Veracity HIGHWIRE Longstar Quick Start Manuals

DECLARATIONS OF
CONFORMITY
We, Veracity UK Ltd, of Prestwick International These devices comply with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
Aerospace Park, 4 Dow Road, Prestwick, KA9 2TU,
these devices may not cause harmful interference, and
UK declare under our sole responsibility that the
(2) these devices must accept any interference received,
product:
including interference that may cause undesired operation.
VLS-1P-BC HIGHWIRE Longstar (Base)
RADIO AND TELEVISION INTERFERENCE
VLS-1P-CC HIGHWIRE Longstar (Camera)
NOTE: This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15 of the FCC
are in conformity with the essential requirements
rules. These limits are designed to provide reasonable
and other relevant requirements of the EMC protection against harmful interference when the equipment is
operated in a commercial environment.
Directive (2014/108/EU)
This equipment generates, uses and can radiate radio frequency
The products are in conformity with the following energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
standards:
communications. Operation of this equipment in a residential area
EN 55022:2010
is likely to cause harmful interference in which case the user will be
EN 55024:2010 required to correct the interference at his own expense.
EN 50121-4:2006
Responsible person:
Alastair McLeod, Group CEO
Issued: 20th Mar 2015, Prestwick, © Veracity UK Ltd 2016 QSGWV1.3 UK
HIGHWIRE LONGSTAR is a trademark of Veracity UK Ltd
CONNECTIONS & LEDS CONNECTIONS & LEDS
GREEN LED
YELLOW LED
BNC coaxial connector for Veracity 57V DC
connection to any 75ohm Power Supply
coaxial cable
LED FUNCTION LED
Green RJ45 Green
Blink = Power good, no link detected On =
Rapid blink = Establishing coax link
Flash = 10Base-T link established RJ45 Yellow
On = 100Base-T link established On =
Blink off =
Yellow
On = Coax link established
Blink off = Network activity on coax link
YELLOW LED GREEN LED
RJ45 copper Ethernet
connector (speed will
match coax speed)
FUNCTION
Power good
10 or 100Base-T established
Network activity on Ethernet link
www.veracityglobal.com
VLS-1P-BC, VLS-1P-CC
QUICK START GUIDE
LONG DISTANCE EOC ADAPTOR WITH POE+
LONGSTAR
