Maxview Precision - SKY Q Only Variant User And Operating Instructions page 6

5
Pull down LNB arm from magnetic lock.
7
Use the elevation map to determine the required angle for your location. Set the dish to this angle using
the elevation knob and indicator. Use the Astra 2 angles for SKY™ transmissions.
6
6
Connect the Twin Flexible Cable to the cable
connection port. See page 8 for receiver end
connections.
!
The sat finder is wired
to the single port.
-
°
+
°
