Sensitech TempTale Ultra Instructions For Use

TempTale
The TempTale
Starting a TempTale
®
• Press and hold the Start button (1 – 3 seconds) until the Sunshine icon
screen. The LED (1) will blink
• The TempTale Ultra will begin to record data after the programmed start-up delay period has passed.

Marking an Important Event (Date Stamp)

• TempTale Ultra monitors provide an option to Date Stamp, or mark, an important event at any time during the monitor
recording period.
• To mark an event while the monitor is recording, press and release the Start button. An Arrow
the top of the LCD screen and trip summary data will appear.
• Press and release the Start button to cycle through the trip summary data. Data appears in the following order:

Alarming

When the TempTale Ultra monitor is exposed to temperatures
outside the programmed alarm limits, an
of the screen. The icon will display if the high alarm was trig-
gered, the icon will display if the low alarm was triggered.

Stopping a TempTale Ultra Monitor

There are two ways to stop a TempTale Ultra monitor:
• Press and hold the Stop button (1 – 3 seconds) until the Stop
icon appears in the upper right corner of the screen.
• Plug the monitor into a USB port on a computer or printer.

Receiving a TempTale Ultra Monitor

• Recover the TempTale Ultra monitor, then press and hold the
RED
Stop button (1 – 3 seconds) to manually stop the unit.
NOTE: If the monitor is not stopped manually, the TempTale
Ultra monitor will continue to record data until it is plugged
into a USB port on the computer or until the programmed trip
length is reached.
• Verify the "Stop" icon

Retrieving TempTale Ultra Monitor Reports and Data Files

• Plug the monitor into a USB port on the computer. The LED will blink
RED LED stops blinking and displays solid GREEN, the file generation process is complete. The files are now accessible on a re-
When the
movable drive, as shown below. (Windows
Note: Do not disconnect the monitor from the USB port while the

Managing and Viewing TempTale Ultra Monitor Files

• If the computer has Adobe PDF compatible reader software installed, double-click the PDF file icon to open and view the PDF file.
• If the computer has Sensitech's TempTale Manager
monitor configuration information, summary statistics, and time-temperature data graph.
• Both the PDF and TTV files can be copied, saved, or emailed as an attachment.
Ultra Monitor — Instructions for Use
®
Ultra temperature monitor can be programmed with custom start-up delays,
®
measurement intervals, and time-temperature alarm settings.
Ultra Monitor
GREEN (if LED startup option was programmed) to indicate that the monitor has started.
1. Average temperature
2. Min. recorded temperature
3. Max. recorded temperature
4. Total time above high limit
5. Total time below low limit
6. Current temperature reading (This is a programmable option.)
will appear at the top
is visible on the display.
7, 8.1, and 10).
®
Desktop Software installed (8.0 or higher), double-click the TTV file icon to open and view
®
