
User's Manual
This User's Manual
NOTE: See Safe & Sound ID
and Pairing Code Label on
back cover of User's Manual.
Advertisement
Table of Contents
Related Manuals for First Alert Onelink Safe & Sound
Summary of Contents for First Alert Onelink Safe & Sound
- Page 1 User’s Manual Important! Please Read Carefully And Save This Document. This User’s Manual NOTE: See Safe & Sound ID contains important information about your combination smoke and CO alarm’s operation. If you are and Pairing Code Label on installing this alarm for use by others, you must leave this manual (or a copy of it) with the end user. back cover of User’s Manual.
- Page 2 User’s Manual Model: 1039102 Installed On Replace By...
-
Page 3: Table Of Contents
Table of Contents Welcome 4 - 5 Parts of This Alarm Smoke & Carbon Monoxide Alarm Where to Install Where Not to Install Setup and Installation 9 - 13 When the Alarm Sounds Using the Silence Feature Factory Reset Weekly Testing Regular Maintenance Alarm End of Life Ionization and Photoelectric Technology... -
Page 4: Welcome
Welcome Welcome to your Onelink Safe & Sound alarm. Thank you for choosing Onelink by First Alert for your safety needs. In addition to the alarm sounds, you can receive notifications in case of an emergency to help provide a warning of a fire or carbon monoxide while you are home or away. -
Page 5: Parts Of This Alarm
System Requirements Wireless Network Android or iOS Device Onelink Home App Required to use a 2.4 GHz wireless You can use your Onelink Safe Search and download the connection and a compatible & Sound with Android 5 or later Onelink Home app from the 802.11 b/g/n/ac router. -
Page 6: Smoke & Carbon Monoxide Alarm
Smoke & Carbon Monoxide Alarm LED Color Smoke / CO Events Voice Guide Patterns Power Up Power Up Programming, Silencing & Pairing “[Location, example: “Hallway”] Location saved.” “The testing is complete.” Testing [Test Complete - interchanging to next test/Safe & Sound out of alarm mode] Hello and welcome to your Onelink Safe &... -
Page 7: Where To Install
Where to Install Minimum coverage for smoke alarms, as recommended by the National Fire Protection Association (NFPA), is one smoke alarm on every level, and in every bedroom (See “Regulatory Information For Smoke Alarms” for details on the NFPA recommendations). For CO alarms, the National Fire Protection Association (NFPA) recommends that CO alarms be installed on every level and in the central location outside each bedroom. -
Page 8: Where Not To Install
Where Not to Install Do Not Place Your Smoke & CO Alarm: In garages, furnace rooms, crawl spaces and unfinished attics. Avoid extremely dusty, dirty or greasy areas. • Where combustion particles are produced. Combustion particles form when something burns. Areas •... -
Page 9: Setup And Installation
Setup & Installation DANGER: ELECTRICAL SHOCK HAZARD. Turn off power to the area where you will install this unit at the circuit breaker or fuse box before beginning installation. Failure to turn off the power before installation may result in serious electrical shock, injury or death. WARNING: Make sure the alarm is not receiving excessively noisy power. - Page 10 Setup & Installation (Continued) Installing the Mounting Bracket Turn off power. Step 1 Remove existing alarm and mounting bracket (if necessary). Step 2 Attach the Onelink mounting bracket to the junction box. Step 3 WARNING: Improper wiring of the power connector or the wiring leading to the power connector will cause damage to the alarm and may lead to a non-functioning alarm.
- Page 11 Setup & Installation (Continued) Installing Power Connectors If replacing an existing First Alert alarm and the power connector is in good working condition skip to the “Installing Onelink Safe & Sound” instructions. If installing the First Alert power connector: Using wire nuts, connect the white wire on the power connector to the neutral wire in...
- Page 12 Setup & Installation (Continued) Installing Onelink Safe & Sound Connect the power connector to the First Alert® alarm. Step 1 Check all connections. Make sure all plugs are completely connected and snapped together. Step 2 Ensure the Adapter Plug is securely connected to the existing Power Connector.
- Page 13 Interconnected units will only work if they are wired to compatible units and all requirements are met. This unit is designed to be compatible with most First Alert and BRK Electronics Models listed in the User’s Manual.
-
Page 14: When The Alarm Sounds
When the Alarm Sounds What to Do If Your Smoke Alarm Sounds If the unit alarms and you are not testing the unit, it is warning you of a potentially dangerous situation that • requires your immediate attention. NEVER ignore any alarm. Ignoring the alarm may result in injury or death. If the unit alarms get everyone out of the house immediately. -
Page 15: Using The Silence Feature
Using the Silence Feature The Alarm Silence Feature This feature is intended to temporarily silence the horn while you identify and correct the problem. Do not use the Silence Feature in emergency situations. It will not correct a CO problem or extinguish a fire. The Silence Feature can temporarily quiet an unwanted alarm for several minutes. -
Page 16: Weekly Testing
Weekly Testing WARNING: NEVER use an open flame of any kind to test this unit. You might accidentally damage or set fire to the unit or to your home. NEVER use vehicle exhaust! Exhaust may cause permanent damage and voids your warranty. WARNING: DO NOT stand close to the alarm when the horn is sounding. -
Page 17: Regular Maintenance
Regular Maintenance This unit has been designed to be as maintenance-free as possible, but there are a few simple things you must do to keep it working properly: Test it at least once a week. • Clean the smoke/CO alarm at least once a month; gently vacuum the outside of the smoke/CO •... -
Page 18: Ionization And Photoelectric Technology
Ionization & Photoelectric Technology This alarm uses photoelectric technology. All First Alert Onelink smoke alarms conform to regulatory requirements, including UL217 and are designed ® ® to detect particles of combustion. Smoke particles of varying number and size are produced in all fires. - Page 19 Fire Safety Tips (Continued) Basic Safety Information Keep alarms clean, and test them weekly. Replace alarms immediately if they are not working properly. Smoke alarms that do not work cannot alert you to a fire. Keep at least one working fire extinguisher on every floor, and an additional one in the kitchen.
-
Page 20: What You Need To Know About Co
What You Need to Know About CO What is CO? Carbon Monoxide (CO) is an invisible, odorless, tasteless gas produced when fossil fuels do not burn completely, or are exposed to heat (usually fire). Electrical appliances typically do not produce CO. Wood, coal, charcoal, oil, natural gas, gasoline, kerosene, and propane. -
Page 21: Potential Sources Of Co In The Home
Potential Sources of CO in the Home Like portable heater, gas or wood burning Fuel-Burning Appliances: fireplace, gas kitchen range or cooktop, gas clothes dryer. Corroded or disconnected water heater vent pipe, leaking Damaged or Insufficient Venting: chimney pipe or flue, or cracked heat exchanger, blocked or clogged chimney opening. Improper Use of Appliance/Device: Operating a barbecue grill or vehicle in an enclosed area (like a garage or screened porch). - Page 22 Potential Sources of CO in the Home (Continued) How Can I Protect My Family from CO Poisoning? A CO alarm is an excellent means of protection. It monitors the air and sounds a loud alarm before carbon monoxide levels become threatening for average, healthy adults. A CO alarm is not a substitute for proper maintenance of home appliances.
- Page 23 Regulatory Information for CO Alarms What Levels of CO Cause an Alarm? Underwriters Laboratories Inc. Standard UL2034 requires residential CO alarms to sound when exposed to levels of CO and exposure times as described below. They are measured in parts per million (ppm) of CO over time (in minutes). UL2034 Required Alarm Points*: If the alarm is exposed to 400 ppm of CO, IT MUST ALARM BETWEEN 4 &...
- Page 24 Regulatory Information for Smoke Alarms Installing Smoke Alarms in Single-Family Residences NOTE: This information is specific to the smoke and carbon monoxide alarm and is not applicable to the home automation capability. The National Fire Protection Association (NFPA), recommends one smoke alarm on every level and in every bedroom.
-
Page 25: Regulatory Information
Regulatory Information Federal Communications Commission (FCC) Compliance Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 26 Modular Devices FCC and Compliance Statements OEM Responsibilities to Comply With FCC Regulations The A76F Module has been certified for integration into products only by OEM integrators under the following condition: The transmitter module must not be co-located or operating in conjunction with any other antenna or transmitter.
-
Page 27: Special Compliance
Special Compliance Considerations This smoke alarm is suitable for use in apartments, condominiums, townhouses, hospitals, day care facilities, health care facilities, boarding houses, group homes and dormitories provided a primary fire detection system already exists to meet fire detection requirements in common areas like lobbies, hallways, or porches. Using this smoke alarm in common areas may not provide sufficient warning to all residents or meet local fire protection ordinances/regulations. - Page 28 General Limitations for Smoke/CO Alarms (Continued) Battery operated units cannot work if the batteries are missing, Smoke/CO Alarms Cannot Work Without Power. disconnected or dead, if the wrong type of batteries are used, or if the batteries are not installed correctly. If the AC power is cut off for any reason (open fuse or circuit breaker, failure along a power line or at a power station, electrical fire that burns the electrical wires, etc.).
-
Page 29: Troubleshooting Guide
Troubleshooting Guide App FAQ If the App... Problem... You Should... Is unable to be downloaded or installed. You cannot download or install the app. Contact Customer Service Team Alarm FAQ If the Alarm... Problem... You Should... Light flashes yellow and Horn sounds Units under warranty should be returned three “chirps”... -
Page 30: Limited Warranty
Limited Warranty BRK Brands, Inc., (“BRK”) the maker of First Alert brand products warrants that for a period of three years from the date ® of purchase, this product will be free from defects in material and workmanship. BRK, at its option, will repair or replace this product or any component of the product found to be defective during the warranty period. -
Page 31: Copyright And Technical Specifications
Copyright and Technical Specifications ©2018 BRK Brands, Inc. All rights reserved. Distributed by BRK Brands, Inc., Aurora, Illinois 60504. BRK Brands, Inc. is a subsidiary of Newell Brands Inc. (NYSE:NWL). Printed in USA. Apple HomeKit Apple, iPhone, iPad, iPad Air, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. - Page 32 ©2018 BRK Brands, Inc. All rights reserved. • Distributed by BRK Brands, Inc. BRK Brands, Inc. is a subsidiary of Newell Brands Inc. (NYSE:NWL) 3901 Liberty Street Road, Aurora, IL 60504-8122 Customer Service Team: 1 (833) ONE-LINK (1-833-663-5465) • onelink.firstalert.com 06/18 •...
