Connecting Your Precision to your SKY Q™ Receiver
SKY Q™ Satellite Receiver
Please note the connectors to the SKY Q™ box can be connected either way around, function remains the
same.
Sky Q™ Box Set Up
- Enter SKY Q™ Menu Settings
- Highlight Settings and Enter 0, 0, 1, 'select' on the remote'
- Change LNB type from Dish to SCR

Using Your Integrated Sat Finder

Your Sat Finder is used to help you locate and find the best signal quality received from satellites.
Using the integrated sat finder.
Tune the sat finder by turning the knob fully anti-clockwise and then slowly clockwise until a deep tone is heard
and until 2-3 red LEDs are lit. Slowly rotate the dish from left to right until the pitch of the sat finder tone peaks
and more LEDs light up.
You should now have a picture on your TV.
Please note if you have a high tone on your sat finder and receiving no reception, you
!
may have located a different satellite as the sat finder is unable to distinguish between
different satellites. If this happens, repeat the above process, searching a slightly
different area and dish angle.
Fine tuning using the integrated sat finder.
Once a picture has been found, turn the sat finder down to a
deep tone and finely adjust your elevation and azimuth to
improve your signal and receive a higher tone with more lights lit.
8
Main TV
HDMI cable
HDMI
Power SAT 1 SAT 2
