Summary of Contents for A4Tech BT-630
- Page 1 Bluetooth Mouse User Guide Model: BT-630 www.a4tech.com...
- Page 2 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
-
Page 3: Package Contents
Package Contents 1. Bluetooth Mouse 2. 1*AA Battery 3. Quick Set Up Guide 4. CD (CD User Manual) Features 1. Bluetooth V2.0, 10 meter range 2. 1000DPI 3. Four stages power saving mode, low battery warning 4. 8 in Right software, innovative 4D wheel System Requirement : Windows XP/Vista /Windows7 Know your product... -
Page 4: Battery Installation
Turn On/Off Mouse 1. Slide on the power switch to immediately turn on the mouse. 2. To turn off the mouse, just slide off the power switch and then LED light is off immediately. Battery Installation Open battery cover and insert the supplied AA battery. Please make sure that the positive (+) and negative (-) ends of the battery match the polarity indicators inside the battery compartment. -
Page 5: Bluetooth Software: Microsoft
Bluetooth Bluetooth Bluetooth Bluetooth Bluetooth Device Support Software Software Device Not Device In Already Version Vendor Name Inserted Working Inserted Windows Windows XP(SP2) Microsoft Bluetooth Above Broadcom Widcomm V4.0 Above BlueSoleil V5.0 Above Toshiba Bluetooth Stack V3.0 Above Mac OS X Mac OS X Apple 10.4~10.5... - Page 6 Step 3 ： Turn on the mouse and press the Step 4：After the device names appear,click connection button at the bottom of mouse until Bluetooth Mouse, and then click Next. the LED Indicator in the middle wheel blinks alternately in Red and Green. In the Add Bluetooth Device Wizard, select the My device is set up and ready to be found check box, and then click Next.
-
Page 7: Bluetooth Software: Widcomm
Bluetooth Software: WIDCOMM Step 2：In popped Initial Bluetooth Configuration Step 1：Right click on Bluetooth icon located at system tray, then select Add a Bluetooth Wizard, Click Next. Device. Step 3 ： Turn on the mouse and press the Step 4：After the device names appear,click connection button at the bottom of mouse until BlueTooth Mouse, and then click Next. - Page 8 Bluetooth Software: BLUESOLEIL Step 2：Double click orange circle button to start Step 1：Right click on Bluetooth icon located at system tray, then select Add a Display Classic searching Bluetooth devices. View. Step 3 ： Turn on the mouse and press the Step 4：Right click on the mouse icon and select connection button at the bottom of mouse until Connect Bluetooth Human Interface Device.
- Page 9 Step 5：The Bluetooth mouse will automatically complete the connection. The bluetooth mouse has successfully installed while the LED Indicator in the middle wheel stops blinking. — 8 —...
- Page 10 Bluetooth Software: Bluetooth Stack Step 2：In popped Bluetooth Settings, Click New Step 1：Right click on Bluetooth icon located at system tray, then select Add New Connection. Connection. Step 4：Please wait until the device names Step 3 ： Turn on the mouse and press the appear,click connection button at the bottom of mouse until BlueTooth Mouse, and then click Next.
- Page 11 Bluetooth Software: Mac OS X Bluetooth Step 2：Follow on-screen instructions to continue Step 1：Right click on Bluetooth icon located at setup. Select Mouse when below window appears. system tray, then select Set up Bluetooth Device. Step 3 ： Turn on the mouse and press the Step 4 ：...
-
Page 12: Software Installation
5. To launch the software, double click the icon on your desktop or go to Start—Programs—A4tech 8 in Right, then the icon will appear in the taskbar at the right corner of your screen.
