Burkert 8200 Operating Instructions Manual
Probe holder
Hide thumbs
Also See for 8200:
- Operating instructions manual (40 pages) ,
- Operating instructions manual (48 pages) ,
- Operating instructions manual (48 pages)
Subscribe to Our Youtube Channel
Related Manuals for Burkert 8200
Summary of Contents for Burkert 8200
- Page 1 Type 8200 Probe Holder Sondenhalter Support de sonde d’analyse Operating Instructions Bedienungsanleitung Manuel d‘utilisation...
- Page 2 We reserve the right to make technical changes without notice. Technische Änderungen vorbehalten. Sous réserve de modifications techniques. © Bürkert SAS, 2013-2016 Operating Instructions 1608/01_EU-ML_00564990 / Original_FR...
-
Page 3: Table Of Contents
Type 8200 Contents 1. About these operAting instructions .......4 6.5. installation of a 8200 clamp version ........11 1.1. symbols used ..................4 6.6. installation of a 8200 for Dn50 thread process connection ..................11 1.2. Definition of the word "holder" ............4 7. mAintenAnce AnD cleAning ............12 2. intenDeD use ....................5 7.1. safety instructions ................. 12 3. bAsic sAfety informAtion ..............5 7.2. cleaning ....................12 4. generAl informAtion . -
Page 4: About These Operating Instructions
▶ Failure to observe this warning can result in death or in serious injury. 1.2. Definition of the word "holder" Warning The word "holder" used within these Operating Instructions refers to the probe holder type 8200. Warns against a potentially dangerous situation. ▶ Failure to observe this warning can result in serious injury or even death. English... -
Page 5: Intended Use
• the local safety regulations for which the operating company The 8200 probe holder allows to install an analytical probe on a is responsible including the staff in charge of installation and Bürkert S020 fitting or on a Tee fitting available on the market. -
Page 6: General Information
4.2. Warranty conditions The condition governing the legal warranty is the conforming use note of the 8200 in observance of the operating conditions specified in the holder may be damaged by the medium in contact with. these Operating Instructions. ▶ Systematically check the chemical compatibility of the compo- nent materials of the holder and the media likely to come into 4.3. -
Page 7: Technical Data
• Clamp 2", Ø 64 mm (ISO 2852) If the pressure ranges are different, use the most • For DN50 thread process connection restrictive range. (SMS 1145) 5.2. Dimensions → Please refer to the technical data sheets regarding the probe holder type 8200, available at: www.burkert.com English... - Page 8 Type 8200 Technicaldata Tab. 1 : Characteristics of the holders type of connection material medium temperature medium pressure frame seal G2" Stainless steel • With S020 PVC fitting: • With S020 PVC fitting: (316L / 1.4404), (EPDM on 0...+50°C PN10 request) • Stainless steel: •...
-
Page 9: Installation, Commissioning
Type 8200 Installation,commissioning insTAllATion, Warning commissioning risk of injury due to nonconforming installation. ▶ Installation can only be carried out by qualified and authorised 6.1. safety instructions personnel with the appropriate tools. ▶ Observe the installation instructions for the measuring device Danger inserted into the holder. -
Page 10: Installation Of A 8200 G2" Version Onto An S020 Fitting
→ Insert the nut 2 on the fitting S020, 8200 onto a Tee fitting identified 5. → Insert the snap ring 3 in the groove 4. → Stick the 8200 PVC-U holder onto → Check that the seal 1 is correctly a PVC-U Tee fitting with appropriate dimensions. -
Page 11: Installation Of A 8200 Clamp Version
→ Place the clamps together. → Fix the clamps with the flange clamp. Fig. 5 : Installation of a probe holder type 8200 for DN50 thread → Insert the probes in the corresponding holes. process connection (acc. to SMS 1145) Fig. -
Page 12: Maintenance And Cleaning
Type 8200 Maintenanceandcleaning mAinTenAnce AnD 7.2. cleaning cleAning note the holder may be damaged by the cleaning product. 7.1. safety instructions ▶ Clean the holder with a cloth dampened with water or a deter- gent compatible with the materials the holder is made of. Danger risk of injury due to high pressure in the installation. spAre pArTs AnD ▶... -
Page 13: Packaging, Transport And Storage
Type 8200 Packaging,transportandstorage pAckAging, TrAnsporT DisposAl of The proDucT AnD sTorAge → Dispose of the holder and its packaging in an environmentally- friendly way. attention note Damage due to transport Damage to the environment caused by parts contaminated by Transport may damage an insufficiently protected part. the medium ▶ Transport the holder in shock-resistant packaging and away ▶... - Page 14 Type 8200 Disposaloftheproduct English...
- Page 16 www.burkert.com...
