WISEUP SHOP AT002 User Manual

Picture frame spy camera
Table of Contents

Advertisement

Available languages
  • EN

Available languages

  • ENGLISH, page 1
I. Product Overview
1.Camera Lens
2.USB Port
3.Micro SD Card Slot
II. What's in the Box
-1× Photo Frame Camera
-1× USB Cable
-1× 8GB Micro SD Card (fitted into the Micro SD card slot already)
AT002
User Guide
4.Green/Red Indicator Light
5.Power/Camera Button
6.Video Recording/Motion Detection Button

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT002 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for WISEUP SHOP AT002

  • Page 1 AT002 User Guide I. Product Overview 1.Camera Lens 4.Green/Red Indicator Light 2.USB Port 5.Power/Camera Button 6.Video Recording/Motion Detection Button 3.Micro SD Card Slot II. What’s in the Box -1× Photo Frame Camera -1× USB Cable -1× 8GB Micro SD Card (fitted into the Micro SD card slot already)
  • Page 2: Operation

    III. Operation >> Please make sure your camera battery is fully recharged before using. >> Please make sure the Micro SD card (4GB-32GB, format it for the first usage) is securely fitted into the camera’s SD card slot, or it will not work. A SDHC Class 10 Micro SD card is recommended.
  • Page 3: Motion Detection Recording

    3.3. CAMERA/STILL PHOTOGRAPHY 3.3.1. Power on the camera by pressing the Power Button for 2 seconds. The green indicator light will flash once and turn off, while the red indicator light will stay illuminated, indicating the camera has entered into standby mode automatically. 3.3.2.
  • Page 4 VI. Charging 6.1. Connect the camera to a PC computer by using the USB cable provided. 6.2. The indicator light will keep flashing red during the charging process. 6.3. It will take 2 hours to obtain a full charge. 6.4. When the camera is about to be fully charged, the indicator light will glow solid red;...
  • Page 5 AT002 Benutzerhandbuch I. Product Übersicht 1.Camera Objektiv Green/Red Indicator Light 2. USB-Port 5.Power / Kamera-Taste 6.Video Aufnahme / Motion-Detection-Taste 3. Micro SD-Karten-Slot II. Was ist in der Box -1 × Photo Frame-Kamera -1 × USB-Kabel -1 × 8 GB Micro SD-Karte (in den Steckplatz Micro SD-Karte ausgestattet bereits)
  • Page 6: Betrieb

    III. Betrieb >> Bitte stellen Sie sicher, dass Ihre Kamera Akku vollständig, bevor Sie wieder aufgeladen wird. >> Bitte stellen Sie sicher, dass die Micro SD-Karte (4GB-32GB, formatieren Sie es für die erste Nutzung) sicher in den SD-Kartensteckplatz der Kamera angebracht, oder es wird nicht funktionieren.
  • Page 7 [Notizen]: 1). Eine Videodatei wird erzeugt und automatisch gespeichert, alle 10 Minuten werden. 2). Die Kamera kann Video eine Stunde lang ununterbrochen auf einer vollen Ladung aufzuneh men. 3). Video-Auflösung: 1280x960 Video-Format: AVI 4). Wenn die Kamera in schwacher Batterie ist, leuchtet die Anzeige für 5 Sekunden wiederum grün und rot blinken.
  • Page 8 4.3. Die SD-Micro-Karte wird als Wechsellaufwerk erkannt werden. 4.4. Alle Dateien können im Ordner "DCIM" zugegriffen werden. V. Einstellung Zeit / Datumsstempel 5.1. Schalten Sie die Kamera aus, entfernen Sie die Micro SD-Karte und in einen Kartenleser ein. 5.2. Setzen Sie den Kartenleser in einen PC-Computer. 5.3.
  • Page 9 AT002 Mode d'emploi I. Aperçu de Produit 1.Objectif de Caméra 2.Port USB 3.Fente pour Carte SD 4.Voyant Verte/Rouge 5.Bouton de March/Caméra 6.Bouton de Video Enregistrement / Détection de mouvement II. Qu'y a-t-il dans la boitîer -1 × Cadre d’Appareil Photo...
  • Page 10: Opération

    -1 × 8 Go Carte SD (insérée dans la fente pour Carte SD déjà) III. Opération >> Assurez-vous que la batterie de votre appareil est complètement rechargée avant d'utiliser. >> Assurez-vous que la Carte SD (4 Go-32GB, formater pour la première utilisation) est solidement fixé...
  • Page 11 automatiquement. 2). La caméra peut enregistrer des vidéos pendant une heure en continu sur une charge complète. 3). Résolution de la vidéo: 1280x960 Format vidéo: AVI 4). Si l'appareil est en batterie faible, le voyant clignote vert et rouge à son tour pendant 5 secondes.
  • Page 12 V. Réglage Heure / Date Stamp 5.1. Mise hors tension de l'appareil photo, retirez la Carte SD et l'insérer dans un lecteur de carte. 5.2. Insérez le lecteur de carte dans un ordinateur PC. 5.3. Apparence de disque amovible. 5.4. Cliquez sur le lecteur dans le répertoire racine et à l'intérieur du répertoire racine, créez un fichier nommé...
  • Page 13 AT002 Mode d'emploi I. Product Vue d'ensemble 1.Camera Lens 2.USB Port Slot per scheda SD 3.Micro 4.Green/Red Spia 5.Power / macchina fotografica del tasto Pulsante 6.Video registrazione / Motion Detection II. Cosa c'è nella scatola -1 × Camera Photo Frame...
  • Page 14: Operazione

    -1 × 8 GB Micro SD Card (montato nello slot per schede Micro SD già) III. operazione >> Si prega di verificare che la batteria della fotocamera è completamente carica prima dell'uso. >> Si prega di verificare che la scheda Micro SD (4GB-32GB, formattarlo per la prima fornitura) è...
  • Page 15 2). La fotocamera può registrare video per un'ora in continuo su una carica completa. 3). Risoluzione video: 1280x960 Formato video: AVI 4). Se la fotocamera è in batteria scarica, la spia lampeggia in verde e rosso, a sua volta per 5 secondi. Il file video verrà salvato e la fotocamera si spegne automaticamente. 3.3.
  • Page 16 lettore di schede. 5.2. Inserire il lettore di schede in un computer PC. 5.3. appare cartella sul disco rimovibile. 5.4. Fare clic sul disco nella directory principale e all'interno della directory principale, creare un file denominato "TIMESET.txt". 5.5. Scrivere la data e l'ora correnti nel file "TIMESET.txt" con il formato corretto: YYYY.MM.DD HH: MM: SS (per esempio: 2016/04/12 14:24:32).
  • Page 17: Visión General Del Producto

    AT002 Guía del usuario I. Visión general del producto 1.Camera lente 2.USB Puerto 3.Ranura para tarjeta SD Micro 4.Green/Red luz indicadora 5.botón de la cámara/potencia 6.Botón de Grabación de Video / detección de movimiento II. Qué hay en la caja -1 ×...
  • Page 18: Operación

    -1 × 8GB tarjeta micro SD (encajado en la ranura para tarjetas Micro SD ya) III. Operación >> Por favor asegúrese de que su batería de la cámara está completamente cargada antes de usarla. >> Por favor asegúrese de que la tarjeta Micro SD (4GB-32GB, formato para el primer uso) ,y segura que la tarjeta está...
  • Page 19 modo de espera. [Notas]: 1). Un archivo de vídeo se genera y se guarda automáticamente cada 10 minutos. 2). La cámara puede grabar vídeo continuamente una hora con una carga completa. 3). Resolución de video: 1280x960 Formato de vídeo: AVI 4).
  • Page 20 4.3. La tarjeta Micro SD será reconocida como una unidad de disco extraíble. 4.4. Todos los archivos se puede acceder en la carpeta "DCIM". V. Ajuste de la hora / fecha sello 5.1. Apague la cámara, retire la tarjeta Micro SD e insertarla en un lector de tarjetas.
  • Page 21 AT002 ユーザーガイド I. 製品概要 1.カメラレンズ 2.USBポート 3.マイクロSDカードスロッ ト 4.インジケータライト 5.電源 /カメラボタン 6.ビデオ録画/モーション検出ボタン II.ボッ クスの中身に -1×フォ トフレームカメラ -1×USBケーブル...
  • Page 22 -1×8GBのマイクロSDカード (すでにマイクロSDカードスロッ トに装着されて います) III.操作 >>カメラをに使用する前にバッテリーが完全充電されていることを確認してく ださい. >>マイクロSDカード (最大4GB-32GBまで、 初めてのご使用の前にフォーマッ ト してくたさい) がしっかりとカメラのSDカードスロッ トに装着されているど確認 してください、 そうじゃない場合はカメラが動作しません. SDHCクラス10マイク ロSDカードをお勧めします.マイクロSDカードをカメラに装着されていない場 合は、 インジケータランプが5秒間緑と赤交代に点灯します、 その後、 5回点滅し た後にオフにします.カメラが自動的にシャッ トダウンします. 3.1. 電源のオン/オフ 3.1.1. 2秒間電源ボタンを押してカメラの電源をオンにします.緑のインジケータ ライトが一回点滅して、 同時に赤のインジケータライトが着きます、 カメラが自 動的にスタンバイモードに入ります、 . 3.1.2.再び2秒間電源ボタンを押してカメラの電源をオフにします.緑と赤のイン ジケータライトは、 その後、 一緒にオフにし、 一回点滅します.カメラが自動的に シャッ トダウンします. [注] :...
  • Page 23 1) .ビデオファイルが生成され、 10分ごとに自動的に保存されます. 2) .カメラは、 フル充電で連続1時間の映像を記録することができます. 3) .ビデオ解像度 : 1280×960 のビデオフォーマッ ト : AVI 4) .カメラがバッテリ 残量不足である場合には、 インジケータランプが5秒間今度 は緑と赤に点滅します.ビデオファイルが保存され、 カメラが自動的にシャッ トダ ウンします. 3.3.カメラ/静止画撮影 3.3.1. 2秒間電源ボタンを押してカメラの電源をオンにします.緑のインジケータ ライトが一回点滅して、 同時に赤のインジケータライトが着きます、 カメラが自動 的にスタンバイモードに入ります、 . 3.3.2.写真を撮るために、 一回カメラのボタンを押してください.赤のインジケー タライトは、 カメラが戻ってスタンバイモードにあることを示す、 それが照らさ滞 在、 一回点滅します. 3.4.モーション検知録画 3.4.1. 2秒間電源ボタンを押してカメラの電源をオンにします.緑のインジケータ ライトが一回点滅して、...
  • Page 24 V.時刻/日付スタンプを設定する 5.1.カメラの電源をオフにし、 マイクロSDカードを取り外し、 カードリーダーに挿 入してくたさい. 5.2. パソコンにカードリーダーを挿入してくたさい. 5.3.リムーバブルディスク ドライブのフォルダが表示されます. 5.4.ルートディレクトリのドライブをクリックして、 ルートディレクトリの中に、 「 TIMESET.txt "という名前のファイルを作成します. 5.5.正しい形式で 「TIMESET.txt」 ファイル内の現在の日付と時刻を書きます : YYYY.MM.DD HH : MM : SS ( 例 : 2016年4月12日午後02時24分32秒) .このファイル を保存してくたさい. 5.6.カメラを再起動し、 システムが自動的にプログラムをアップグレードします. VI.充電 6.1. 付属のUSBケーブルを使用して、 カメラをパソコンに接続してくたさい。 6.2.インジケータライトは、 充電プロセス中に赤色に点滅します. 6.3.フル充電を取得するために2時間かかります. 6.4.カメラが完全に充電されようとしているときは、 インジケータライトが赤く点 灯します.それが完全に充電されると、...
