- Page 1 Powered by Accton SIP Extension Server Quick Installaion Guide VES3302-36 www.edge-core.com...
- Page 3 SIP Extension Server VES3302 Quick Installation Guide...
-
Page 4: Table Of Contents
Table of Content TABLE OF CONTENT ........................2 BASIC CONFIGURATION......................3 NOTICE OF BASIC CONFIGURATION ....................3 ........................4 REPARATION BEFORE NSTALLATION VES3302 Content............................4 Shape of VES3302............................4 LED indicator of VES3302 ........................... 5 ...................... 6 ONFIGURATION OF ETWORK NVIRONMENT Configuration for Windows XP / 2000 / 98 ....................6 Enter Management Web Page........................ -
Page 5: Basic Configuration
IP/Phone ID and configure this machine to pass through NAT, and then you are able to use this device For other advanced application purpose (such as SIP IP PBX advanced function, Integration with other Edge-Core VoIP devices advanced/value-added application), please refer to the user manual in attached CD. -
Page 6: Preparation Before Installation
Power Cord x 1 unit Quick Installation Guide x 1 unit Console Cable x 1 unit Rubber Foot x 4 unit CD x 1 unit Shape of VES3302 【 】 Front Panel VES3302-36 Console MD -X Registered Alarm Stun Link/Act Time server Power... -
Page 7: Led Indicator Of Ves3302
LED indicator of VES3302 Label Description Power supply is normal ALRAM Errors detected when auto HW diagnostics running Able to access to TIME SERVER The system t ries to access TIME SERVER every 30 minutes. If TIME Flash Time Server is not reachable, the LED is flashing until the SRVR system is able to access Time Server System has not yet access to Time Server. -
Page 8: Configuration Of Network Environment
Configuration of Network Environment This chapter helps you how to configure the parameter of network Preparation before Configuration: 1. Please prepare a PC or Notebook PC. Connect one side of LAN cable to LAN and connect the other side of LAN cable to 【To WAN / MDI-X】 of VES3302. 2. - Page 9 Step 3 Right click LAN icon and click Step 4 "Properties" Single click "Ethernet Protocol (TCP/IP)" and then click "Properties" Step 5 5-1: Input the value below IP address: 192.168.0.179 Subnet Mask: 255.255.255.0 Default Gateway 192.168.0.1 DNS Server 168.95.1.1 5-2: Click OK Step 6 For Windows 2000/XP: Please follow the steps on next chapter.
-
Page 10: Enter Management Web Page
Enter Management Web Page Step 7 7-1: Start Browser and input URL: http://192.168.0.2 and then press ENTER. 7-2: Input WEB in User Name field (capitalized WEB) and leave Password blank. They are default value and it can be modified in management web later 7-3: Click OK Step 8... -
Page 11: Configure Ip And My Phone Number
Configure IP and My Phone Number This chapter tells you how to configure the IP address and My Phone Number of this machine λ IP Address: Please apply a set of IP address from Network Administrator for this machine in advance. We suggest you to use Fixed Public IP. If you use Private IP, please refer to Chapter 11 for how to pass through λ... - Page 12 Configuration of My Phone Number: 1. Click path on left column: HOME / Basic / System Config 2. Input Office or Home PSTN phone number to My Phone Number field. 3. Click Apply after phone number had been inputted Input My Phone Number and then click Apply Input Phone number.
-
Page 13: Configure Server Function
Configure Server Function The parameter of Registrar Server and Proxy Server (figure shown below and next page) is pre-configured. For general application, you only need to input correct Public Address Settings in Sub-step 5 and click Apply, and then you can go through to next Chapter If you need to configure different parameter of Server for advanced application purpose, or the setting is reset for some purpose, you can configure it by yourself... - Page 14 Steps to check or configure Proxy Server: 1. Click path on left column: HOME / Advanced-SIP / Common Check or configure each parameter according to sub-steps on the figure below. Be aware that the IP address you input must be the same as the IP address configured on chapter 3.
-
Page 15: Configure Sip Extensions No
Configure SIP Extensions No. Classify by the model you purchase, there are 12, 36 and 90 SIP Channel available. Each Channel can be registered by one SIP device as an extension. SIP phone or gateway that wants to register to this machine has to use the account and password specified by this machine. -
Page 16: Configure Prefix N O . Of Extensions (Prefix Map )
Configure Prefix No. of Extensions (Prefix Map) For the SIP Extensions that can dial to each other, you need to configure Prefix No. of this machine. Steps to configure Prefix No. of Extensions Click path on left column: HOME / Advanced-PBX /Prefix Map 2. -
Page 17: Restart This Machine
Configure IP and My Phone Number] if necessary after the system is restarted. λ Next, register SIP phone or gateway to this machine, and then you are able to make calls. For SIP phone or gateway configuration, please refer to Edge-Core Web http://WWW.EDGE-CORE.COM... -
Page 18: Verify Sip Extension Registration Status
Verify SIP Extension Registration Status User can check the registration status in this page. If the registration is fail, you are not able to dial phone call. Configuration of SIP Registration: Click path on left column: HOME / Advanced-SIP / Registrar 2. -
Page 19: How To Make A Call
How to Make a Call Basic Dialing – Dialing between extension Each SIP phone that registers to VES3302 is regarded as an extension. SIP phone dial to each other is called Dialing Between Extensions. Dialing method: (Ext. 3811 dial to Ext. 3810) 1. -
Page 20: Advanced Setting
Advanced Setting... -
Page 21: Configure Of Sip Registration Password
Configure of SIP Registration Password For security reason, we strongly suggest you configure passwords for different account according to the figure below. Step to configure SIP Extension password: 1. Click path on left column: HOME / Advanced-SIP / Inbound Auth Configure parameter according to each sub-steps in the figure below. -
Page 22: How To Pass Through Nat Or Firewall
How to pass through NAT or Firewall When VES3302 acts as Public Domain Server, it needs to use Public IP. If Public IP address is not available and need to use Private IP instead, then you should try to pass through NAT. If Firewall is used in your company, please contact network administrator to open the related Port No. -
Page 23: Q & A
Q & A... -
Page 24: What Does Channel No. Means In Web Path: Channel
What Does Channel No. Means in Web Path: Channel\? Classified by the model you purchase, VES3302 has 12, 36, 90 channels. Each channel has Channel No. (Channel No. for 12 channel model are 10-21, 36 channel model are 10~45, 90 channel model are 10~99. Each channel can be specified an Extension No. -
Page 25: Is A Single Ves3302 Able To Act Both Public Domain Server And Local Domain Server
Is a single VES3302 able to act both Public Domain Server and Local Domain Server? No, VES3302 is unable to support this structure. If VES3302 is configured as Public Domain Server, we suggest you to use Public IP and all SIP extension use Public IP, too. Use only Private IP to register Local Domain Server. -
Page 26: Appendix
Appendix... -
Page 27: Flow Chart To Create Ves3302 Sip Line Server
Flow Chart to Create VES3302 SIP Line Server Create SIP LINE WEB\IP Setting Use Private WEB\Advance-SIP\Registrar Local Domain Enable NAT (Public Domain Server) Server? Traversal (optional) WEB\Advance-SIP\STUN WEB\Advance-SIP\Registrar STUN Disable STUN Enable? Enable Registrar WEB\Advance-SIP\STUN WEB\Advance-SIP\STUN WEB\Advance-SIP\STUN Configure WEB\Advance-SIP\Common Configure Configure WAN IP of WAN IP as... -
Page 28: Channel Mapping Table
Channel Mapping Table Channel Extension Channel Extension Channel Extension Channel Channel Channel 3810 3840 3870 3811 3841 3871 3812 3842 3872 3813 3843 3873 3814 3844 3874 3815 3845 3875 3816 3846 3876 3817 3847 3877 3818 3848 3878 3819 3849 3879 3820... -
Page 29: Pre-Configured Parameter - Cfg File Specification
Pre-configured parameter - CFG File Specification The factory pre-configured parameter is listed below. When you lost the original setting, you can configure it as the list below Function Value Remark Country Code My Phone Area Code Number Phone Number 44970000 Registrar Enable NAT Traversal... - Page 30 Continued from last page Function Value Remark IP Setting Please contact Distributor Softkey Soft key string (per channel) Trigger Mode Key Press Trigger Digits Append Trigger Not Append Digit Virtual Device Channel#1 3810 (per channel) Channel#2 3811 Channel#3 3812 ……. ……...
- Page 31 Continued from last page Function Value Remark IP Setting Please contact Distributor Softkey Soft key string (per channel) Trigger Mode Key Press Trigger Digits Append Trigger Not Append Digit Virtual Device Channel#1 3810 (per channel) Channel#2 3811 Channel#3 3812 ……. ……...
- Page 33 VES3302-36 E072005-R01...
