HTD SZA-1 Owner's Manual

Thank you for giving Home Theater Direct the chance to win your business! We are confident you
will find that HTD offers an outstanding combination of performance and value in everything we
make. To ensure you get the most out of your new equipment, please take a moment to read this
manual before you get started. Should you lose this manual, you can always download or print a
copy from www.htd.com.
SZA-1 Features
Power Button and Indicator Light
- "blue" is ON
- "amber" is in stand-by
Amplifier Protection Light - will light only when a problem
exists that triggers the built-in protection mode. Amplifier
will shut down until problem is resolved.
Mono
Source Input - RCA connections
to input sources Stereo
Mono
Stereo
Mono/Stereo Switch - Set
output to mono or stereo

Basic Connection:

• Increasingly, televisions and other devices are providing digital audio outputs. Use the DAC-1 (Digital-to-Analog Con-
verter) to convert the digital information into an analog signal necessary for whole-house audio distribution.
• Works great with Apple TV
coax cables sold separately. See the diagrams below for more information about these uses.
V.04.04.2012
Protect
POWER
INPUT
Protect
POWER L
R
INPUT
L
R
Power Switch - determines whether the amplifier
is always on (ON) or if the amplifier powers on
when an input signal is detected (Auto)
Connecting and Using the SZA-1
®
as well as other devices with either an optical or digital coax output. Optical and digital
Sub-Zone Amplifier SZA-1
Sub-Zone Amplifier SZA-1
ON AUTO Single pair of 5-way binding
post speaker terminals
POWER
L
ON AUTO
POWER
L
1
O wner 's M a n u a l
Front
VOLUME
Min Max
VOLUME
Volume Control
SPEAKERS
+
Min Max
_
6' Power Cable
AC 120V~60Hz
Power Consumption: 135W
SPEAKERS
R
4 Ω Minimum
+
_
AC 120V~60Hz
Power Consumption: 135W
R
4 Ω Minimum
Back
S Z A - 1
