Orion Technology OR-4534i Quick Manual

4
"Control Panel > Internet Options > Security" menu, press [Custom
5.
level...] button.
Select all the ActiveX-related options as available.
6.
Web Viewer

Learning the Live screen

\ \
a
Item Name
If selecting Dual Stream, the streams are shifted in the order of the 1st (the first stream)
Stream Change
a stream).
Full Screen Displays the image in full screen.
b
Multi Window Plays the video in two screens.
c
OSD Display or hide the OSD menu on the screen.
d
Freeze Stops transmitting the image manually.
e
Mute Used to mute the sound.
f
Snapshot Saves current image as .jpg image file.
g
Print Prints current screen.
h
Panic Record Start the panic recording.
i
Turns on if an event occurs. It does not turn on if no reaction to the event is yet defined. Click this to check
Alarm
j
the information of the event that occurred.
Stream Status Click to display the network information.
k
Timeline Date Display the current time and date.
l
Event Status/Information Click to see the event status, network information, streaming session, storage status, and system status.
m
A motion is detected by the connected camera.
n
n
b cd e f gh i j k l m
Description
2nd (the second
<
Quick Guide
WDR BULLET
NETWORK CAMERA

What's Included

1
\ \
Overview
Camera Sun Shield
CD Manual Quick Guide

At a Glance

\ \
a
b
f
c d e
3 Screws
Sun Shield Fixing Screw 3 Plastic Anchors
(PH / M4 X 30)
L Wrench BNC Cable
Item Name Description
Audio In Jack Connect to mic.
a
Used to connect the PoE cable between power
Network
b supply and network.
N Focusing on a near object (Near)
Focus control
c lever
F Focusing on a far object (Far)
T Zoom in (Tele)
Zoom control
d lever
W Zoom out (Wide)
Analog video out terminal which is used in
CVBS out
e Installing.
Press this button to restore the camera
Factory Reset
f configuration to its factory default settings.
