5MM WASHER
4MM S.S
WASHER
12MM SPACER
Attach the Trunk to the Cab using the bolts, spacers and washers supplied as above. Bolt the
trunk frame mounting points highlighted in red above in Fig. 7 to the tapped bushings on
the cab highlighted in blue.
M16 X 120 BOLT, FLAT & SPRING WASHER
FIG. 7
BUSHING TOP
BUSHING
BOTTOM
40mm x 20mm
Bushing
