Wahl Digi-Stem Mounting Installation Manual

Digi-Stem Thermometer
®

Panel Mount Installation Instructions

The Panel Mount system for Wahl Digi-Stem® is designed for use with panels
from 1/8" to 3/8" thickness. The system uses a square O-ring to seal around the
meters H-Frame and the panel. The unit is secured by a U-bracket with 2 #8
wing-nuts and lock washers.
For Panel cutout dimensions and installation reference Wahl Drawing 13615.
1) Remove Hardware and bracket from mounting studs on rear of meter
enclosure.
2) Ensure the square O-ring is installed flat against the H-frame and is not
twisted.
3) Slide the meter from the front surface of the panel through the panel opening.
4) Install the U bracket over the mounting studs with the short arms facing the
rear side of the panel.
5) Install a lock washer and wing-nut onto the studs.
6) Gently tighten the wing-nuts until they just start tightening. The bracket should
not be deflected more than 0.020" (approximately ¾ to 1 turn after touching).
CAUTION: Excessive force may result in bending and fracturing the U bracket or
damaging the mounting studs.
Wahl Instruments, Inc.
234 Old Weaverville Road
Asheville, NC 28804
Toll Free 800-421-2853
Phone 828-658-3131
Fax 828-658-0728
www.palmerwahl.com
10/01/13 WD1100 Rev A
