NewMar ACE-VAF110 Installation & Operation Manual

Model: ACE-VAF110
AC Energy Monitor
I
NSTALLATION
Introduction
The ACE-VAF110 provides accurate digital metering for AC Volts, Amps, Frequency and Kilowatts. Low/High Voltage,
Low/High Frequency and High KW alarms are easily set. When activated, the built-in 85 dB alarm will sound and the
display will flash the out-of-limit condition.
Volts can be displayed from 90 to 300 VACRMS. Amps can be displayed from 0 to 150 amps. Killowatts are displayed
from 0.0 to 45.0 kW in tenths.
The ACE-VAF110 outputs standard NMEA 0183 serial data sentences of AC volts, amps, frequency and kW. If the NMEA
0183 serial data is
not required, then this output line can be programmed to turn off a faulty generator.
Five levels of backlighting can be selected and the backlights can be remotely turned ON/OFF. All set-up, calibration and
alarm values are saved to non-volatile memory. The ACE-VAF110 comes complete with voltage and current transformers
and is factory calibrated to read within 1%. The large LCD display draws only .035 amps and only .055 amps with full
backlighting.
The ACE-VAF110 is powered with a power source of 9.5 to 33.0 VDC and transient protected.
P.O. Box 1306, Newport Beach, California 92663 • Phone: 714-751-0488 • Fax: 714-957-1621 • E-Mail: sales@newmarpower.com
/O M
PERATION ANUAL
ELECTRONIC POWER PRODUCTS
COMMUNICATION • NAVIGATION
www.newmarpower.com
M-ACE-VAF
April 2005
