Operating instruction
SR 90 Airline
Upprättad:
2010-07-01 / RK
Utgåva:
01
Reviderad:
Sida:
1 av 15
HI-SR 90 Airline EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR 90 Airline and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sundstrom SR 90 Airline

Summary of Contents for Sundstrom SR 90 Airline

  • Page 1 Upprättad: 2010-07-01 / RK Utgåva: HI-SR 90 Airline EN Reviderad: Sida: 1 av 15 Operating instruction SR 90 Airline...

  • Page 2: General Information

    European Standard EN 14594: 2005 and AS/NZS 1716:2003. The unique feature of the SR 90 Airline is the scope it provides for filter back-up. The SR 90 Airline is available with the face piece made of two different materials, i.e.
  • Page 3 Upprättad: 2010-07-01 / RK Utgåva: HI-SR 90 Airline EN Reviderad: Sida: 3 av 15 2.1 Unpackning 2.2 Packing list Check that the equipment is complete in accordance with the packing list and that no transport damage has occurred. • Face piece with breathing hose •...
  • Page 4 Upprättad: 2010-07-01 / RK Utgåva: HI-SR 90 Airline EN Reviderad: Sida: 4 av 15 The membranes are consumables and must be replaced if there are any signs of damage or ageing. Carefully check that the internal groove of the mask is clean and undamaged.
  • Page 5 Upprättad: 2010-07-01 / RK Utgåva: HI-SR 90 Airline EN Reviderad: Sida: 5 av 15 On every occasion before the equipment is used, check that the air flow – measured through the face piece is at least 150 l/min. Proceed as follows: Connect the breathing hose to the control valve.

  • Page 6: Combination Filter

    Upprättad: 2010-07-01 / RK Utgåva: HI-SR 90 Airline EN Reviderad: Sida: 6 av 15 Place the equipment in the bag, and grip the lower part of the bag so that the bag seals around the breathing hose. Grip the flow meter with the other hand and hold it so that the tube points vertically up from the bag.
  • Page 7 Upprättad: 2010-07-01 / RK Utgåva: HI-SR 90 Airline EN Reviderad: Sida: 7 av 15 Attach the filters to each other. The filter arrow marks should point towards the mask. The gas filter should be mounted closest to mask. Pre-filter Fit pre-filter SR 221 in the pre-filter holder and press it into place on the filter.
  • Page 8 Upprättad: 2010-07-01 / RK Utgåva: HI-SR 90 Airline EN Reviderad: Sida: 8 av 15 Mount pre-filter SR 221 in the pre-filter holder and attach this to the filter. 2.4 Putting the face piece on Belt with control valve Put the belt on and adjust the length.
  • Page 9 Upprättad: 2010-07-01 / RK Utgåva: HI-SR 90 Airline EN Reviderad: Sida: 9 av 15 Use the test disc supplied to test the tightness. Place the test disc in the pre-filter holder supplied and fit the holder to the filter. Use the test disc supplied to test the tightness.
  • Page 10 Upprättad: 2010-07-01 / RK Utgåva: HI-SR 90 Airline EN Reviderad: Sida: 10 av 15 Breathing hose / Compressed air hose Connect the breathing hose of the face piece to the control valve outlet. Unroll the compressed air tube and make sure that it is not twisted.
  • Page 11 Upprättad: 2010-07-01 / RK Utgåva: HI-SR 90 Airline EN Reviderad: Sida: 11 av 15 2.5 Taking the face piece off. When using backup-filter Remove the sealing cover, if fitted. Disconnect the compressed air hose from the control valve. See below: Leave the polluted work area and take the equipment off.

  • Page 12: Daily Maintenance

    Upprättad: 2010-07-01 / RK Utgåva: HI-SR 90 Airline EN Reviderad: Sida: 12 av 15 4.1 Cleaning Daily maintenance Remove filter or seal cover and the membranes. Wipe the mask with Sundström cleaning tissue SR 5226 witch also is disinfecting. Check and replace torn parts.

  • Page 13: Manual Cleaning

    Upprättad: 2010-07-01 / RK Utgåva: HI-SR 90 Airline EN Reviderad: Sida: 13 av 15 Manual Cleaning Remove filter, membranes and head harness. If the equipment is more heavily fouled, use a soft brush or sponge moistened with a solution of water and dishwashing detergent or the like.

  • Page 14: Maintenance Schedule

    Upprättad: 2010-07-01 / RK Utgåva: HI-SR 90 Airline EN Reviderad: Sida: 14 av 15 4.3 Maintenance schedule The schedule below shows the minimum requirements on maintenance routines to assure the user that the equipment will always be in usable condition.
  • Page 15 Upprättad: 2010-07-01 / RK Utgåva: HI-SR 90 Airline EN Reviderad: Sida: 15 av 15...
