- Page 1 High Performance Infrared Thermometer with High D:S Ratio, Adjustable Emissivity, and Built-in Laser Sighting DHS235XEL WD1048 Rev A 04/10/10...
-
Page 2: Table Of Contents
Table of Contents 1. Product Introductions....1 1-1 Features ........ 1 1-2 Applications ......1 2. Safety Information..... 2 2-1 Warning ......... 2 2-2 Safety Symbols...... 2 3. Specifications......4 4. Operation Instructions....5 4-1 Quick Start......5 4-2 Unit Diagram ......5 4-3 Displays and Controls.... -
Page 3: Features
Thank you for purchasing the Wahl DHS235XEL non- Read the following safety information carefully before contact infrared thermometer. To measure a temperature, attempting to operate or service the instrument. Only simply point the unit at the object, pull the trigger and qualified personnel should perform repairs or service not read the display. - Page 4 Restrict to use of six substances within electrical and RoHS electronic equipment (EEE), thereby contributing Distance/Spot Ratio 50:1 the protection of human health and the Temperature Range -58° to 2732°F (-50° to 1500°C) environment. Accuracy ±5.4°F (±3°C) From -58° to (Assumes Operation -4°F (-50°...
-
Page 5: Operation Instructions
4. Operation Instructions To measure a temperature, point the unit at the target pull the trigger and hold. Be sure to consider the target area inside the angle of vision of this instrument. The laser spot is used for aiming only. 4-3.4 Laser On/Off Switch –... -
Page 6: Advanced Functions
4-5 Memory 4-4 Advanced Functions 4-5.1 Memory Read – Press MODE switch until DATA (0- To operate advanced functions, pull the trigger and use A) is on steady. Unit is now in Data Read mode for the MODE button to select the desired function. Advanced memory locations DATA (1-A) or Memory Erase mode function data is displayed on the Secondary Display. -
Page 7: Technical Information
5. Technical Information 5-1 Distance to Spot Ratio The D:S Ratio is the ratio of the distance from the target to the target diameter (spot). This is determined by the optics of the unit. The smaller the target, the closer you should be to it. -
Page 8: Lens
The cost is relatively high, although in some cases is comparable to contact devices. Wahl Inst rum ent s, Inc. 234 Old Weaverville Road Asheville, NC 28804-1260 Phone: (828) 658-3131, Toll Free 1-800-421-2853 Fax: (828) 658-0728 Email: info@palmerwahl.com...
